3110-00-100-4173
Tapered Roller Bearing
3110001004173 001004173 482-472X 12314 827416AND827417 482AND472X
A cylindrical device in which the inner cone or outer cup turns upon a single or double row of tapered hardened rollers which roll easily in a race, thus minimizing friction and designed to carry a radial load and capable of sustaining axial thrust. Excludes BEARING, ROLLER, THRUST. View more Tapered Roller Bearing
May 2023
5
Marketplace 3110-00-100-4173
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 3110-00-100-4173 5+ Documents (More...)
482AND472X RQST NE Updated Every Day 3110-00-100-4173 RQST NE Updated Every Day 3110-00-100-4173 RQST
Updated Every Day 3110-00-100-4173 RQST NE Related Documents 3110-00-100-4173 5+ Documents ( More...
Tapered Roller Bearing 3110001004173 day Upgrade your Account Upgrade 3110-00-100-4173Tapered Roller
Bearing3110001004173 001004173 482-472X ... 12314 BEARING,ROLLER,TAPERED 3 EA NS Request Quotation Subscribe
Restrictions 3110-00-100-4173
3110-00-100-4173 is a Tapered Roller Bearing that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 3110-00-100-4173
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3110-00-100-4173
- US Navy (N9BG)
- Effective Date:
- 1 Feb 2005
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- HD
- Greece (ZU01)
- Effective Date:
- 1 Jun 2006
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 3110-00-100-4173
- Part Number
- Manufacturer
- Status
- 482-472X
- Manufacturer
- 60038 - The Timken Corporation (Active)
- Primary Buy
- Primary Buy
- 12314
- 61465 - Garwood/Feller Inc Garwood Winch Div (Active)
- Secondary Buy
- Secondary Buy
- 827416AND827417
- 61465 - Garwood/Feller Inc Garwood Winch Div (Active)
- Secondary Buy
- Secondary Buy
- 482AND472X
- 60038 - The Timken Corporation (Active)
- Secondary Buy
- Secondary Buy
Datasheet 3110-00-100-4173
- Characteristic
- Specifications
- FIIG
- Specifications
- A044A0
- Material [MATT]
- Steel Overall
- Style Designator [STYL]
- Straight Bore, Normal Angle
- Overall Width [ABMK]
- 1.1875 Inches Nominal
- Bore Diameter [ABXV]
- 2.7500 Inches Nominal
- Overall Outside Diameter [ADGA]
- 4.8750 Inches Nominal
- Backface Corner Radius [AGWU]
- 0.1250 Inches Nominal
- Standout Width [AGWV]
- 0.2188 Inches Nominal
- Cone Corner Radius [AGWW]
- 0.1400 Inches Nominal
- Cone Width [AGWX]
- 1.1420 Inches Nominal
- Cup Width [AGWY]
- 0.9687 Inches Nominal
- Standard Tolerance Designation [CTFZ]
- Afbma Class 2
- Retainer Fabrication Method [AGYF]
- Pressed
DLA Procurement Analysis 3110-00-100-4173
Management Data 3110-00-100-4173
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 3110-00-100-4173
Freight Information 3110-00-100-4173
3110-00-100-4173 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 114820. A Sub NMFC of X. It has a NMFC Description of BEARINGS/BUSHINGS NOI BALL/ROLLER. 3110-00-100-4173 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 58860 which rates the freight between FCL and LCL. 3110-00-100-4173 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 742 for ocean manifesting and military sealift. 3110-00-100-4173 is not classified as a special type of cargo when transported by water. 3110-00-100-4173 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3110-00-100-4173
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- Special requirements
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Contracting Technical Data File (CTDF) 3110-00-100-4173 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
