3020-00-200-2131
Helical Gear
3020002002131 002002131 008-2932 H2932 86FT47 231822 BB22154 5861 395422
A gear, cylindrical in form, with teeth on the outer surface at an angle to the axis of the gear. See also GEAR, ANTIBACKLASH, HELICAL: View more Helical Gear
May 2023
24
Marketplace 3020-00-200-2131
Request a Quotation from participating marketplace vendors
Related Documents 3020-00-200-2131 5+ Documents (More...)
Photo 1/5 3020-00-200-2131 Photo 2/5 3020-00-200-2131 Photo 3/5 NSN 3020-00-200-2131 (Identification
Updated Every Day 3020-00-200-2131 RQST NE Updated Every Day 3020-00-200-2131 RQST Updated Every Day
$1 5861 008-2932 H2932 86FT47 231822 BB22154 395422 https//www.nsnlookup.com /fsg-59/fsc-5915 Intercommunication
$1 5861 008-2932 H2932 86FT47 231822 BB22154 395422 https/ https//www.nsnlookup.com /fsg-59/fsc-5998
/www.nsnlookup.com /fsg-49/fsc-4920/it 4920-15-053-7894 Apparato Controllo 4920150537894150537894 231822
Helical Gear 3020002002131 002002131,5861 7894Apparato Controllo4920150537894 150537894 https//
395422 $1 5861 008-2932 H2932 86FT47 231822 BB22154 395422 https//www.nsnlookup.com /fsg-59/fsc-5915
Intercommunication Set Control 5830143584311 7022Mounting Bracket5340144657022 144657022 395422 https
enable JavaScript in your web browser . 4920-15-057 -1638Tester Fuel Pouring4920150571638 150571638 231822
www.nsnlookup.com /fsg-49/fsc-4920/it 4920-15-057-1638 Tester Fuel Pouring 4920150571638150571638 us 3020-00-200-2131
Restrictions 3020-00-200-2131
3020-00-200-2131 is a Helical Gear that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 3020-00-200-2131
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3020-00-200-2131
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 3020-00-200-2131
- Part Number
- Manufacturer
- Status
- 5861
- Manufacturer
- 73460 - Eaton Corp Transmission Div (Active)
- Primary Buy
- Primary Buy
- 008-2932
- 95685 - Marathon Le Tourneau Co (Active)
- Secondary Buy
- Secondary Buy
- H2932
- 35311 - American Standard Inc (Obsolete)
- Secondary Buy
- Secondary Buy
- H2932
- 95685 - Marathon Le Tourneau Co (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 86FT47
- 45152 - Oshkosh Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 231822
- 08683 - Brockway Motor Trucks Div Of Mack (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- BB22154
- 56442 - Diamond Reo Truck Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 5861
- 63734 - Kaitlin Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 395422
- 65282 - White Motor Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3020-00-200-2131
- Characteristic
- Specifications
- FIIG
- Specifications
- A27300
- Body Style [AAQL]
- Webbed, Solid
- Bore Nominal Diameter [CWRS]
- 2.485 Inches Both Ends
- Bore Style [ANTP]
- W/ Keyway Both Ends
- Face Nominal Width [CWRM]
- 1.750 Inches
- Helix Angle [CWPZ]
- 23.4167 Degrees
- Hub Nominal Diameter [CWTX]
- 3.250 Inches First End
- Hub Nominal Diameter [CWTX]
- 3.250 Inches Second End
- Hub Style Designator [CWTR]
- Plain Both Ends
- Nominal Distance From Bore Center To Keyway Bottom [CWSR]
- 1.427 Inches Both Ends
- Nominal Distance Between Body Face And Protruding Hub End [CWQL]
- 0.375 Inches First End
- Nominal Outside Diameter [CWCD]
- 6.4240 Inches
- Nominal Overall Length [CWFR]
- 2.123 Inches
- Material [MATT]
- Steel Comp 8620H Overall
- Keyway Nominal Width [CWSN]
- 0.378 Inches Both Ends
- Material Document And Classification [MDCL]
- 66 Fed Std Single Material Response Overall
- Pressure Angle [CWPP]
- 20.0000 Degrees
- Pitch Diameter [AGJS]
- 6.0210 Inches Nominal
- Style Designator [STYL]
- One Protruding Hub, One Flush Hub
- Teeth Quantity [AJLA]
- 37
- Teeth Type [CWMW]
- Single Helix
- Tooth Direction [CWNM]
- Right
- Tooth Form [CWNH]
- Stub
Similar Supply Items to 3020-00-200-2131
Freight Information 3020-00-200-2131
3020-00-200-2131 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 197339. A Sub NMFC of X. It has a NMFC Description of WHEELS COG/GEAR/PINION I/S. 3020-00-200-2131 is rated as class 65 when transported by Less-Than Truckload (LTL) freight. 3020-00-200-2131 is rated as class 60 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 96710 which rates the freight between FCL and LCL. 3020-00-200-2131 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 3020-00-200-2131 is not classified as a special type of cargo when transported by water. 3020-00-200-2131 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
