3040-00-701-5408
Remote Control Lever
3040007015408 007015408 7015408
A rigid item usually in the form of an arm of various shapes and cross sections, containing two or more holes so spaced that one serves as a pivot with or without hubs and must have a definite means for securing to a shaft (such as threaded hole for set-screw, keyway(s), splines, serrations or some clamping device). The other hole(s) connect(s) to CONNECTING LINK, RIGID; WIRE ROPE ASSEMBLY, SINGLE LEG; or CLEVIS, ROD END; to provide transmission of movement to other parts of the mechanism. See also BELL CRANK. For manually operated items see LEVER, MANUAL CONTROL. View more Remote Control Lever
May 2023
8
Marketplace 3040-00-701-5408
Request a Quotation from participating marketplace vendors
Related Documents 3040-00-701-5408 5+ Documents (More...)
United States (US) 4. 3040-00-701-5408 Marketplace Restrictions Approved Sources Datasheet Management
RQST NE Updated Every Day 3040-00-701-5408 RQST Updated Every Day 3040-00-701-5408 RQST NE Related Documents
Restrictions 3040-00-701-5408
3040-00-701-5408 is a Remote Control Lever that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a US Munitions List Item and must be mutilated to scrap. This item is not suspected to be hazardous. The precious metals content of this item is unknown.
End Users 3040-00-701-5408
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 3040-00-701-5408
- Part Number
- Manufacturer
- Status
- 7015408
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
Datasheet 3040-00-701-5408
- Characteristic
- Specifications
- FIIG
- Specifications
- A524P0
- End Item Identification [AGAV]
- Differential Steering Brake Shaft
- Bore Diameter [ABXV]
- 1.250 Inches Minimum And 1.253 Inches Maximum
- Bore Length [ADGE]
- 1.375 Inches Nominal
- Bore Type [ASBP]
- Plain Straight
- Center To Center Distance Between Link And Shaft Holes [BFGW]
- 7.250 Inches Nominal
- Features Provided [CBBL]
- Keyway
- Material Document And Classification [MDCL]
- Mil-S-13048, Fs 1040 To Fs 1045 Mil Spec Single Material Response
- Material [MATT]
- Steel
- Keyway Length [AFYS]
- 1.375 Inches Nominal
- Keyway Width [ABRR]
- 0.251 Inches Minimum And 0.253 Inches Maximum
- Link End Hole Diameter [BFHA]
- 1.248 Inches Minimum And 1.253 Inches Maximum
- Link End Thickness [BFGY]
- 1.875 Inches Nominal
- Shaft End Thickness [BFGX]
- 1.375 Inches Nominal
- Shaft Securing Method [CZLP]
- Keyway
- Overall Width [ABMK]
- 1.688 Inches Nominal
- Special Features [FEAT]
- Offset Height: 1.719 In. Nominal
Similar Supply Items to 3040-00-701-5408
Freight Information 3040-00-701-5408
3040-00-701-5408 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 133300. A Sub NMFC of Z. It has a NMFC Description of MACHINERY/MACHINES NOI. 3040-00-701-5408 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 3040-00-701-5408 is rated as class 85 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 63220 which rates the freight between FCL and LCL. 3040-00-701-5408 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 3040-00-701-5408 is not classified as a special type of cargo when transported by water. 3040-00-701-5408 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
