2940-00-831-6945
Fluid M113 Filter
2940008316945 008316945 10861684 M2080A M2080 1041 2940PL0885068 2520008316945
A filter having inlet and outlet connections and designed to be connected in a pipe, tube or hose line. For spin-on, base-mounted filtering devices with integral outer casings, see FILTER ELEMENT, FLUID. Excludes AIR CONDITIONER. View more Fluid Filter
Managed by United States
NSN Created on 1 Jan 1962
Data Last Changed
March 2025
March 2025
NATO Update Count
40
40
NATO Data Quality
Product Information 2940-00-831-6945
Fluid Filter Assembly
Includes Filter Element Kit 4330-00-767-3153
Used on vehicles:
- M113
- M113A1
- M113A2
Marketplace 2940-00-831-6945
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Updated Every Day 2940-00-831-6945 RQST NE
Updated Every Day 2940-00-831-6945 RQST
Updated Every Day 2940-00-831-6945 RQST NE
Related Documents 2940-00-831-6945 5+ Documents (More...)
10861684 M2080A M2080 1041 2940PL0885068 2520008316945 A filter having inlet and outlet connections
1041 FILTER 3 EA NS Request Quotation 10861684 FILTER 19 EA NS Request Quotation Subscribe to View Vendor
Details... 1041 FILTER,FLUID M113 6 EA NS Request Quotation Subscribe to View Vendor Details... 2940
1041 FILTER 3 EA NS Request Quotation 10861684 FILTER 19 EA NS Request Quotation Subscribe to View Vendor
Details... 1041 FILTER,FLUID M113 6 EA NS Request Quotation Subscribe to View Vendor Details... 2940
10861684 M2080A M2080 1041 2940PL0885068 2520008316945 A filter having inlet and outlet connections
M2080 FILTER,FLUID 71 EA NS Request Quotation 1041 FILTER,FLUID 1 EA NS Request Quotation Subscribe to
Request Quotation Subscribe to View Vendor Details... 10861684 FILTER 1 EA NS Request Quotation 1041
M2080 FILTER,FLUID 71 EA NS Request Quotation 1041 FILTER,FLUID 1 EA NS Request Quotation Subscribe to
Request Quotation Subscribe to View Vendor Details... 10861684 FILTER 1 EA NS Request Quotation 1041
$1 a day Upgrade your Account Upgrade 5365-00-270-7859Machine Thread Plug5365002707859 002707859 M2080A
www.nsnlookup.com /fsg-53/fsc-5365/us 5365-00-270-7859 Machine Thread Plug 5365002707859002707859 M2080A
Documents 5365-00-270-7859 2+ Documents ( More... https//www.nsnlookup.com /fsg-29/fsc-2940/us 2940-00-831-6945
www.nsnlookup.com /fsg-53/fsc-5365/us 5365-00-270-7859 Machine Thread Plug 5365002707859002707859 M2080A
Documents 5365-00-270-7859 2+ Documents ( More... https//www.nsnlookup.com /fsg-29/fsc-2940/us 2940-00-831-6945
$1 a day Upgrade your Account Upgrade 4330-00-833-0890Fluid Filter Element4330008330890 008330890 M2080
www.nsnlookup.com /fsg-43/fsc-4330/us 4330-00-833-0890 Fluid Filter Element 4330008330890008330890 M2080
Day 4330-00-833-0890 RQST NE Related Documents https//www.nsnlookup.com /fsg-29/fsc-2940/us 2940-00-831-6945
www.nsnlookup.com /fsg-43/fsc-4330/us 4330-00-833-0890 Fluid Filter Element 4330008330890008330890 M2080
Day 4330-00-833-0890 RQST NE Related Documents https//www.nsnlookup.com /fsg-29/fsc-2940/us 2940-00-831-6945
a day Upgrade your Account Upgrade 8135-01-386-2322Plastic Film Wrap8135013862322 013862322 WMF86 M2080
(Active) Primary Buy RNCC 3 RNVC 2 DAC 4 M2080 20" X 6000 98744 - Cantwell-Cleary Co., Inc.
(Active) Primary Buy RNCC 3 RNVC 2 DAC 4 M2080 20" X 6000 98744 - Cantwell-Cleary Co., Inc.
Restrictions 2940-00-831-6945
2940-00-831-6945 is a Fluid M113 Filter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 2940-00-831-6945
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2940-00-831-6945
- US Army (A920)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZBD
- US Air Force (FUGC)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- FUAX
- Lithuania (WI01)
- Effective Date:
- 1 May 2001
- Poland (WP01)
- Effective Date:
- 1 Jul 2013
- Brazil (YA01)
- Effective Date:
- 1 Dec 2001
- Spain (YB01)
- Effective Date:
- 1 May 1997
- Israel (YD01)
- Effective Date:
- 1 Jul 2016
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Morocco (YP01)
- Effective Date:
- 1 Sep 2010
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 2006
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 2940-00-831-6945
- Part Number
- Manufacturer
- Status
- 10861684
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Source Control
- Source Control
- M2080A
- 92863 - Marvel Engineering Company Inc (Active)
- Primary Buy
- Primary Buy
- M2080
- 92863 - Marvel Engineering Company Inc (Active)
- Secondary Buy
- Secondary Buy
- 2520008316945
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 1041
- 18170 - Dollinger Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 2940PL0885068
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
- 2520008316945
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
- 1041
- T0720 - Fnss Savunma Sistemleri Anonim (Active)
- NATO Reproduction
- NATO Reproduction
Datasheet 2940-00-831-6945
- Characteristic
- Specifications
- FIIG
- Specifications
- A24000
- Distance From Bottom Of Body To Center Of Inlet [CSKY]
- 6.969 Inches Nominal
- Body Height [ADAU]
- 8.313 Inches Nominal
- Body Length [ADAQ]
- 4.625 Inches Nominal
- Bracket Quantity [CBQD]
- 1
- Design Type [APGF]
- Reusable
- Distance Between Mounting Hole Centers [AFQM]
- 2.250 Inches Nominal
- Filtering Element Quantity [CCZM]
- 1
- Filtering System For Which Designed [CXZX]
- Full Flow
- First Discharge Connection Relationship To Intake Connection [CSJR]
- Identical To First Intake Connection
- First Intake Connection Type [CRXZ]
- Threaded Internal Pipe Head Side
- First Intake Nominal Thread Size [CTGK]
- 1.000 Inches
- First Intake Thread Direction [CXPF]
- Right-Hand
- First Intake Thread Series Designator [CTDY]
- Nptf
- Material [MATT]
- Aluminum Body
- Maximum Operating Pressure [CQGM]
- 15.0 Pounds Per Square Inch
- Media For Which Designed [MEDA]
- Fuel/Oil, Hydrocarbon
- Mounting Hole Diameter [ABTB]
- 0.406 Inches Nominal
- Mounting Hole Quantity [ABTJ]
- 2
- Mounting Type [AAXX]
- Bracket W/Drilled Hole Upper Side
- Style Designator [STYL]
- Straight Flow Basket Strainer W/Bolted Cover
- Second Discharge Connection Relationship To Preceding Connection [CSLN]
- Not Identical
- Second Discharge Connection Type [CSPQ]
- Threaded Internal Pipe Top
- Second Discharge Nominal Thread Size [CTQF]
- 0.750 Inches
- Second Discharge Thread Direction [CXTT]
- Right-Hand
- Second Discharge Thread Series Designator [CTGB]
- Nptf
- Temp Rating [AZKQ]
- -40.0 Deg Fahrenheit Minimum And 300.0 Deg Fahrenheit Maximum
Weapon Systems (WSDC) 2940-00-831-6945
DLA Procurement Analysis 2940-00-831-6945
- Last Stock Position:
- 4 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 2940-00-831-6945
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Mar 2023
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2022
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Army (DA)
- A
- X
- Formerly 2520
- X
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- MC
- Armored Carriers
M113A1/A2 Armored Personnel Carrier, Combat Vehicle, Anti-tank
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SU
- AF SICA RESIDUAL MMAC-OO-ALC
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
NATO Stock Numbers Related to 2940-00-831-6945
4330-99-852-0735 2910-12-367-3651 4330-25-150-9110 2940-98-204-5651 4330-12-377-4992 6515-12-381-7567 4330-12-381-0125 2910-13-119-5435 4330-99-709-1442 4330-99-612-6237 4330-12-360-4953 2910-22-619-5095 4330-17-115-4952 2910-12-368-6759 4310-98-855-0816 4130-12-366-6736 4330-12-343-9896 1650-99-841-9689
Freight Information 2940-00-831-6945
2940-00-831-6945 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 069100. A Sub NMFC of Z. It has a NMFC Description of FILTERS:CARTRIDGES/ELEMENTS. 2940-00-831-6945 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 21275 which rates the freight between FCL and LCL. 2940-00-831-6945 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 2940-00-831-6945 is not classified as a special type of cargo when transported by water. 2940-00-831-6945 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 2940-00-831-6945
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Preservative Coating Only
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- MIL-PRF-121, Type II, Light Duty, Greaseproof, Waterproof Barrier
- A-A-1051, Paperboard Cushioning
- Not Applicable
- ASTM-D5118, Type CF, Class Weather-Resistant, Corrugated Fiberboard Box
- No special marking
- MIL-PRF-121, Type II, Light Duty, Greaseproof, Waterproof Barrier
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Procurement History 2940-00-831-6945 7 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE7L322P6997
- 19 Jul 2022
- Subscribe
- 15
- Subscribe
- Subscribe
- Subscribe
- SPE7L321V9850
- 01 Sep 2021
- Subscribe
- 13
- Subscribe
- Subscribe
- Subscribe
- SPE7L321P5108
- 14 Jun 2021
- Subscribe
- 26
- Subscribe
- Subscribe
- Subscribe
- SPE7L315M5126
- 16 Apr 2015
- Subscribe
- 9
- Subscribe
- Subscribe
- Subscribe
- SPE7L315V1953
- 13 Nov 2014
- Subscribe
- 20
- Subscribe
- Subscribe
- Subscribe
- SPE7L314V6218P00001
- 19 May 2014
- Subscribe
- 20
- Subscribe
- Subscribe
- Subscribe
- SPM7L213M6586
- 11 Jul 2013
- Subscribe
- 6
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 2940-00-831-6945 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- T
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
