2940-00-168-2338
Intake Air Cleaner
2940001682338 001682338 11598003 2940PL1451102
A device designed to prevent foreign particles from entering the air intake system of an internal combustion engine or air compressor. Excludes mufflers. View more Intake Air Cleaner
May 2023
39
Marketplace 2940-00-168-2338
Request a Quotation from participating marketplace vendors
Related Documents 2940-00-168-2338 3+ Documents (More...)
11598003 AIR CLEANER,INTAKE 7 EA NS Request Quotation Subscribe to View Vendor Details... 11598003 AIR
RQST NE Updated Every Day 2940-00-168-2338 RQST Updated Every Day 2940-00-168-2338 RQST NE Related
www.nsnlookup.com /fsg-29/fsc-2940/us 2940-01-496-2794 Intake Air Cleaner 2940014962794014962794 11598003
www.nsnlookup.com /fsg-29/fsc-2940/us 2940-01-496-2794 https//www.nsnlookup.com /fsg-29/fsc-2940/us 2940-00-168-2338
Intake Air Cleaner 2940001682338 001682338 https//www.nsnlookup.com /fsg-29/fsc-2940/us 2940-00
-168-2338 Intake Air Cleaner 2940001682338 001682338 Subscribe to View Vendor Details... 11598003 AIR
Restrictions 2940-00-168-2338
2940-00-168-2338 is a Intake Air Cleaner that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 2940-00-168-2338
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2940-00-168-2338
- US Army (A920)
- Effective Date:
- 1 Aug 2010
- Former MOE Rule:
- A204
- Supplementary Receivers:
- AZBD
- Lithuania (WI01)
- Effective Date:
- 1 May 2001
- Brazil (YA01)
- Effective Date:
- 1 Dec 1999
- Spain (YB01)
- Effective Date:
- 1 Feb 1994
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Kuwait (YK01)
- Effective Date:
- 1 Jan 2015
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Aug 1993
Approved Sources 2940-00-168-2338
- Part Number
- Manufacturer
- Status
- 11598003
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- 2940001682338
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
- 2940PL1451102
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
Datasheet 2940-00-168-2338
- Characteristic
- Specifications
- FIIG
- Specifications
- T135-D
- Element Replaceability [ARYD]
- Replaceable
- Air Cleaner Type [ARYC]
- Throw-Away
- Backfire Valve [ARYF]
- Not Included
- Filter Type [ALTR]
- Dry
- Mounting Outside Diameter [ADHZ]
- 5.560 Inches Nominal
- Outlet Location [ARTJ]
- Located On Side Of Cleaner
- Outlet Sleeve Type [ARZP]
- Protruding
- Outlet Type [ARZG]
- Sleeve
- Outside Diameter [ABKV]
- 12.280 Inches Nominal
- Fsc Application Data [ZZZV]
- Engine Air Cleaner
- Material [MATT]
- Laminated Plastic
- Inlet Type [ARYG]
- Sleeve
- Integral Clamp [ARZR]
- Not Included
- Pressure Relief Valve [ARYE]
- Not Included
- Quantity [NMBR]
- 1
- Remote Location Inlet Adapter [ARZW]
- Not Included
- Sleeve Connection Quantity [ARYT]
- 1
- Sleeve Length [AMCA]
- 2.510 Inches Nominal
- Sleeve Location [ARYH]
- Located On Side Of Cleaner
- Sleeve Outside Diameter [ARYW]
- 5.366 Inches Nominal
- Overall Height [ABKW]
- 21.250 Inches Nominal
- Submersibility [AHZV]
- Nonsubmersible
Weapon Systems (WSDC) 2940-00-168-2338
DLA Procurement Analysis 2940-00-168-2338
Management Data 2940-00-168-2338
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
NATO Stock Numbers Related to 2940-00-168-2338
Freight Information 2940-00-168-2338
2940-00-168-2338 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 069100. A Sub NMFC of Z. It has a NMFC Description of FILTERS:CARTRIDGES/ELEMENTS. 2940-00-168-2338 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 2940-00-168-2338 is rated as class 85 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 21275 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 2940-00-168-2338 is not classified as a special type of cargo when transported by water. 2940-00-168-2338 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Procurement History 2940-00-168-2338 1 Records
Contracting Technical Data File (CTDF) 2940-00-168-2338 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- T
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
