2940-01-069-9238
Fluid Filter
2940010699238 010699238 M3638 11669410
A filter having inlet and outlet connections and designed to be connected in a pipe, tube or hose line. For spin-on, base-mounted filtering devices with integral outer casings, see FILTER ELEMENT, FLUID. Excludes AIR CONDITIONER. View more Fluid Filter
Managed by United States
NSN Created on 29 Dec 1978
Data Last Changed
November 2023
November 2023
NATO Update Count
31
31
NATO Data Quality
Marketplace 2940-01-069-9238
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 2940-01-069-9238 5+ Documents (More...)
M3638 11669410 A filter having inlet and outlet connections and designed to be connected in a pipe,
Vendor Details... 2940-01-069-9238 FILTER,FLUID 5 EA NS Request Quotation Updated Every Day 2940-01-
069-9238 RQST NE Updated Every Day 2940-01-069-9238 RQST Updated Every Day 2940-01-069-9238 RQST NE Related
Vendor Details... 2940-01-069-9238 FILTER,FLUID 5 EA NS Request Quotation Updated Every Day 2940-01-
069-9238 RQST NE Updated Every Day 2940-01-069-9238 RQST Updated Every Day 2940-01-069-9238 RQST NE Related
https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930-00-064-2867 Toggle Switch 5930000642867000642867,M3638
https//www.nsnlookup.com /fsg-29/fsc-2940/us 2940-01-069-9238 Fluid Filter 2940010699238 010699238,M3638
Upgrade for $1 a day Upgrade your Account Upgrade 2940-01-069-9238Fluid Filter2940010699238 010699238
https//www.nsnlookup.com /fsg-29/fsc-2940/us 2940-01-069-9238 Fluid Filter 2940010699238 010699238,M3638
Upgrade for $1 a day Upgrade your Account Upgrade 2940-01-069-9238Fluid Filter2940010699238 010699238
JavaScript in your web browser . 5995-25-132-9681Radio Frequency Cable Assembly5995251329681 251329681 M3638
Cable Assembly5995251329681 251329681M3638-2181195995 M3638 218119 in your web browser . 5995-25-132
/www.nsnlookup.com /fsg-53/fsc-5315/us 5315-01-182-7504 Machine Key 5315011827504 011827504,218119 M3638
Cable Assembly5995251329681 251329681M3638-2181195995 M3638 218119 in your web browser . 5995-25-132
/www.nsnlookup.com /fsg-53/fsc-5315/us 5315-01-182-7504 Machine Key 5315011827504 011827504,218119 M3638
218119 in your web browser . 5995-25-132-9681Radio Frequency Cable Assembly5995251329681 251329681 M3638
5995251329681 in your web browser . 5995-25-132-9681Radio Frequency Cable Assembly5995251329681 251329681 M3638
-218119 Assembly5995251329681 251329681 M3638 Cable Assembly5995251329681 251329681M3638-2181195995 M3638
5995251329681 in your web browser . 5995-25-132-9681Radio Frequency Cable Assembly5995251329681 251329681 M3638
-218119 Assembly5995251329681 251329681 M3638 Cable Assembly5995251329681 251329681M3638-2181195995 M3638
218119 in your web browser . 5995-25-132-9681Radio Frequency Cable Assembly5995251329681 251329681 M3638
5995251329681 in your web browser . 5995-25-132-9681Radio Frequency Cable Assembly5995251329681 251329681 M3638
https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930-00-064-2867 Toggle Switch 5930000642867 000642867,M3638
5995251329681 in your web browser . 5995-25-132-9681Radio Frequency Cable Assembly5995251329681 251329681 M3638
https//www.nsnlookup.com /fsg-59/fsc-5930/us 5930-00-064-2867 Toggle Switch 5930000642867 000642867,M3638
Restrictions 2940-01-069-9238
2940-01-069-9238 is a Fluid Filter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 2940-01-069-9238
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2940-01-069-9238
- US Army (A920)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZ
- US Navy (N9BC)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Lithuania (WI01)
- Effective Date:
- 1 May 2001
- Spain (YB01)
- Effective Date:
- 1 Feb 1994
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Kuwait (YK01)
- Effective Date:
- 1 Feb 2015
- Australia (ZA01)
- Effective Date:
- 1 Jul 2002
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Jun 2006
- Turkey (ZW01)
- Effective Date:
- 1 Oct 2001
Approved Sources 2940-01-069-9238
- Part Number
- Manufacturer
- Status
- 11669410
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Source Control
- Source Control
- M3638
- 92863 - Marvel Engineering Company Inc (Active)
- Primary Buy
- Primary Buy
- 11669410
- T0720 - Fnss Savunma Sistemleri Anonim (Active)
- NATO Reproduction
- NATO Reproduction
Datasheet 2940-01-069-9238
- Characteristic
- Specifications
- FIIG
- Specifications
- A24000
- Distance From Bottom Of Body To Center Of Inlet [CSKY]
- 6.344 Inches Nominal
- Body Height [ADAU]
- 7.625 Inches Nominal
- Body Length [ADAQ]
- 3.812 Inches Nominal
- Design Type [APGF]
- Reusable
- Filtering Element Quantity [CCZM]
- 1
- Filtering System For Which Designed [CXZX]
- Full Flow
- First Discharge Connection Relationship To Intake Connection [CSJR]
- Identical To First Intake Connection
- First Intake Connection Type [CRXZ]
- Threaded Internal Pipe Side Near Top
- First Intake Nominal Thread Size [CTGK]
- 1.000 Inches
- First Intake Thread Direction [CXPF]
- Right-Hand
- First Intake Thread Series Designator [CTDY]
- Nptf
- Material [MATT]
- Aluminum Body
- Maximum Operating Pressure [CQGM]
- 185.0 Pounds Per Square Inch
- Mounting Facility Nominal Thread Size [CSJC]
- 0.375 Inches
- Mounting Facility Thread Series Designator [CDTD]
- Nptf
- Mounting Type [AAXX]
- Threaded Stud Bottom
- Style Designator [STYL]
- Diverted Flow Basket Strainer W/Bolted Cover
- Temp Rating [AZKQ]
- -40.0 Deg Fahrenheit Minimum And 300.0 Deg Fahrenheit Maximum
Weapon Systems (WSDC) 2940-01-069-9238
DLA Procurement Analysis 2940-01-069-9238
- Last Stock Position:
- 325 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 2940-01-069-9238
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 2940-01-069-9238
4330-99-852-0735 2910-12-367-3651 4330-25-150-9110 2940-98-204-5651 4330-12-377-4992 6515-12-381-7567 4330-12-381-0125 2910-13-119-5435 4330-99-709-1442 4330-99-612-6237 4330-12-360-4953 2910-22-619-5095 4330-17-115-4952 2910-12-368-6759 4310-98-855-0816 4130-12-366-6736 4330-12-343-9896 1650-99-841-9689
Freight Information 2940-01-069-9238
2940-01-069-9238 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 069100. A Sub NMFC of F. It has a NMFC Description of FILTERS:FILTERS,NOI SUB6. 2940-01-069-9238 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. 2940-01-069-9238 is rated as class 100 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 21275 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 581 for ocean manifesting and military sealift. 2940-01-069-9238 is not classified as a special type of cargo when transported by water. 2940-01-069-9238 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 2940-01-069-9238
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 8.0" H x 4.0" W x 4.0" L
- --
- --
- --
- Any Suitable Process
- 8.0" H x 4.0" W x 4.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Procurement History 2940-01-069-9238 7 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE7L317P0834
- 03 Nov 2016
- Subscribe
- 362
- Subscribe
- Subscribe
- Subscribe
- SPE7L316C0046
- 08 Jun 2016
- Subscribe
- 1750
- Subscribe
- Subscribe
- Subscribe
- SPE7L316M3169
- 09 Feb 2016
- Subscribe
- 370
- Subscribe
- Subscribe
- Subscribe
- SPE7L315M9141
- 29 Sep 2015
- Subscribe
- 50
- Subscribe
- Subscribe
- Subscribe
- SPE7L314M8806
- 20 Aug 2014
- Subscribe
- 9
- Subscribe
- Subscribe
- Subscribe
- SPE7L314V8028P00001
- 21 Jul 2014
- Subscribe
- 40
- Subscribe
- Subscribe
- Subscribe
- SPE7L314V6481
- 30 May 2014
- Subscribe
- 30
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 2940-01-069-9238 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
