2940-01-157-8873

Oil Filter Adapter

2940011578873 011578873 5104771

INC: 77777

2940-01-157-8873 ADAPTER,OIL FILTER 2940011578873 011578873

Managed by United States
NSN Created on 13 Jul 1983
Data Last Changed
July 2025
NATO Update Count
7
NATO Data Quality
2940-01-157-8873 ADAPTER,OIL FILTER 2940011578873 011578873 1/3
2940-01-157-8873 Photo 1/3
2940-01-157-8873 ADAPTER,OIL FILTER 2940011578873 011578873 2/3
2940-01-157-8873 Photo 2/3
2940-01-157-8873 ADAPTER,OIL FILTER 2940011578873 011578873 3/3
2940-01-157-8873 Photo 3/3

2940-01-157-8873 Product Information Product Information 2940-01-157-8873

Remote Oil FIlter Adaptor

Used on Detroit Diesel 6V53 Engines.

Applicable Engine Models:

  • 5063-5292
  • 5063-5293
  • 5063-529L

This adaptor provides a Female NPT (National Pipe Thread) threaded connection for a hose going from the engine to the inlet of the remote oil filter and a Female NPT for connection of a hose from the outlet of the remote oil filter returning oil to the engine. Provision is made for a simple sprung-loaded non-metallic disc filter bypass valve which operates when the differential pressure across the oil filter is elevated (when the oil filter is clogged or a hose is restricted). This emergency bypass valve prevents a remote oil filter failure from starving the engine of lubricating oil. The valve components are sold separately and must be fitted for correct operation.

Common Failure - Hose Thread Splitting/Cracking

The most common failure of this part is over-tightening of the hose connection threads into this adaptor. The adaptor is made of cast aluminum and the boss containing each female thread is very much weaker than the forces generated by tightening the tapered pipe thread for the hose connections. This causes the boss to fracture leaving a crack across the thread which can be easily un-noticeable to a mechanic. When the engine is started, oil immediately streams out of the crack in a high volume high pressure oil leak. The design and material of this adaptor do not allow a sufficient repair to be made and so this part must be replaced if cracked.

NSN Lookup CAGE 99V35 has developed an upgraded remote oil filter adaptor for 6V53 engines. The upgraded part is CNC machined from steel billet and is a direct fit replacement. The precision threads in the hardened alloy steel for the hose connections have a higher strength than the hose fittings and so fracturing of the adaptor has been eliminated. This upgrade typically saves an end user $1000s in repairs over the life of the vehicle. The upgraded adaptor is part number NLK-5104771 from CAGE 99V35.

Upgraded Adaptor

Click here to purchase NLK-5104771

2940-01-157-8873 Stock and Availability Marketplace 2940-01-157-8873

Need Help?
Request a Quotation from participating marketplace vendors
eBay Updated Every Day
2940-01-157-8873 RQST NE eBay
eBay Updated Every Day
2940-01-157-8873 RQST eBay
Amazon Updated Every Day
2940-01-157-8873 RQST NE Amazon

2940-01-157-8873 Related Documents Related Documents 2940-01-157-8873 1+ Documents (More...)

Count 7 NATO Data Quality 2940-01-157-8873 Photo 1/3 2940-01-157-8873 Photo 2/3 2940-01-157-8873 Photo
Upgraded Adaptor Click here to purchase NLK-5104771 Marketplace 2940-01-157-8873 Need Help?
RQST NE Updated Every Day 2940-01-157-8873 RQST Updated Every Day 2940-01-157-8873 RQST NE Related

2940-01-157-8873 Demil Restrictions 2940-01-157-8873

DEMIL: A | DEMILI: 1 | CRITICALITY: | HMIC: N | PMIC: A | EDC: | ADPEC:

2940-01-157-8873 is a Oil Filter Adapter Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.

2940-01-157-8873 End Users End Users 2940-01-157-8873

US Army (A920)
Effective Date:
1 Sep 2005
Former MOE Rule:
A181
Supplementary Receivers:
AZ
US Marine Corps (MC40)
Effective Date:
1 Sep 2005
Former MOE Rule:
MC01
US Navy (N9BC)
Effective Date:
1 Dec 2013
Supplementary Collaborators:
GG
Australia (ZA01)
Effective Date:
1 Apr 1991
Canada (ZC01)
Effective Date:
1 Apr 1991
Turkey (ZW01)
Effective Date:
1 Oct 2001

2940-01-157-8873 Stock, Inventory and Procurement DLA Procurement Analysis 2940-01-157-8873

Last Stock Position:
1 In Stock
DLA Administrative Lead Time:
Subscribe
DLA Production Lead Time:
Subscribe
Subscribe to View DLA Inventory and Forecast...

2940-01-157-8873 Management Data Management Data 2940-01-157-8873

Effective Date
Organization
Unit of Issue
Unit Price
Qty Unit Pack
Oct 2022
Department of the Army (DA)
EA
Subscribe
1
Oct 2021
Defense Logistics Agency (DS)
EA
Subscribe
1
Oct 2020
Defense Logistics Agency (DS)
EA
Subscribe
1
Oct 2019
Department of the Army (DA)
EA
Subscribe
1

Army Army

Materiel Category and Inventory Manager:
J
Ground Forces Support Materiel (DLA/GSA Items)
Appropriation and Budget Activity:
2
Stock Fund Secondary Items
Management Inventory Segment:
2
Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
Weapons System / End Item / Homogeneous Group:
00
DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
Accounting Requirements:
X
Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Navy Navy

Cognizance:
9B
Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Marine Corps Marine Corps

Stores Account:
1
Stock Fund Account Item
Combat Essentiality:
5
Critical Repair Part to a Combat Essential End Item
Echelon Management:
B2
Operational Test:
No Special Procedures

2940-01-157-8873 Similar Items Similar Supply Items to 2940-01-157-8873

2940-01-157-8873 Freight Data Freight Information 2940-01-157-8873

2940-01-157-8873 has freight characteristics.. 2940-01-157-8873 has a variance between NMFC and UFC when transported by rail and the description should be consulted.

2940-01-157-8873 Packaging Data Packaging Data 2940-01-157-8873

Responsible Activity
Packaging Data Source
Primary Inventory Control Activity (PICA)
--

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation
--
--
Bare Metal Item
Over 10lb
Less than 85G
No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying
1
--
--
--
Physical Protection
Any Suitable Process
Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking
No Requirement
No Requirement
--
--
PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container
Any Suitable Fiber Box

2940-01-157-8873 Procurement History Procurement History 2940-01-157-8873 16 Records

Contract
Date
CAGE
Quantity
Net Price
Std Price
SPE7L123F9363
19 Jul 2023
Subscribe
7
Subscribe
Subscribe
SPE7L123F9363
19 Jul 2023
Subscribe
7
Subscribe
Subscribe
SPE7L123F7704
23 May 2023
Subscribe
10
Subscribe
Subscribe
SPE7L123F7704
23 May 2023
Subscribe
10
Subscribe
Subscribe
SPE7LX23F662U
16 Feb 2023
Subscribe
3
Subscribe
Subscribe
SPE7LX23F662U
16 Feb 2023
Subscribe
3
Subscribe
Subscribe
SPE7LX22F00E4
24 Mar 2022
Subscribe
2
Subscribe
Subscribe
SPE7LX22F00F6
24 Mar 2022
Subscribe
8
Subscribe
Subscribe
SPE7LX22F00J9
24 Mar 2022
Subscribe
1
Subscribe
Subscribe
SPE7LX22F00E4
24 Mar 2022
Subscribe
2
Subscribe
Subscribe
SPE7LX22F00F6
24 Mar 2022
Subscribe
8
Subscribe
Subscribe
SPE7LX22F00J9
24 Mar 2022
Subscribe
1
Subscribe
Subscribe
SPE7L121F154K
28 Jan 2021
Subscribe
8
Subscribe
Subscribe
SPE7L121F154K
28 Jan 2021
Subscribe
8
Subscribe
Subscribe
SPE7M118FB23J
21 Aug 2018
Subscribe
4
Subscribe
Subscribe
SPE7LX15D00651310
22 Mar 2016
Subscribe
17
Subscribe
Subscribe

2940-01-157-8873 Contracting Technical Data File (CTDF) Contracting Technical Data File (CTDF) 2940-01-157-8873 October 2021

Criticality and Quality

Critical Item Code:
X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):
F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:
N
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:
