3110-00-100-4459
Tapered Roller Bearing
3110001004459 001004459 FFB187TYPE751 32J649-86 44J66PC92 2578-2525 2525-2578 32J614PC82 32J655PC91 44J66PC91
A cylindrical device in which the inner cone or outer cup turns upon a single or double row of tapered hardened rollers which roll easily in a race, thus minimizing friction and designed to carry a radial load and capable of sustaining axial thrust. Excludes BEARING, ROLLER, THRUST. View more Tapered Roller Bearing
November 2023
15
Marketplace 3110-00-100-4459
Request a Quotation from participating marketplace vendors
Related Documents 3110-00-100-4459 5+ Documents (More...)
FFB187TYPE751 BEARING,ROLLER,TAPERED 47 EA NS Request Quotation Updated Every Day 2578-2525 RQST NE Updated
Every Day 2525-2578 RQST NE Updated Every Day 3110-00-100-4459 RQST NE Updated Every Day 3110-00-100
Restrictions 3110-00-100-4459
3110-00-100-4459 is a Tapered Roller Bearing that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 3110-00-100-4459
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3110-00-100-4459
- US Navy (N9BG)
- Effective Date:
- 1 Feb 2005
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- HD
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 3110-00-100-4459
- Part Number
- Manufacturer
- Status
- 2578-2525
- Manufacturer
- 60038 - The Timken Corporation (Active)
- Primary Buy
- Primary Buy
- FFB187TYPE751
- 81348 - Federal Specifications Promulgated (Active)
- Incomplete Standard
- Incomplete Standard
- 32J649-86
- 79500 - Westinghouse Electric Corp (Active)
- Secondary Buy
- Secondary Buy
- 44J66PC92
- 79500 - Westinghouse Electric Corp (Active)
- Secondary Buy
- Secondary Buy
- 2578-2525
- 01212 - Federal-Mogul Corp Government Sales (Active)
- Secondary Buy
- Secondary Buy
- 2525-2578
- 60038 - The Timken Corporation (Active)
- Secondary Buy
- Secondary Buy
- 2525-2578
- 79500 - Westinghouse Electric Corp (Active)
- Secondary Buy
- Secondary Buy
- 2578-2525
- 51588 - Rbc Bearings Incorporated (Active)
- Secondary Buy
- Secondary Buy
- 32J614PC82
- 79500 - Westinghouse Electric Corp (Active)
- Secondary Buy
- Secondary Buy
- 32J655PC91
- 79500 - Westinghouse Electric Corp (Active)
- Secondary Buy
- Secondary Buy
- 44J66PC91
- 79500 - Westinghouse Electric Corp (Active)
- Secondary Buy
- Secondary Buy
- 2578-2525
- 61220 - Tyson Bearing Co Div Skf Industries (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3110-00-100-4459
- Characteristic
- Specifications
- FIIG
- Specifications
- A044A0
- Backface Corner Radius [AGWU]
- 0.0310 Inches Nominal
- Bore Diameter [ABXV]
- 1.1250 Inches Nominal
- Cone Corner Radius [AGWW]
- 0.0930 Inches Nominal
- Cone Width [AGWX]
- 0.9963 Inches Nominal
- Cup Width [AGWY]
- 0.7500 Inches Nominal
- Material [MATT]
- Steel Overall
- Retainer Fabrication Method [AGYF]
- Pressed
- Overall Outside Diameter [ADGA]
- 2.8355 Inches Nominal
- Overall Width [ABMK]
- 0.9375 Inches Nominal
- Standard Tolerance Designation [CTFZ]
- Afbma Class 2
- Standout Width [AGWV]
- 0.1875 Inches Nominal
- Style Designator [STYL]
- Straight Bore, Normal Angle
DLA Procurement Analysis 3110-00-100-4459
Management Data 3110-00-100-4459
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 3110-00-100-4459
Freight Information 3110-00-100-4459
3110-00-100-4459 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 114820. A Sub NMFC of X. It has a NMFC Description of BEARINGS/BUSHINGS NOI BALL/ROLLER. 3110-00-100-4459 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 58860 which rates the freight between FCL and LCL. 3110-00-100-4459 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 742 for ocean manifesting and military sealift. 3110-00-100-4459 is not classified as a special type of cargo when transported by water. 3110-00-100-4459 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3110-00-100-4459
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- Special requirements
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Contracting Technical Data File (CTDF) 3110-00-100-4459 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
