3020-00-406-3518
Spur Antibacklash Gear
3020004063518 004063518 60877-7 GAB64A96P2-7
An item having one fixed gear and one free gear, both having the same complement of spur gear teeth, mounted on a common hub. The free gear is attached to the fixed gear by springs and operates as one gear. Upon installation with the mating gear, the teeth of the free moving gear are preset to mesh with teeth other than those of the fixed gear. This spring tension between the fixed gear and the free gear eliminates any free motion between the driver and the driven gear. The gear is used where identical and accurate transmitted motion between gears is required. View more Spur Antibacklash Gear
May 2023
6
Marketplace 3020-00-406-3518
Request a Quotation from participating marketplace vendors
Related Documents 3020-00-406-3518 2+ Documents (More...)
Photo 1/3 3020-00-406-3518 Photo 2/3 NSN 3020-00-406-3518 (Identification) 3/3 - - - 1.
3020-00-406-3518 2+ Documents ( More... ) https//www.nsnlookup.com /fsg-30/fsc-3020/us 3020-00-406-3518
Detector System Sensing Element6340988572684 988572684 https//www.nsnlookup.com /fsg-30/fsc-3020/us 3020-00-406-3518
Spur Antibacklash Gear 3020004063518,60877-7 www.nsnlookup.com /fsg-30/fsc-3020/us 3020-00-406-3518
Restrictions 3020-00-406-3518
3020-00-406-3518 is a Spur Antibacklash Gear that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 3020-00-406-3518
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3020-00-406-3518
- Brazil (YA01)
- Effective Date:
- 1 Dec 2001
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 3020-00-406-3518
- Part Number
- Manufacturer
- Status
- 60877-7
- Manufacturer
- 9Y580 - L3harris Technologies, Inc. (Active)
- Primary Buy
- Primary Buy
- GAB64A96P2-7
- 04391 - Fluid Mechanisms Of Hauppauge, Inc. (Active)
- Secondary Buy
- Secondary Buy
- 60877-7
- 82340 - L3harris Technologies, Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3020-00-406-3518
- Characteristic
- Specifications
- FIIG
- Specifications
- A27300
- Attachment Method [ABSX]
- Clamp
- Backlash Designation [BDZQ]
- Grade D
- Bore Nominal Diameter [CWRS]
- 0.187 Inches Both Ends
- Bore Style [ANTP]
- Plain Both Ends
- Face Nominal Width [CWRM]
- 0.125 Inches
- Material Document And Classification [MDCL]
- Qq-A-225/6,T4 Fed Spec Single Material Response Overall
- Nominal Distance Between Body Face And Protruding Hub End [CWQL]
- 0.071 Inches Second End
- Nominal Distance Between Body Face And Protruding Hub End [CWQL]
- 0.264 Inches First End
- Nominal Outside Diameter [CWCD]
- 1.530 Inches
- Material [MATT]
- Aluminum Alloy 2024 Overall
- Pressure Angle [CWPP]
- 20.0000 Degrees
- Precision Classification [CWWK]
- Quality Number 12
- Pitch Diameter [AGJS]
- 1.5000 Inches Nominal
- Style Designator [STYL]
- Protruding Hubs
- Surface Treatment Document And Classification [STDC]
- Mil-A-8625 Mil Spec Single Treatment Response Overall
- Surface Treatment [SFTT]
- Anodize Overall
- Teeth Quantity [AJLA]
- 96
- Tooth Form [CWNH]
- Standard
Similar Supply Items to 3020-00-406-3518
Freight Information 3020-00-406-3518
3020-00-406-3518 has freight characteristics managed by the Office od the Secretary of HEW.. 3020-00-406-3518 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
