3010-00-111-3273
Flexible Shaft Coupling
3010001113273 001113273 25LYA3002
A device for connecting the ends of two shafts so that rotary motion of one shaft is transmitted to the other shaft. It is constructed to allow for slight misalignment of shafts both linear and angular. View more Flexible Shaft Coupling
May 2023
9
Marketplace 3010-00-111-3273
Request a Quotation from participating marketplace vendors
Related Documents 3010-00-111-3273 5+ Documents (More...)
3010-00-111-3273 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-30/fsc-3010/us 3010-00-111-3273
Flexible Shaft Coupling 3010001113273 Photo 1/2 3010-00-111-3273 Photo 2/2 - - 1.
Restrictions 3010-00-111-3273
3010-00-111-3273 is a Flexible Shaft Coupling that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 3010-00-111-3273
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 3010-00-111-3273
- US Navy (N9BC)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- HD
- Brazil (YA01)
- Effective Date:
- 1 Dec 1999
- Spain (YB01)
- Effective Date:
- 1 May 1997
- Malaysia (YW01)
- Effective Date:
- 1 Oct 2006
Approved Sources 3010-00-111-3273
- Part Number
- Manufacturer
- Status
- 25LYA3002
- Manufacturer
- 10613 - Pentair Pump Group, Inc. (Active)
- Primary Buy
- Primary Buy
- 25LYA3002
- 82796 - Coltec Industries Inc. (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 3010-00-111-3273
- Characteristic
- Specifications
- FIIG
- Specifications
- A522B0
- Bore Length [ADGE]
- 1.8750 Inches Nominal Both Ends
- Bore Shape [AGZD]
- Tapered Both Ends
- Features Provided [CBBL]
- Keyway And Gear Flex
- Design Type [APGF]
- Internal Gear
- Outside Diameter [ABKV]
- 3.750 Inches Nominal
- Keyway Depth [ABRV]
- 0.7188 Inches Minimum Both Ends And 1.0000 Inches Maximum Both Ends
- Keyway Width [ABRR]
- 0.375 Inches Nominal Both Ends
- Keying Facility Quantity [BSGH]
- 1 Both Ends
- Keying Facility Type [BSGK]
- Keyway Both Ends
- Securing Method [BSNP]
- Key Both Ends
- Overall Length [ABHP]
- 5.000 Inches Nominal
- Taper Minor Diameter [ABQA]
- 1.4375 Inches Nominal Both Ends
- Taper Largest Diameter [CFGD]
- 1.6250 Inches Nominal Both Ends
Weapon Systems (WSDC) 3010-00-111-3273
DLA Procurement Analysis 3010-00-111-3273
Management Data 3010-00-111-3273
Navy
- Cognizance:
- 3B
Similar Supply Items to 3010-00-111-3273
Freight Information 3010-00-111-3273
3010-00-111-3273 has freight characteristics managed by the Food and Drug Administration (FDA).It has a National Motor Freight Classification (NMFC) of 126880. A Sub NMFC of Z. It has a NMFC Description of POWER TRANS SHAFTING PULLEYS. 3010-00-111-3273 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 64300 which rates the freight between FCL and LCL. 3010-00-111-3273 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 3010-00-111-3273 is not classified as a special type of cargo when transported by water. 3010-00-111-3273 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 3010-00-111-3273
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- MIL-PRF-21260, Preservative and Break-in Lubricating Oil, Internal Combustion Engine, Grade 10, 30 or 50
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Weather-Resistant, Corrugated Fiberboard Box
Contracting Technical Data File (CTDF) 3010-00-111-3273 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- Z
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
