2990-00-199-2304
Exhaust Muffler
2990001992304 001992304 31723BXW
INC: 10849 Exhaust Muffler
May 2023
8
Marketplace 2990-00-199-2304
Request a Quotation from participating marketplace vendors
Related Documents 2990-00-199-2304 5+ Documents (More...)
BUY NE FedMall Updated Every Day 2990-00-199-2304 RQST NE Updated Every Day 2990-00-199-2304 RQST
Updated Every Day 2990-00-199-2304 RQST NE Related Documents 2990-00-199-2304 2+ Documents ( More...
12-199-2304 5965-15-199-2304 1+ Documents ( More https//www.nsnlookup.com /fsg-29/fsc-2990/us 2990-00-199-2304
Exhaust Muffler 2990001992304 001992304 United States (US) 4. 2990-00-199-2304 Marketplace Restrictions
Exhaust Muffler 2990001992304 001992304 00-199-2304 RQST Updated Every Day 2990-00-199-2304 RQST
Restrictions 2990-00-199-2304
2990-00-199-2304 is a Exhaust Muffler that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 2990-00-199-2304
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2990-00-199-2304
- US Navy (N9BC)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- HD
Approved Sources 2990-00-199-2304
- Part Number
- Manufacturer
- Status
- 31723BXW
- Manufacturer
- 75Q65 - Oshkosh Defense Llc (Active)
- Primary Buy
- Primary Buy
- 31723BXW
- 45152 - Oshkosh Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 2990-00-199-2304
- Characteristic
- Specifications
- FIIG
- Specifications
- T135-C
- Body Shape [ARNG]
- Round
- Coolant Type [ARNA]
- Air
- Design Type [APGF]
- Dry
- Material [MATT]
- Steel
- Muffler Design [ARND]
- Straight Through
- Operating Position [ARNH]
- Any Acceptable
- Outlet Connection Type [ARTH]
- Unthreaded
- Outlet Inside Diameter [AJLW]
- 2.500 Inches Nominal
- Outlet Location [ARTJ]
- Centrally Located In End Section Of Body
- Outlet Outside Diameter [ARWA]
- 2.625 Inches Nominal
- Outlet Projection Length [ARTK]
- 2.500 Inches Nominal
- Inlet Connection Type [ACQW]
- Unthreaded
- Inlet Inside Diameter [ARTE]
- 2.500 Inches Nominal
- Inlet Location [ARNJ]
- Centrally Located In End Section Of Body
- Inlet Outside Diameter [ARSQ]
- 2.625 Inches Nominal
- Inlet Projection Length [ARNK]
- 2.500 Inches Nominal
- Special Features [FEAT]
- 1 U-Shape Bracket And 1 L-Shape Bracket Welded To Periphery,Located 5.500 In. From Inlet And Outlet End To Center Of Brackets
- Overall Diameter [ADAV]
- 6.000 Inches Nominal
- Overall Length [ABHP]
- 25.000 Inches Nominal
- Surface Treatment [SFTT]
- Paint
DLA Procurement Analysis 2990-00-199-2304
Management Data 2990-00-199-2304
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 2990-00-199-2304
Freight Information 2990-00-199-2304
2990-00-199-2304 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 125850. A Sub NMFC of Z. It has a NMFC Description of MUFFLER/EXHAUST SYS/PIPE/ETC. 2990-00-199-2304 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 61440 which rates the freight between FCL and LCL. 2990-00-199-2304 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 2990-00-199-2304 is not classified as a special type of cargo when transported by water. 2990-00-199-2304 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 2990-00-199-2304
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- MIL-PRF-21260, Engine Oil, Type I, Grades 10, 30 or 50
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 25.0" H x 6.0" W x 6.0" L
- --
- --
- Physical Protection
- Any Suitable Process
- 25.0" H x 6.0" W x 6.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- ASTM-D5118, Type CF, Class Domestic, Corrugated Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Contracting Technical Data File (CTDF) 2990-00-199-2304 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
