3040-01-524-9307
Linear Actuating Cylinder Assembly
3040015249307 015249307 RC-2512
A cylinder containing a piston and other component parts designed to develop linear motion required to operate a given object(s) with energy generated from either pneumatic or hydraulic pressure(s). See also CYLINDER, ACTUATING, LINEAR. Do not use if a more specific name applies. View more Linear Actuating Cylinder Assembly
May 2023
6
Marketplace 3040-01-524-9307
Request a Quotation from participating marketplace vendors
Related Documents 3040-01-524-9307 5+ Documents (More...)
Every Day 3040-01-524-9307 RQST NE Related Documents 3040-01-524-9307 1+ Documents ( More... ) https
//www.nsnlookup.com /fsg-30/fsc-3040/us 3040-01-524-9307 Linear Actuating Cylinder Assembly 015249307
Restrictions 3040-01-524-9307
3040-01-524-9307 is a Linear Actuating Cylinder Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 3040-01-524-9307
- Australia (ZA01)
- Effective Date:
- 1 Oct 2004
- Canada (ZC01)
- Effective Date:
- 1 Nov 2015
- United Kingdom (ZK01)
- Effective Date:
- 1 Dec 2012
Approved Sources 3040-01-524-9307
- Part Number
- Manufacturer
- Status
- RC-2512
- Manufacturer
- 26952 - Enerpac Tool Group Corp (Active)
- Original Design
- Original Design
- RC-2512
- Z2754 - Actuant Australia Ltd (Active)
- Secondary Buy
- Secondary Buy
- RC-2512
- ZT877 - Applied Power Australia Ltd (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3040-01-524-9307
- Characteristic
- Specifications
- FIIG
- Specifications
- A34200
- Design Characteristics [CKSD]
- Single Acting Single Cylinder
- Body Material [AAFZ]
- Steel
- Special Features [FEAT]
- Stroke In Milimeters 311; Collapsed Height In Milimeter 425.0; Cr-400 Coupler And Dust Cap Included
- Part Name Assigned By Controlling Agency [CXCY]
- Ingle Acting General Purpose Cylinder
Similar Supply Items to 3040-01-524-9307
Freight Information 3040-01-524-9307
3040-01-524-9307 has freight characteristics managed by Australia.. 3040-01-524-9307 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
