3010-01-441-6323
Rigid Shaft Coupling
3010014416323 014416323 12448907 RCSK14638
A device for connecting the ends of two shafts to produce in effect, one piece of rigid shafting so that the rotary motion of one shaft is transmitted to the other shaft. Couplings of the sleeve type must have an over-all length exceeding the outside diameter, or must have an internal spline. View more Rigid Shaft Coupling
August 2023
1
Marketplace 3010-01-441-6323
Request a Quotation from participating marketplace vendors
Related Documents 3010-01-441-6323 1+ Documents (More...)
... 12448907 COUPLING,SHAFT,RIGID 6 EA NS Request Quotation Subscribe to View Vendor Details...
RCSK14638 COUPLING,SHAFT,RIGID 5 EA NS Request Quotation FedMall Updated Every 15 Minutes 3010-01-441
Restrictions 3010-01-441-6323
3010-01-441-6323 is a Rigid Shaft Coupling that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 3010-01-441-6323
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3010-01-441-6323
- US Army (A920)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZ
Approved Sources 3010-01-441-6323
- Part Number
- Manufacturer
- Status
- 12448907
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- RCSK14638
- 34623 - Am General Llc (Active)
- Secondary Buy
- Secondary Buy
Datasheet 3010-01-441-6323
- Characteristic
- Specifications
- FIIG
- Specifications
- A522C0
- End Item Identification [AGAV]
- 2320-01-383-3850
- Bore Diameter [ABXV]
- 1.2520 Inches Nominal Through Bore
- Bore Length [ADGE]
- 3.0000 Inches Nominal Through Bore
- Bore Shape [AGZD]
- Straight Through Bore
- Features Provided [CBBL]
- Keyway
- Body Material [CQRG]
- Steel
- Material Document And Classification [MDCL]
- Astm-A576 Assn Std 1St Material Response Or Astm-A108 Assn Std 2Nd Material Response
- Overall Diameter [ADAV]
- 2.000 Inches Nominal
- Overall Length [ABHP]
- 3.000 Inches Nominal
- Special Features [FEAT]
- Keyway 0.314 In. Wd X 0.143 In Dp, 2 Drilled Holes 0.327 In. Dia Located 90 Degrees From Keyway And 0.500 In. From End, Heat Treat Per Rockwell C 30-36, Finish Zinc Plated Astm B633, Weapons System Truck 2 1/1 Ton, 6X6
- Style Designator [STYL]
- Plain Sleeve
Weapon Systems (WSDC) 3010-01-441-6323
DLA Procurement Analysis 3010-01-441-6323
- Last Stock Position:
- 2 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 3010-01-441-6323
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Similar Supply Items to 3010-01-441-6323
Freight Information 3010-01-441-6323
3010-01-441-6323 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 126880. A Sub NMFC of Z. It has a NMFC Description of POWER TRANS SHAFTING PULLEYS. 3010-01-441-6323 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 64300 which rates the freight between FCL and LCL. 3010-01-441-6323 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 3010-01-441-6323 is not classified as a special type of cargo when transported by water. 3010-01-441-6323 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3010-01-441-6323
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- --
- --
- --
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Contracting Technical Data File (CTDF) 3010-01-441-6323 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- Z
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
