3020-00-404-8458

Bevel Gear

3020004048458 004048458 YSM12F15HX1/2 HLK101Y 12M15H 122585

A gear in the form of a frustum of a cone, with straight, skewed, or curved teeth, cut on the external face. See also GEAR, ANTIBACKLASH, BEVEL. View more Bevel Gear

Managed by United States

NSN Created on 13 Aug 1969

Data Last Changed
May 2023

NATO Update Count
5

NATO Data Quality

3020-00-404-8458 GEAR,BEVEL 3020004048458 004048458 1/3 — 3020-00-404-8458 Photo 1/3

AAQL Style 1 for 3020-00-404-8458 2/3 — NSN 3020-00-404-8458 (Identification) 2/3

STYL Style 39 for 3020-00-404-8458 3/3 — NSN 3020-00-404-8458 (Identification) 3/3

Marketplace 3020-00-404-8458

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

122585 GEAR,BEVEL 1 EA NS

Updated Every Day

3020-00-404-8458 RQST NE

Updated Every Day

3020-00-404-8458 RQST

Updated Every Day

3020-00-404-8458 RQST NE

Related Documents 3020-00-404-8458 5+ Documents (More...)

https//www.nsnlookup.com
/fsg-30/fsc-3020/us

3020-00-404-8458 Bevel Gear 3020004048458 004048458

YSM12F15HX1/2 HLK101Y 122585 12M15H A gear in the form of a frustum of a cone, with straight, skewed
Photo 1/3 NSN 3020-00-404-8458 (Identification) 2/3 NSN 3020-00-404-8458 (Identification) 3/3 -
GEAR,BEVEL 1 EA NS Request Quotation Updated Every Day 3020-00-404-8458 RQST NE Updated Every Day 3020

https//www.nsnlookup.com
/fsg-53/fsc-5330/uk

5330-99-556-2252 Preformed Packing 5330995562252 995562252

JavaScript in your web browser . 5330-99-556-2252Preformed Packing5330995562252 995562252 JW122585 122585
browser . 5330-99-556-2252Preformed Packing5330995562252 995562252JW122585122585947-376088 RNVC 2 DAC 2 122585
JavaScript in your web browser . 3110-14-365-2060Bearing Ball3110143652060 143652060 124-29002-003 122585

https//www.nsnlookup.com
/fsg-31/fsc-3110/fr

3110-14-365-2060 Bearing Ball 3110143652060 143652060

JavaScript in your web browser . 3110-14-365-2060Bearing Ball3110143652060 143652060 124-29002-003 122585
JavaScript in your web browser . 3110-14-365-2060Bearing Ball3110143652060 143652060124-29002-003 122585
Bevel Gear 3020004048458 004048458 995562252 JW122585 122585 JavaScript in your web browser . 3110

https//www.nsnlookup.com
/fsg-42/fsc-4240/ca

4240-21-845-7070 Head Harness 4240218457070 218457070,376088

995562252 in your web browser . 5330-99-556-2252Preformed Packing5330995562252 995562252 JW122585 122585
www.nsnlookup.com /fsg-42/fsc-4240/ca 4240-21-845-7070 https//www.nsnlookup.com /fsg-30/fsc-3020/us 3020-00-404-8458
Bevel Gear 3020004048458 004048458 Obsolete) Original Design RNCC 3 RNVC 9 DAC 2 122585 https//

https//www.nsnlookup.com
/fsg-73/fsc-7330/us

7330-01-467-7718 Insulated Jug 7330014677718 014677718,320L

for $1 a day Upgrade your Account Upgrade 7330-01-467-7718Insulated Jug7330014677718 014677718 320L 122585
Vendor Details... 320L JUG,INSULATED 100 EA NS Request Quotation Subscribe to View Vendor Details... 122585
NumberManufacturerStatus320L 02707 - American Production Co Inc (Obsolete) Original Design RNCC 3 RNVC 9 DAC 2 122585

Restrictions 3020-00-404-8458

3020-00-404-8458 is a Bevel Gear that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.

Import and Export 3020-00-404-8458

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 3020-00-404-8458

US Army (A920)
Effective Date:: 1 Jul 2005
Former MOE Rule:: A181
Supplementary Receivers:: CL; AMC 1 AMSC L IMC Z IMCACTY CU

US Air Force (FXGC)
Effective Date:: 1 Jul 2005
Former MOE Rule:: FXAX; AMC 1 AMSC L IMC Z IMCACTY SX

US Marine Corps (MC40)
Effective Date:: 1 Jul 2005
Former MOE Rule:: MC01; AMC 1 AMSC L IMC Z IMCACTY PA

Poland (WP01)
Effective Date:: 1 Aug 2011

Approved Sources 3020-00-404-8458

Part Number
Manufacturer
Status
YSM12F15HX1/2: 71176 - Emerson Electric Co Browning Mfg Div (Active); Primary Buy; RNCC 3 RNVC 2 DAC A
HLK101Y: 71041 - Altra Industrial Motion Corp. (Active); Secondary Buy; RNCC 5 RNVC 2 DAC E
12M15H: 76474 - Emerson Power Transmission (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC A
122585: 76474 - Emerson Power Transmission (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC A

Datasheet 3020-00-404-8458

Characteristic
Specifications
FIIG: A27300
Body Style [AAQL]: Plain, Solid
Bore Nominal Diameter [CWRS]: 0.5003 Inches Both Ends
Bore Style [ANTP]: W/ Keyway Both Ends
Face Nominal Width [CWRM]: 0.2700 Inches
Hub Style Designator [CWTR]: Plain Second End
Hub Nominal Diameter [CWTX]: 0.1000 Inches Second End
Nominal Distance From Bore Center To Keyway Bottom [CWSR]: 0.3130 Inches Both Ends
Nominal Distance Between Body Face And Protruding Hub End [CWQL]: 0.5000 Inches Second End
Nominal Outside Diameter [CWCD]: 1.3700 Inches
Nominal Overall Length [CWFR]: 0.8565 Inches
Material [MATT]: Steel Overall
Keyway Nominal Width [CWSN]: 0.1255 Inches Both Ends
Pressure Angle [CWPP]: 20.0000 Degrees
Pitch Diameter [AGJS]: 1.2500 Inches Nominal
Pitch Angle [CWQD]: 45.0000 Degrees
Style Designator [STYL]: Peripheral Face, Back Hub Protruding
Teeth Quantity [AJLA]: 15
Teeth Type [CWMW]: Straight

Subscribe
View Data

DLA Procurement Analysis 3020-00-404-8458

DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 3020-00-404-8458

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Army (DA); EA; Subscribe; 1
Oct 2021: Department of the Army (DA); EA; Subscribe; 1
Oct 2020: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2019: Department of the Air Force (DF); EA; Subscribe; 1

Army

Materiel Category and Inventory Manager:

J: Ground Forces Support Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

5: Critical Repair Part to a Combat Essential End Item

Echelon Management:

B2

Operational Test:

: No Special Procedures

Similar Supply Items to 3020-00-404-8458

Freight Information 3020-00-404-8458

3020-00-404-8458 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 121870. A Sub NMFC of X. It has a NMFC Description of GEAR/SPEED INCREASING/REDUCING MACH. 3020-00-404-8458 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 64910 which rates the freight between FCL and LCL. 3020-00-404-8458 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 586 for ocean manifesting and military sealift. 3020-00-404-8458 is not classified as a special type of cargo when transported by water. 3020-00-404-8458 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 3020-00-404-8458

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Bare Metal Item; Over 10lb; Less than 85G; Special Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: --; MIL-PRF-121, Greaseproof, Waterproof Barrier; --; --; PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: Any Suitable Fiber Box

Contracting Technical Data File (CTDF) 3020-00-404-8458 October 2021

Criticality and Quality

Critical Item Code:
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: N
