3040-00-107-8937
Straight Shaft
3040001078937 001078937 9609M97P06 9609M97P03 9609M97P02
A straight shaft having two or more of the following conditions: a specified surface finish designation in the range of 1 to 125 microinches (o.o25 to 3.2 micrometers), arithmetical average (aa), machined peripheral flat(s), circular groove (s), keyway(s), splines, threads, or holes. It is not designed for use in aligning by fitting into corresponding holes of another item. It may be drilled for lubricating holes. For items having an integral gear(s) or worm(s), see GEARSHAFT (as modified). For items designed to support rotating members see AXLE(1), STRAIGHT. For items not having the above conditions see PIN, STRAIGHT, HEADLESS. For items having machined ends which constitute steps see SHAFT(1), SHOULDERED; AXLE(1), SHOULDERED; and BOLT, FLUID PASSAGE. View more Straight Shaft
November 2023
5
Marketplace 3040-00-107-8937
Request a Quotation from participating marketplace vendors
Related Documents 3040-00-107-8937 5+ Documents (More...)
/fsg-30/fsc-3040/us
Photo 1/3 3040-00-107-8937 Photo 2/3 NSN 3040-00-107-8937 (Identification) 3/3 - - - 1.
BUY NE FedMall Updated Every Day 3040-00-107-8937 RQST NE Updated Every Day 3040-00-107-8937 RQST
/fsg-99/fsc-9999/dk
/fsg-99/fsc-9999/ca
/fsg-99/fsc-9999/ca
/fsg-99/fsc-9999/ca
Restrictions 3040-00-107-8937
3040-00-107-8937 is a Straight Shaft that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Non-Critical Munitions List Item or a Non-Sensitive Commerce Control List Item and cannnot be in the possession of any party outside of the USA who is a not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 3040-00-107-8937
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3040-00-107-8937
- US Air Force (FXGC)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- FXAX
Approved Sources 3040-00-107-8937
- Part Number
- Manufacturer
- Status
- 9609M97P06
- Manufacturer
- 07482 - General Electric Company (Active)
- Primary Buy
- Primary Buy
- 9609M97P03
- 07482 - General Electric Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 9609M97P02
- 07482 - General Electric Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3040-00-107-8937
- Characteristic
- Specifications
- FIIG
- Specifications
- A23200
- End Similarity [AAHN]
- Identical
- First End Diameter [AMDL]
- 0.2480 Inches Nominal
- First End Spline Minor Diameter [AMDN]
- 1.2260 Inches Minimum And 1.2360 Inches Maximum
- First End Spline Quantity [BDSQ]
- 26
- First End Style [AAGZ]
- Splined (Straight)
- First End Spline Length [AMDM]
- 0.910 Inches Minimum And 0.950 Inches Maximum
- First End Spline Major Diameter [AMDP]
- 1.3310 Inches Minimum And 1.3360 Inches Maximum
- Material [MATT]
- Steel
- Second End Diameter [AMFZ]
- 0.2490 Inches Nominal
- Overall Length [ABHP]
- 18.340 Inches Nominal
Weapon Systems (WSDC) 3040-00-107-8937
DLA Procurement Analysis 3040-00-107-8937
- Last Stock Position:
- 12 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 3040-00-107-8937
Similar Supply Items to 3040-00-107-8937
Freight Information 3040-00-107-8937
3040-00-107-8937 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 126900. A Sub NMFC of Z. It has a NMFC Description of POWER TRANS SHAFTING/SHAFTS. 3040-00-107-8937 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 65750 which rates the freight between FCL and LCL. 3040-00-107-8937 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 3040-00-107-8937 is not classified as a special type of cargo when transported by water. 3040-00-107-8937 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3040-00-107-8937
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 20.0" H x -- W x -- L
- --
- --
- --
- Any Suitable Process
- 20.0" H x -- W x -- L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-PRF-3420, Volatile Corrosion Inhibitor Treated Material
- --
- --
- ASTM - D5118, Fiberboard Box
- No special marking
- MIL-PRF-3420, Volatile Corrosion Inhibitor Treated Material
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Contracting Technical Data File (CTDF) 3040-00-107-8937 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
