3020-01-029-8561
Groove Pulley
3020010298561 010298561 300601 4178765
A pulley with one or more grooved faces or rims of the same diameter. For pulleys encased in a shell or frame, see BLOCK, TACKLE.For items specifically designed for aviation, see PULLEY(1), GROOVE, AVIATION. View more Groove Pulley
July 2025
13
Marketplace 3020-01-029-8561
Request a Quotation from participating marketplace vendors
Related Documents 3020-01-029-8561 5+ Documents (More...)
Groove Pulley 3020010298561 010298561,4178765 Netilmicina Solfato 6505152358026152358026 300601 -566
Groove Pulley 3020010298561 010298561,4178765 Every Day 3020-01-029-8561 RQST NE Updated Every https
Groove Pulley 3020010298561 010298561,4178765 8561 RQST NE Related Documents 3020-01-029-8561 https
Groove Pulley 3020010298561 010298561,4178765 https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00-566
www.nsnlookup.com /fsg-65/fsc-6505/it 6505-15-235-8026 Netilmicina Solfato 6505152358026152358026 300601
enable JavaScript in your web browser . 6505-15-235 -8026Netilmicina Solfato6505152358026 152358026 300601
www.nsnlookup.com /fsg-65/fsc-6505/it 6505-15-235-8727 Netilmicina Solfato 6505152358727152358727 300601
-4127 Plastic Dielectric Fixed Capacitor 005664127 8026Netilmicina Solfato6505152358026 152358026 300601
029-8561 Groove Pulley 3020010298561 010298561,4178765 Netilmicina Solfato 6505152358026152358026 300601
https//www.nsnlookup.com /fsg-30/fsc-3020/us 3020-01-029-8561 Groove Pulley 3020010298561 010298561,4178765
Restrictions 3020-01-029-8561
3020-01-029-8561 is a Groove Pulley that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 3020-01-029-8561
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3020-01-029-8561
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Aug 1993
Approved Sources 3020-01-029-8561
- Part Number
- Manufacturer
- Status
- 4178765
- Manufacturer
- 80212 - Bae Systems Land & Armaments L.P. (Active)
- Primary Buy
- Primary Buy
- 300601
- H0G87 - Wiba Zevenaar B.V. (Active)
- Secondary Buy
- Secondary Buy
- 4178765
- T0720 - Fnss Savunma Sistemleri Anonim (Active)
- NATO Reproduction
- NATO Reproduction
Datasheet 3020-01-029-8561
- Characteristic
- Specifications
- FIIG
- Specifications
- T353-A
- Distance From Center Of Bore To Bottom Of Keyway [AEVF]
- 0.609 Inches Minimum And 0.614 Inches Maximum
- Distance From Outside Flange/Rim To Hub End And Location [BYZF]
- 0.685 Inches Nominal Aa End And 0.781 Inches Nominal Bb End
- Bearings [AWJQ]
- Not Included
- Bore Diameter [ABXV]
- 1.000 Inches Minimum And 1.002 Inches Maximum
- Bore Feature [BYDS]
- Included
- Bore Length [ADGE]
- 1.904 Inches Nominal
- Bore Type [ASBP]
- Straight
- Counterbore Feature [AXND]
- Not Included
- Design Form [ARJD]
- Webbed
- Face Width [AQPL]
- 2.000 Inches Nominal
- First End Groove Diameter And Location [BYZR]
- 2.000 Inches Nominal Aa End
- First End Groove Width And Location [BYZS]
- 0.786 Inches Nominal Aa End
- Groove Depth [ABGA]
- 0.625 Inches Nominal
- Groove Quantity [AXHQ]
- 3
- Groove Shape [BXSM]
- V
- Groove Width [ABGF]
- 0.625 Inches Nominal
- Hub End Outside Diameter And Location [BYZD]
- 2.380 Inches Nominal Aa End And 2.000 Inches Nominal Bb End
- Outside Diameter [ABHE]
- 8.060 Inches Nominal
- Integral Cooling Vane [BXSK]
- Not Included
- Keyway Width [ABRR]
- 0.251 Inches Minimum And 0.253 Inches Maximum
- Keying Facility [BSGG]
- Included
- Keying Facility Type [BSGK]
- Keyway
- Lightening Hole [BXSJ]
- Included
- Material And Location [ANNQ]
- Aluminum Alloy Overall
- Pitch Diameter [AGJS]
- 6.812 Inches Nominal
- Protruding Hub Characteristic [BYDZ]
- Grooved Or Plain
- Quantity [NMBR]
- 1
- Securing Location [BYFF]
- Both Ends
- Securing Method [BSNP]
- Key
- Overall Length [ABHP]
- 2.620 Inches Minimum And 2.760 Inches Maximum
- V Groove Angle In Deg [AGGS]
- 36.0
- Web/Spoke Relationship To Face Centerline [BXSH]
- Offset
- Split Hub Feature [BSYG]
- Not Included
- Style Designator [STYL]
- Webbed Or Spoked
NATO Stock Numbers Related to 3020-01-029-8561
Freight Information 3020-01-029-8561
3020-01-029-8561 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 127300. A Sub NMFC of X. It has a NMFC Description of PULLEY BLOCKS/TCKLE/SNATCH/FAIRLDRS. 3020-01-029-8561 is rated as class 60 when transported by Less-Than Truckload (LTL) freight. 3020-01-029-8561 is rated as class 60 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 64560 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 3020-01-029-8561 is not classified as a special type of cargo when transported by water. 3020-01-029-8561 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
