3040-00-363-8093

Remote Control Lever

3040003638093 003638093 5154158BPC5151519 5151519 B5151519 PC5151519 K-5151519 5158432 N24304PC2 NX12290PC2 2990003638093

A rigid item usually in the form of an arm of various shapes and cross sections, containing two or more holes so spaced that one serves as a pivot with or without hubs and must have a definite means for securing to a shaft (such as threaded hole for set-screw, keyway(s), splines, serrations or some clamping device). The other hole(s) connect(s) to CONNECTING LINK, RIGID; WIRE ROPE ASSEMBLY, SINGLE LEG; or CLEVIS, ROD END; to provide transmission of movement to other parts of the mechanism. See also BELL CRANK. For manually operated items see LEVER, MANUAL CONTROL. View more Remote Control Lever

Managed by United States

NSN Created on 1 Jan 1963

Data Last Changed
September 2023

NATO Update Count
58

NATO Data Quality

3040-00-363-8093 LEVER,REMOTE CONTROL 3040003638093 003638093 1/1 — NSN 3040-00-363-8093 (Generic Image) 1/1

Marketplace 3040-00-363-8093

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

2990-00-363-8093 LEVER,REMOTE CONTROL 10 EA NS

Subscribe to View Vendor Details...

5151519 LEVER,REMOTE CONTROL 1 EA NS

2990-00-363-8093 LEVER,REMOTE CONTROL 2 EA NS

Subscribe to View Vendor Details...

5151519 LEVER,REMOTE CONTRO 1 EA SN

Subscribe to View Vendor Details...

B5151519 LEVER,REMOTE CONTROL 4 EA NS

Updated Every Day

5154158BPC5151519 RQST NE

Updated Every Day

N24304PC2 RQST NE

Updated Every Day

NX12290PC2 RQST NE

Updated Every Day

5158432 RQST NE

Updated Every Day

3040-00-363-8093 RQST NE

Updated Every Day

3040-00-363-8093 RQST

Updated Every Day

3040-00-363-8093 RQST NE

Restrictions 3040-00-363-8093

3040-00-363-8093 is a Remote Control Lever that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.

Import and Export 3040-00-363-8093

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 3040-00-363-8093

US Army (A920)
Effective Date:: 1 Jun 2006
Former MOE Rule:: A181
Supplementary Receivers:: AZ; AMC 3 AMSC D IMC Z IMCACTY CD

US Coast Guard (C911)
Effective Date:: 1 Jun 2006
Former MOE Rule:: C001; AMC 3 AMSC D

US Air Force (FUGC)
Effective Date:: 1 Jun 2006
Former MOE Rule:: FUAX; AMC 3 AMSC D IMC Z IMCACTY SU

US Marine Corps (MC40)
Effective Date:: 1 Jun 2006
Former MOE Rule:: MC01; AMC 3 AMSC D IMC Z IMCACTY PA

US Navy (N9BC)
Effective Date:: 1 Jun 2006
Former MOE Rule:: N9CD
Supplementary Collaborators:: GTKEJBHD; AMC 3 AMSC D IMC Z IMCACTY GH

Austria (WB01)
Effective Date:: 1 Feb 2005

Lithuania (WI01)
Effective Date:: 1 May 2001

Brazil (YA01)
Effective Date:: 1 Dec 1999

Spain (YB01)
Effective Date:: 1 Apr 1991

Singapore (YJ01)
Effective Date:: 1 Apr 1991

Kuwait (YK01)
Effective Date:: 1 Jan 2015

Morocco (YP01)
Effective Date:: 1 Sep 2011

Malaysia (YW01)
Effective Date:: 1 Sep 2005

Thailand (YY01)
Effective Date:: 1 Feb 2015

Australia (ZA01)
Effective Date:: 1 Apr 1991

Belgium (ZB01)
Effective Date:: 1 Apr 1991

Canada (ZC01)
Effective Date:: 1 Apr 1991

New Zealand (ZE01)
Effective Date:: 1 Apr 1991

France (ZF01)
Effective Date:: 1 Apr 1991

Germany (ZG01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

Netherlands (ZN01)
Effective Date:: 1 Apr 1991

Italy (ZR01)
Effective Date:: 1 Jul 1997

Denmark (ZS01)
Effective Date:: 1 Apr 1991

Norway (ZT01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Aug 1993

Approved Sources 3040-00-363-8093

Part Number
Manufacturer
Status
5151519: 72582 - Rolls-Royce Solutions America Inc (Active); Primary Buy; RNCC 3 RNVC 2 MEDALS DAC 6
5151519: K4285 - Terex Equipment Ltd (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 2
B5151519: 7U177 - Federal-Mogul Corporation (Active); Secondary Buy; RNCC 5 RNVC 2 DAC A
PC5151519: C7432 - Power Components (Deutschland) Gmbh (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
K-5151519: 18954 - Korody-Colyer Corp A Cr Industries (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
5158432: 24617 - General Motors Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
5154158BPC5151519: 24617 - General Motors Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
N24304PC2: 24617 - General Motors Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
NX12290PC2: 24617 - General Motors Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
5158432: 72582 - Rolls-Royce Solutions America Inc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
2990003638093: A00AM - E.C.A Etablissement Central Des (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
5154158BPC5151519: 7X677 - General Motors Llc (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
N24304PC2: 7X677 - General Motors Llc (Active); Advisory Reference; RNCC C RNVC 1 DAC 6
NX12290PC2: 7X677 - General Motors Llc (Active); Advisory Reference; RNCC C RNVC 1 DAC 6

Datasheet 3040-00-363-8093

Characteristic
Specifications
FIIG: A524P0
End Item Identification [AGAV]: Grumman Aircraft,Model A10 And General Motors Corp,Light Armored Vehicle Model Lav-25; Governor, Diesel Engine
Bore Diameter [ABXV]: 0.500 Inches Minimum And 0.503 Inches Maximum
Bore Length [ADGE]: 0.500 Inches Nominal
Bore Type [ASBP]: Plain Straight
Center To Center Distance Between Link And Shaft Holes [BFGW]: 2.250 Inches Nominal
Features Provided [CBBL]: Keyway
Material Document And Classification [MDCL]: Sae 1117 Assn Std 1St Material Response Or Sae 1118 Assn Std 2Nd Material Response
Material [MATT]: Steel
Keyway Width [ABRR]: 0.095 Inches Minimum And 0.105 Inches Maximum
Keyway Length [AFYS]: 0.094 Inches Nominal
Link End Hole Diameter [BFHA]: 0.311 Inches Minimum And 0.314 Inches Maximum
Link End Thickness [BFGY]: 0.319 Inches Minimum And 0.320 Inches Maximum
Shaft End Thickness [BFGX]: 0.344 Inches Nominal
Shaft Securing Method [CZLP]: Keyway
Overall Width [ABMK]: 0.875 Inches Nominal
Special Features [FEAT]: Offset Height: 0.375 In. Nominal

Weapon Systems (WSDC) 3040-00-363-8093

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 3040-00-363-8093

Last Stock Position:: 125 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 3040-00-363-8093

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Defense Logistics Agency (DS); EA; Subscribe; 1
Oct 2021: US Coast Guard (GP); EA; Subscribe; 1
Oct 2020: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2019: Department of the Army (DA); EA; Subscribe; 1

Army

Materiel Category and Inventory Manager:

J: Ground Forces Support Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Air Force

Fund:

SF: Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point

Budget:

9: 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors

Aggregation Code:

SU: AF SICA RESIDUAL MMAC-OO-ALC

Price Validation Code:

N: The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

5: Critical Repair Part to a Combat Essential End Item

Echelon Management:

B2

Material Identification:

B: Consumable Repair Parts

Operational Test:

: No Special Procedures

NATO Stock Numbers Related to 3040-00-363-8093

2915-14-464-2426 3040-33-115-9012 3040-34-031-1667 2915-99-458-0503 1680-14-450-8758 3040-15-195-2189 3040-14-548-7627 3960-14-387-3491 3040-33-116-6710 3040-14-445-5582 3040-12-177-2275 3040-14-559-2330 3040-33-103-1684 3040-12-189-8097 3040-98-104-9679 1680-14-337-3329 1680-14-315-7093 3040-14-341-4845

Freight Information 3040-00-363-8093

3040-00-363-8093 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 132330. A Sub NMFC of X. It has a NMFC Description of TRANSMISSIONS/CLUTCHES/PARTS,NOI. 3040-00-363-8093 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 64340 which rates the freight between FCL and LCL. 3040-00-363-8093 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 3040-00-363-8093 is not classified as a special type of cargo when transported by water. 3040-00-363-8093 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 3040-00-363-8093

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Bare Metal Item; Over 10lb; Less than 85G; Special Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; --

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: --; --; --; --; --; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: See Method of Preservation; --

Procurement History 3040-00-363-8093 4 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE7L023V4713: 30 Aug 2023; Subscribe; 196; Subscribe; Subscribe
SPE7L522V2171: 21 Apr 2022; Subscribe; 191; Subscribe; Subscribe
SPE7L521V1545: 21 Apr 2021; Subscribe; 175; Subscribe; Subscribe
SPE7L214M1787: 29 May 2014; Subscribe; 177; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 3040-00-363-8093 October 2021

Criticality and Quality

Critical Item Code:: X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: N
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...
