3110-00-100-4172
Tapered Roller Bearing
3110001004172 001004172 472-479 RC3525H31 571000 479-472 5556001 5556006 T126
A cylindrical device in which the inner cone or outer cup turns upon a single or double row of tapered hardened rollers which roll easily in a race, thus minimizing friction and designed to carry a radial load and capable of sustaining axial thrust. Excludes BEARING, ROLLER, THRUST. View more Tapered Roller Bearing
May 2023
19
Marketplace 3110-00-100-4172
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 3110-00-100-4172 5+ Documents (More...)
Photo 1/4 3110-00-100-4172 Photo 2/4 3110-00-100-4172 Photo 3/4 NSN 3110-00-100-4172 (Identification
Quotation Updated Every Day 472-479 RQST NE Updated Every Day 479-472 RQST NE Updated Every Day 3110
-25/fsc-2530/de 2530-12-301-9044 Fahrze Bremsanlage 2530123019044123019044 78822507882-2501000025-571000
web browser . 9905-12-174-2317Identification Plate9905121742317 121742317 7882776 7882-776 1000025-571000
99/fsc-9905/de 9905-12-174-2317 Identification Plate 9905121742317121742317 78827767882-7761000025-571000
web browser . 9905-12-174-2317Identification Plate9905121742317 12174231778827767882-776 1000025-571000
Restrictions 3110-00-100-4172
3110-00-100-4172 is a Tapered Roller Bearing that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 3110-00-100-4172
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3110-00-100-4172
- US Navy (N9BG)
- Effective Date:
- 1 Sep 2006
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- HD
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Jan 2011
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 3110-00-100-4172
- Part Number
- Manufacturer
- Status
- 472-479
- Manufacturer
- 60038 - The Timken Corporation (Active)
- Primary Buy
- Primary Buy
- RC3525H31
- 55102 - Continental Emsco Co (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 571000
- 12204 - Chrysler Realty Company Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 479-472
- 60038 - The Timken Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 479-472
- 01212 - Federal-Mogul Corp Government Sales (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 5556001
- 55102 - Continental Emsco Co (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 5556006
- 55102 - Continental Emsco Co (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- T126
- 66821 - Yale Security Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3110-00-100-4172
- Characteristic
- Specifications
- FIIG
- Specifications
- A044A0
- Material [MATT]
- Steel Overall
- Style Designator [STYL]
- Straight Bore, Normal Angle
- Overall Width [ABMK]
- 1.1730 Inches Nominal
- Bore Diameter [ABXV]
- 2.6250 Inches Nominal
- Overall Outside Diameter [ADGA]
- 4.7244 Inches Nominal
- Backface Corner Radius [AGWU]
- 0.0780 Inches Nominal
- Standout Width [AGWV]
- 0.2188 Inches Nominal
- Cone Corner Radius [AGWW]
- 0.0930 Inches Nominal
- Cone Width [AGWX]
- 1.1420 Inches Nominal
- Cup Width [AGWY]
- 0.9542 Inches Nominal
- Standard Tolerance Designation [CTFZ]
- Afbma Class 2
DLA Procurement Analysis 3110-00-100-4172
Management Data 3110-00-100-4172
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 3110-00-100-4172
Freight Information 3110-00-100-4172
3110-00-100-4172 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 114820. A Sub NMFC of X. It has a NMFC Description of BEARINGS/BUSHINGS NOI BALL/ROLLER. 3110-00-100-4172 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 58860 which rates the freight between FCL and LCL. 3110-00-100-4172 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 742 for ocean manifesting and military sealift. 3110-00-100-4172 is not classified as a special type of cargo when transported by water. 3110-00-100-4172 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3110-00-100-4172
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 3110-00-100-4172 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
