3020-00-186-2840
Groove Pulley
3020001862840 001862840 65850-0500-043 656850-05005-043 65850-05005-043 65850-05005-041
A pulley with one or more grooved faces or rims of the same diameter. For pulleys encased in a shell or frame, see BLOCK, TACKLE.For items specifically designed for aviation, see PULLEY(1), GROOVE, AVIATION. View more Groove Pulley
May 2023
7
Marketplace 3020-00-186-2840
Request a Quotation from participating marketplace vendors
Related Documents 3020-00-186-2840 5+ Documents (More...)
Photo 1/5 3020-00-186-2840 Photo 2/5 3020-00-186-2840 Photo 3/5 3020-00-186-2840 Photo 4/5 NSN
to View Vendor Details... 65850-05005-043 PULLEY 1 EA NS Request Quotation Updated Every Day 3020-00
Groove Pulley 3020001862840 001862840 -0500-043 656850-05005-043 65850-05005-043 65850-05005-041
faces or -05005-043 PULLEY,GROOVE 1 EA NS Request Quotation Subscribe to View Vendor Details... 65850-05005-043
Groove Pulley 3020001862840 001862840 -043 65850-05005-043 65850-05005-041 A pulley with one or
Groove Pulley 3020001862840 001862840 -043 65850-05005-043 65850-05005-041 A pulley with one or
diameter -04365850-05005-04365850-05005-041 A pulley with one or more grooved faces Photo 1/5 3020-00-186-2840
Groove Pulley 3020001862840 001862840 -043 65850-05005-043 65850-05005-041 A pulley with one or
Restrictions 3020-00-186-2840
3020-00-186-2840 is a Groove Pulley that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 3020-00-186-2840
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3020-00-186-2840
- US Navy (N9BC)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- KE
Approved Sources 3020-00-186-2840
- Part Number
- Manufacturer
- Status
- 65850-05005-043
- Manufacturer
- 57145 - Mohawk Fabric Co Inc (Active)
- Original Design
- Original Design
- 65850-0500-043
- 4A014 - Richard Manufacturing Co., Inc. (Active)
- Secondary Buy
- Secondary Buy
- 656850-05005-043
- 2A269 - Macor Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 65850-05005-043
- 78286 - Sikorsky Aircraft Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 65850-05005-041
- 78286 - Sikorsky Aircraft Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 65850-05005-041
- 2A269 - Macor Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 65850-05005-041
- 4A014 - Richard Manufacturing Co., Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 65850-0500-043
- 2A269 - Macor Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3020-00-186-2840
- Characteristic
- Specifications
- FIIG
- Specifications
- T353-A
- Style Designator [STYL]
- Webbed Or Spoked
- Outside Diameter [ABHE]
- 4.125 Inches Nominal
- Face Width [AQPL]
- 0.605 Inches Nominal
- Hub End Outside Diameter And Location [BYZD]
- 1.960 Inches Nominal Both Ends
- Distance From Outside Flange/Rim To Hub End And Location [BYZF]
- 0.219 Inches Nominal Both Ends
- Design Form [ARJD]
- Webbed
- Web/Spoke Relationship To Face Centerline [BXSH]
- Not Offset
- Lightening Hole [BXSJ]
- Not Included
- Integral Cooling Vane [BXSK]
- Not Included
- Material And Location [ANNQ]
- Steel Overall
- Groove Shape [BXSM]
- U
- Groove Quantity [AXHQ]
- 1
- Groove Depth [ABGA]
- 0.315 Inches Nominal
- Groove Width [ABGF]
- 0.490 Inches Nominal
- Groove Radius [AGWA]
- 0.218 Inches Nominal
- Bore Feature [BYDS]
- Included
- Bearings [AWJQ]
- Included
- Bearing Type [BYDT]
- Sleeve
- Bearing Quantity [BDDY]
- 1
- Bore Type [ASBP]
- Straight
- Bore Diameter [ABXV]
- 0.500 Inches Nominal
- Bore Length [ADGE]
- 0.750 Inches Nominal
- Counterbore Feature [AXND]
- Not Included
- Keying Facility [BSGG]
- Not Included
- Split Hub Feature [BSYG]
- Not Included
DLA Procurement Analysis 3020-00-186-2840
Management Data 3020-00-186-2840
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 3020-00-186-2840
Freight Information 3020-00-186-2840
3020-00-186-2840 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 127320. A Sub NMFC of X. It has a NMFC Description of PULLEYS/SHEAVES,NOI. 3020-00-186-2840 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 64560 which rates the freight between FCL and LCL. 3020-00-186-2840 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 3020-00-186-2840 is not classified as a special type of cargo when transported by water. 3020-00-186-2840 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 3020-00-186-2840 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
