3020-00-288-3197
Worm Gear
3020002883197 002883197 H1407 H1407RH
A gear with teeth on its outer surface in the form of helical threads. View more Worm Gear
May 2023
9
Marketplace 3020-00-288-3197
Request a Quotation from participating marketplace vendors
Related Documents 3020-00-288-3197 5+ Documents (More...)
H1407 GEAR,WORM 99 EA NS Request Quotation Subscribe to View Vendor Details... 3020-00-288-3197 GEAR,
/fsg-30/fsc-3020/us 3020-00-288-3197 Worm Gear 3020002883197002883197,H1407 H1407H1407RH A gear with
https//www.nsnlookup.com /fsg-30/fsc-3020/us 3020-00-288-3197 Worm Gear 3020002883197 002883197,H1407
Upgrade for $1 a day Upgrade your Account Upgrade 3020-00-288-3197Worm Gear3020002883197 002883197 H1407
H1407 GEAR,WORM 99 EA NS Request Quotation Subscribe to View Vendor Details... 3020-00-288-3197 GEAR
Worm Gear 3020002883197 002883197,H1407 Upgrade for $1 a day Upgrade your Account Upgrade 3020-
Documents 7021-12-700-5256 3+ Documents https/ https// https//www.nsnlookup.com /fsg-30/fsc-3020/us 3020-00-288-3197
Worm Gear 3020002883197 002883197,H1407 CG16/M6 to View Vendor Details... 3020-00-288-3197 https
www.nsnlookup.com /fsg-70/fsc-7021/de 7021-12-703-2844 https//www.nsnlookup.com /fsg-30/fsc-3020/us 3020-00-288-3197
Worm Gear 3020002883197 002883197,H1407 for $1 a day Upgrade your Account Upgrade 3020- https//
Restrictions 3020-00-288-3197
3020-00-288-3197 is a Worm Gear that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 3020-00-288-3197
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3020-00-288-3197
- US Navy (N9BC)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GTHD
Approved Sources 3020-00-288-3197
- Part Number
- Manufacturer
- Status
- H1407
- Manufacturer
- 71041 - Altra Industrial Motion Corp. (Active)
- Primary Buy
- Primary Buy
- H1407RH
- 71041 - Altra Industrial Motion Corp. (Active)
- Secondary Buy
- Secondary Buy
- H1407
- 63689 - Profile Gear Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3020-00-288-3197
- Characteristic
- Specifications
- FIIG
- Specifications
- A27300
- Material [MATT]
- Steel Overall
- Face Type [ALPN]
- Straight
- Thread Form Quantity [CWPC]
- 2
- Thread Form Direction [CWPH]
- Right-Hand
- Pressure Angle [CWPP]
- 14.5000 Degrees
- Helix Angle [CWPZ]
- 9.4665 Degrees
- Style Designator [STYL]
- Hubless
- Pitch Diameter [AGJS]
- 1.0000 Inches Nominal
- Nominal Outside Diameter [CWCD]
- 1.167 Inches
- Face Nominal Width [CWRM]
- 1.125 Inches
- Bore Style [ANTP]
- W/ Keyway Both Ends
- Bore Nominal Diameter [CWRS]
- 0.625 Inches Both Ends
- Keyway Nominal Width [CWSN]
- 0.125 Inches Both Ends
- Nominal Distance From Bore Center To Keyway Bottom [CWSR]
- 0.375 Inches Both Ends
Weapon Systems (WSDC) 3020-00-288-3197
DLA Procurement Analysis 3020-00-288-3197
Management Data 3020-00-288-3197
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 3020-00-288-3197
Freight Information 3020-00-288-3197
3020-00-288-3197 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062070. A Sub NMFC of Z. It has a NMFC Description of GEAR MOTORS/PARTS NOI. 3020-00-288-3197 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 64910 which rates the freight between FCL and LCL. 3020-00-288-3197 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 3020-00-288-3197 is not classified as a special type of cargo when transported by water. 3020-00-288-3197 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3020-00-288-3197
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Vendor's Protective Grease or Oil Coating
- MIL-PRF-121, Greaseproof, Waterproof Barrier
- --
- --
- --
- No special marking
- MIL-PRF-121, Greaseproof, Waterproof Barrier
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Contracting Technical Data File (CTDF) 3020-00-288-3197 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
