2940-00-886-5836
Intake Air Cleaner Filter Element
2940008865836 008865836 5129604 5117596 PC5129604 2815008865836
A replaceable device designed to remove dust, pollen or other foreign matter from the air passing through it. The removal of particles is accomplished by porous material (metallic or non-metallic), wire mesh, or the like. It is designed to fit into an AIR CLEANER,INTAKE. View more Intake Air Cleaner Filter Element
Managed by United States
NSN Created on 1 Jan 1962
Data Last Changed
August 2025
August 2025
NATO Update Count
51
51
NATO Data Quality
Marketplace 2940-00-886-5836
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 2940-00-886-5836 5+ Documents (More...)
5129604 5117596 PC5129604 2815008865836 A replaceable device designed to remove dust, pollen or other
RQST NE Updated Every Day 2940-00-886-5836 RQST NE Updated Every Day 2940-00-886-5836 RQST Updated Every
Day 2940-00-886-5836 RQST NE Related Documents 2940-00-886-5836 2+ Documents ( More... ) https//www.nsnlookup.com
RQST NE Updated Every Day 2940-00-886-5836 RQST NE Updated Every Day 2940-00-886-5836 RQST Updated Every
Day 2940-00-886-5836 RQST NE Related Documents 2940-00-886-5836 2+ Documents ( More... ) https//www.nsnlookup.com
424-6158 2940-00-244-1319 2940-01-315-5519 2940-00-313-1194 2940-01-291-5893 2940-00-968-1794 2940-00-886-5836
424-6158 2940-00-244-1319 2940-01-315-5519 2940-00-313-1194 2940-01-291-5893 2940-00-968-1794 2940-00-886-5836
424-6158 2940-00-244-1319 2940-01-315-5519 2940-00-313-1194 2940-01-291-5893 2940-00-968-1794 2940-00-886-5836
118-4300 2940-01-424-6158 2940-00-244-1319 2940-01-315-5519 2940-00-313-1194 2940-00-968-1794 2940-00-886-5836
Restrictions 2940-00-886-5836
2940-00-886-5836 is a Intake Air Cleaner Filter Element that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 2940-00-886-5836
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2940-00-886-5836
- US Army (A920)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- A181
- Supplementary Receivers:
- BD
- US Air Force (FUGC)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- FUAX
- US Marine Corps (MC40)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- MC01
- US Navy (N9BC)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GTJNHD
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Brazil (YA01)
- Effective Date:
- 1 Dec 2001
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Israel (YD01)
- Effective Date:
- 1 Jul 2016
- Kuwait (YK01)
- Effective Date:
- 1 Feb 2015
- Morocco (YP01)
- Effective Date:
- 1 Jun 2016
- Malaysia (YW01)
- Effective Date:
- 1 Apr 1991
- Thailand (YY01)
- Effective Date:
- 1 Feb 2015
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 May 2002
- Germany (ZG01)
- Effective Date:
- 1 Feb 2005
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Nov 1997
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 2940-00-886-5836
- Part Number
- Manufacturer
- Status
- 5129604
- Manufacturer
- 72582 - Rolls-Royce Solutions America Inc (Active)
- Primary Buy
- Primary Buy
- 5129604
- 73342 - Allison Transmission Inc (Active)
- Secondary Buy
- Secondary Buy
- 5117596
- 72582 - Rolls-Royce Solutions America Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- PC5129604
- C7432 - Power Components (Deutschland) Gmbh (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 5129604
- 24617 - General Motors Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 2815008865836
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
Datasheet 2940-00-886-5836
- Characteristic
- Specifications
- FIIG
- Specifications
- A24000
- Style Designator [STYL]
- Cylindrical W/Out Container
- Body Diameter [ABPM]
- 3.375 Inches Nominal
- Body Inside Diameter [ADAS]
- 0.500 Inches Nominal
- Body Overall Length [AZTL]
- 3.250 Inches Nominal
- Material [MATT]
- Steel Corrosion Resisting Filtering Medium
- Filtering Media Design [CRXW]
- Matted Single Filtering Media Response
- Design Type [APGF]
- Reusable
- Special Features [FEAT]
- Used On Diesel Engine Oil Venting System
Weapon Systems (WSDC) 2940-00-886-5836
DLA Procurement Analysis 2940-00-886-5836
- Last Stock Position:
- 37 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 2940-00-886-5836
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Mar 2023
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2022
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- F
- X
- Formerly 2815
- X
- Department of the Navy (DN)
- N
- X
- Formerly 2815
- X
- Defense Logistics Agency (DS)
- I
- X
- Formerly 2815
- X
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- T
- Maintenance Float Secondary Non-depot Reparables
- Operational Test:
- No Special Procedures
Similar Supply Items to 2940-00-886-5836
Freight Information 2940-00-886-5836
2940-00-886-5836 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 069100. A Sub NMFC of Z. It has a NMFC Description of FILTERS:CARTRIDGES/ELEMENTS. 2940-00-886-5836 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 21275 which rates the freight between FCL and LCL. 2940-00-886-5836 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 2940-00-886-5836 is not classified as a special type of cargo when transported by water. 2940-00-886-5836 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 2940-00-886-5836
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- --
- --
- Vendor's Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Procurement History 2940-00-886-5836 2 Records
Contracting Technical Data File (CTDF) 2940-00-886-5836 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- T
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
