3020-00-040-2169
Sprocket Wheel
3020000402169 000402169 8330110 840E17
A toothed wheel whose teeth or sprockets are designed to be engaged with the links of a pitch chain, track, or the like. It is usually used for transmitting power. View more Sprocket Wheel
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
August 2023
August 2023
NATO Update Count
20
20
NATO Data Quality
Marketplace 3020-00-040-2169
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 3020-00-040-2169 5+ Documents (More...)
https//www.nsnlookup.com
/fsg-30/fsc-3020/us
/fsg-30/fsc-3020/us
3020-00-040-2169 Sprocket Wheel 3020000402169 000402169
8330110 840E17 A toothed wheel whose teeth or sprockets are designed to be engaged with the links of
Photo 1/2 NSN 3020-00-040-2169 (Identification) 2/2 - - 1.
RQST NE Updated Every Day 3020-00-040-2169 RQST Updated Every Day 3020-00-040-2169 RQST NE Related Documents
Photo 1/2 NSN 3020-00-040-2169 (Identification) 2/2 - - 1.
RQST NE Updated Every Day 3020-00-040-2169 RQST Updated Every Day 3020-00-040-2169 RQST NE Related Documents
enable JavaScript in your web browser . 5998-21-898-0928Circuit Card Assembly5998218980928 218980928 8330110
www.nsnlookup.com /fsg-59/fsc-5998/ca 5998-21-898-0928 Circuit Card Assembly 5998218980928218980928 8330110
www.nsnlookup.com /fsg-59/fsc-5998/ca 5998-21-898-0928 https//www.nsnlookup.com /fsg-30/fsc-3020/us 3020-00-040-2169
www.nsnlookup.com /fsg-59/fsc-5998/ca 5998-21-898-0928 Circuit Card Assembly 5998218980928218980928 8330110
www.nsnlookup.com /fsg-59/fsc-5998/ca 5998-21-898-0928 https//www.nsnlookup.com /fsg-30/fsc-3020/us 3020-00-040-2169
https//www.nsnlookup.com
/fsg-99/fsc-9999/dk
/fsg-99/fsc-9999/dk
9999-22-608-3978 Sprocket Wheel 9999226083978 226083978
9999-22-608-3978 is a Sprocket Wheel Similar Supply Items to 9999-22-608-3978 3020-01-491-2622 3020-00-040-2169
https//www.nsnlookup.com
/fsg-99/fsc-9999/uk
/fsg-99/fsc-9999/uk
9999-99-610-9800 Sprocket Wheel 9999996109800 996109800
9999-99-610-9800 is a Sprocket Wheel Similar Supply Items to 9999-99-610-9800 3020-01-491-2622 3020-00-040-2169
https//www.nsnlookup.com
/fsg-70/fsc-7025/nz
/fsg-70/fsc-7025/nz
7025-98-855-1139 Sprocket Wheel 7025988551139 988551139
7025-98-855-1139 is a Sprocket Wheel Similar Supply Items to 7025-98-855-1139 3020-01-491-2622 3020-00-040-2169
Restrictions 3020-00-040-2169
3020-00-040-2169 is a Sprocket Wheel that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 3020-00-040-2169
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3020-00-040-2169
- US Army (A920)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- A181
- US Marine Corps (MC40)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- MC01
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 3020-00-040-2169
- Part Number
- Manufacturer
- Status
- 8330110
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- 840E17
- 56442 - Diamond Reo Truck Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3020-00-040-2169
- Characteristic
- Specifications
- FIIG
- Specifications
- T353-C
- Distance From Center Of Bore To Bottom Of Keyway [AEVF]
- 0.683 Inches Maximum
- Distance From Outside Flange/Rim To Hub End And Location [BYZF]
- 1.0625 Inches Nominal Both Ends And 1.0625 Inches Nominal Both Ends
- Asa Standard Chain Number [BYFP]
- 50
- Belt/Chain/Film Size For Which Designed [BYFH]
- Roller Chain
- Bore Bearing [BYFS]
- Not Included
- Bore Diameter [ABXV]
- 1.125 Inches Minimum And 1.126 Inches Maximum
- Bore Length [ADGE]
- 1.3125 Inches Nominal
- Bore Type [ASBP]
- Straight
- Counterbore Feature [AXND]
- Not Included
- Design Form [ARJD]
- Plain
- Furnished Items And Quantity [AKYN]
- One 1/4 In. -20 By 3/16 In. Lg Setscrew
- Face Width [AQPL]
- 0.240 Inches Nominal
- Groove/Step Location [BYFB]
- Aa End
- Hardness Rating Test Method [BYFQ]
- Rockwell
- Hole Location [BFYT]
- Located On Top Of Keyway
- Hub External Keyway [BYFW]
- Not Included
- Material [MATT]
- Steel
- Metallic Hardness Rating And Location [ASXJ]
- 58.0 Rockwell C Nominal Body
- Outside Diameter [ABHE]
- 2.4375 Inches Nominal
- Style Designator [STYL]
- Plain
- Keyway Width [ABRR]
- 0.250 Inches Nominal
- Keying Facility Type [BSGK]
- Keyway
- Keying Facility [BSGG]
- Included
- Lightening Hole [BXSJ]
- Not Included
- Protruding Hub Characteristic [BYDZ]
- Stepped
- Quantity [NMBR]
- 1
- Roller Chain Pitch Type For Which Designed [BYFJ]
- Single Pitch
- Securing Hole Quantity [AHYF]
- 1
- Securing Location [BYFF]
- Aa End
- Securing Method [BSNP]
- Threaded Hole
- Overall Length [ABHP]
- 1.3125 Inches Nominal
- Pitch Diameter [AGJS]
- 2.415 Inches Nominal
- Special Features [FEAT]
- First Step Face Largest Diameter 1.6875 In.,First Step Length 0.500 In.,Second Step Length 0.5625 In.
- Teeth Hardness Rating [BYFR]
- 50.0 Rockwell C Minimum
- Teeth Quantity Per Row [BYFN]
- 12
- Teeth Row Quantity [BYFL]
- 1
- Thread Size [ABUJ]
- 1/4 In.-20
- Tooth Pitch [BYGF]
- 0.625 Inches Nominal
DLA Procurement Analysis 3020-00-040-2169
Management Data 3020-00-040-2169
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- K
- Reserved
- Operational Test:
- No Special Procedures
Similar Supply Items to 3020-00-040-2169
Freight Information 3020-00-040-2169
3020-00-040-2169 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 117020. A Sub NMFC of X. It has a NMFC Description of CHAIN AND SPROCKET DRIVES/WHEELS. 3020-00-040-2169 is rated as class 60 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 59820 which rates the freight between FCL and LCL. 3020-00-040-2169 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 3020-00-040-2169 is not classified as a special type of cargo when transported by water. 3020-00-040-2169 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
