3040-01-354-0406
Shouldered Shaft
3040013540406 013540406 23506053 2HE208
A shaft having two or more different diameters (greater than 0.031 inches (0.79 millimeter)) along its length. It must have one or more of the following conditions: a specified surface finish designation in the range 1 to 125 microinches (0.025 to 3.2 micrometers) arithmetical average (AA), machined peripheral flat(s), circular groove(s), keyway(s), splines, threads, or holes. The ends and/or shoulders may be machined to accommodate bearings, couplings, and the like. It is not designed for use in aligning by fitting into corresponding holes of another item. For items used to support rotating members see AXLE(1), SHOULDERED. For items not having any of the above conditions see PIN, SHOULDER, HEADLESS. Excludes SHAFT(1), STRAIGHT; and AXLE(1), STRAIGHT. View more Shouldered Shaft
August 2025
11
Marketplace 3040-01-354-0406
Request a Quotation from participating marketplace vendors
Related Documents 3040-01-354-0406 5+ Documents (More...)
Photo 1/3 NSN 3040-01-354-0406 (Identification) 2/3 NSN 3040-01-354-0406 (Identification) 3/3 -
Day 3040-01-354-0406 RQST Updated Every Day 3040-01-354-0406 RQST NE Related Documents 3040-01-354-0406
-10HD11-10-2HE208-10-860MM A length of nonmetallic hose with fittings on one or both ends.
Shouldered Shaft 3040013540406 013540406 0406 RQST NE Related Documents 3040-01-354-0406 https/
https your web browser . 4720-99-827-8021Nonmetallic Hose Assembly4720998278021 998278021FV 834833 2HE208
-10HD11 https//www.nsnlookup.com /fsg-30/fsc-3040/us 3040-01-354-0406 Shouldered Shaft 3040013540406
Restrictions 3040-01-354-0406
3040-01-354-0406 is a Shouldered Shaft that does not have a nuclear hardened feature, but does have another critical feature or features such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 3040-01-354-0406
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3040-01-354-0406
- US Army (A920)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZ
- US Coast Guard (C911)
- Effective Date:
- 1 Apr 2007
- US Air Force (FXGC)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- FXAX
- US Navy (N9BC)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- HD
- Singapore (YJ01)
- Effective Date:
- 1 Dec 1999
- Republic of Korea (ZH01)
- Effective Date:
- 1 Dec 1997
Approved Sources 3040-01-354-0406
- Part Number
- Manufacturer
- Status
- 23506053
- Manufacturer
- 72582 - Rolls-Royce Solutions America Inc (Active)
- Primary Buy
- Primary Buy
- 2HE208
- 75Q65 - Oshkosh Defense Llc (Active)
- Secondary Buy
- Secondary Buy
- 2HE208
- 45152 - Oshkosh Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3040-01-354-0406
- Characteristic
- Specifications
- FIIG
- Specifications
- A23200
- Material [MATT]
- Steel
- First End Style [AAGZ]
- Plain
- First End Diameter [AMDL]
- 0.7460 Inches Nominal
- End Similarity [AAHN]
- Not Identical
- Second End Style [AAHP]
- External Threaded
- Second End Diameter [AMFZ]
- 0.4380 Inches Nominal
- Largest Step Diameter [CSPY]
- 1.000 Inches Nominal
- Overall Length [ABHP]
- 5.760 Inches Nominal
- Step Quantity [ATPC]
- 9
- Special Features [FEAT]
- Weapon System Essential
- Criticality Code Justification [CRTL]
- Feat
- End Item Identification [AGAV]
- 2320-01-318-9902 Het (Heavy Equipment Transporter); 2320-01-304-2277 Pls (Palletized Loading System); Wasp Class Lhd; 2320-01-097-0260 Hemtt (Heavy Expanded Mobility Tactical Truck)
- Part Name Assigned By Controlling Agency [CXCY]
- Shaft,Pump,Water
Weapon Systems (WSDC) 3040-01-354-0406
DLA Procurement Analysis 3040-01-354-0406
- Last Stock Position:
- 6 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 3040-01-354-0406
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SX
- SICA RESIDUAL MMAC-OC-ALC
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 3040-01-354-0406
Freight Information 3040-01-354-0406
3040-01-354-0406 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 126900. A Sub NMFC of Z. It has a NMFC Description of POWER TRANS SHAFTING/SHAFTS. 3040-01-354-0406 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 65750 which rates the freight between FCL and LCL. 3040-01-354-0406 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 3040-01-354-0406 is not classified as a special type of cargo when transported by water. 3040-01-354-0406 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3040-01-354-0406
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 7.7" H x -- W x -- L
- --
- --
- --
- Any Suitable Process
- 7.7" H x -- W x -- L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Vendor's Protective Grease or Oil Coating
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Procurement History 3040-01-354-0406 1 Records
Contracting Technical Data File (CTDF) 3040-01-354-0406 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
