3020-00-266-6515
Helical Gear
3020002666515 002666515 PGF9073 PGF9073A
A gear, cylindrical in form, with teeth on the outer surface at an angle to the axis of the gear. See also GEAR, ANTIBACKLASH, HELICAL: View more Helical Gear
May 2023
14
Marketplace 3020-00-266-6515
Request a Quotation from participating marketplace vendors
Related Documents 3020-00-266-6515 5+ Documents (More...)
Photo 1/6 3020-00-266-6515 Photo 2/6 3020-00-266-6515 Photo 3/6 3020-00-266-6515 Photo 4/6 NSN
3020-00-266-6515 (Identification) 5/6 NSN 3020-00-266-6515 (Identification) 6/6 - - - - - - 1.
/us 3020-01-122-7912 Helical Gear 3020011227912 011227912,,5107079 122-7912 3020-00-273-3831 3020-00-266-6515
Special Procedures Similar Supply Items to 3020-01-123-8875 3020-00-273-3831 3020-01-122-7912 3020-00-266-6515
Restrictions 3020-00-266-6515
3020-00-266-6515 is a Helical Gear that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 3020-00-266-6515
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3020-00-266-6515
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Sep 2009
Approved Sources 3020-00-266-6515
- Part Number
- Manufacturer
- Status
- PGF9073
- Manufacturer
- 77237 - Dana Off Highway Products, Llc (Active)
- Primary Buy
- Primary Buy
- PGF9073A
- 77237 - Dana Off Highway Products, Llc (Active)
- Primary Buy
- Primary Buy
- PGF9073A
- 40152 - Vme Americas Inc Sub Of Vme Group N (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- PGF9073
- 40152 - Vme Americas Inc Sub Of Vme Group N (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3020-00-266-6515
- Characteristic
- Specifications
- FIIG
- Specifications
- A27300
- Teeth Quantity [AJLA]
- 28
- Teeth Type [CWMW]
- Single Helix
- Tooth Form [CWNH]
- Standard
- Tooth Direction [CWNM]
- Right
- Pressure Angle [CWPP]
- 20.0000 Degrees
- Style Designator [STYL]
- Protruding Hubs
- Pitch Diameter [AGJS]
- 4.6660 Inches Nominal
- Face Nominal Width [CWRM]
- 1.562 Inches
- Bore Style [ANTP]
- Straight Spline Both Ends
- Spline Quantity [ABSA]
- 6 Both Ends
- Hub Style Designator [CWTR]
- Plain Both Ends
- Hub Nominal Diameter [CWTX]
- 3.000 Inches First End
- Hub Nominal Diameter [CWTX]
- 3.000 Inches Second End
- Body Style [AAQL]
- Webbed, Offset, Solid
Similar Supply Items to 3020-00-266-6515
Freight Information 3020-00-266-6515
3020-00-266-6515 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 197339. A Sub NMFC of X. It has a NMFC Description of WHEELS COG/GEAR/PINION I/S. 3020-00-266-6515 is rated as class 65 when transported by Less-Than Truckload (LTL) freight. 3020-00-266-6515 is rated as class 60 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 96710 which rates the freight between FCL and LCL. 3020-00-266-6515 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 3020-00-266-6515 is not classified as a special type of cargo when transported by water. 3020-00-266-6515 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
