2940-00-073-3316

Fluid Filter Element

2940000733316 000733316 PF432 LF0051600 244523R91 998445R91 51954 P41 P428 1954 P999 CH211A S196CP LF516 149557 FL170 CH211 158139 CW954MP 1CD77 PM-343MA

A replaceable device designed to remove solid particles from fluids ranging in density from heavy liquids to gases. The removal of particles is accomplished by porous material (metallic or non-metallic), stacked disks, wound wire, or the like, constructed so the fluid can flow through the device while the solid particles are retained. It may be designed to fit into a FILTER, FLUID (or similar cavity), or it may have an integral outer casing and mounting facilities and be designed to connect directly to an engine, compressor, or the like. The degree of removal of particles must be nominally rated at less than 50 microns or absolutely rated at less than 75 microns. Excludes FILTER ELEMENT, AIR CONDITIONING. See also STRAINER ELEMENT, SEDIMENT. View more Fluid Filter Element

Managed by United States

NSN Created on 25 Jul 1967

Data Last Changed
November 2023

NATO Update Count
70

NATO Data Quality

STYL Style A10 for 2940-00-073-3316 1/1 — NSN 2940-00-073-3316 (Identification) 1/1

Marketplace 2940-00-073-3316

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

1954 FILTER ELEMENT,FLUID 1 EA NS

Subscribe to View Vendor Details...

2940-00-073-3316 FILTER ELEMENT,FLUID 78 EA NS

Subscribe to View Vendor Details...

195-4 FILTER ELEMENT,FLUID 10 EA NS

P428 FILTER ELEMENT,FLUID 234 EA NS

1954 FILTER ELEMENT,FLUID 1 EA NS

5195-4 FILTER ELEMENT,FLUID RQST NS

Subscribe to View Vendor Details...

CH211A FILTER 13 EA NS

1CD77 FILTER 19 EA NS

158139 FILTER 7 EA NS

158139 FILTER ELEMENT 52 EA NS

PM-343MA FILTER 12 EA NS

1954 FILTER 6 EA NS

LF516 FILTER ELEMENT 2 EA NS

51954 FILTER 1 EA NS

Subscribe to View Vendor Details...

CH211A FILTER ELEMENT,FLUID 4 EA NS

Subscribe to View Vendor Details...

2940-00-073-3316 OIL FILTER ELEMENT 106 EA NS

Subscribe to View Vendor Details...

195-4 FILTER ELEMENT,FLUID 24 EA NS

Subscribe to View Vendor Details...

195-4 FILTER ELEMENT,FLUID 298 EA NS

Subscribe to View Vendor Details...

000733316.2940 FILTER ELEMENT,FLUID 10 EA NS

Updated Every Day

PF432 RQST NE

Updated Every Day

244523R91 RQST NE

Updated Every Day

998445R91 RQST NE

2940-00-073-3316 RQST NE

Updated Every Day

2940-00-073-3316 RQST

Updated Every Day

2940-00-073-3316 RQST NE

Restrictions 2940-00-073-3316

2940-00-073-3316 is a Fluid Filter Element that does not have a nuclear hardened feature, but does have another critical feature or features such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.

Import and Export 2940-00-073-3316

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 2940-00-073-3316

US Army (A920)
Effective Date:: 1 Jun 2006
Former MOE Rule:: A181
Supplementary Receivers:: AZBD; AMC 3 AMSC Z IMC Z IMCACTY CD

MOE Rule:: B031
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0

MOE Rule:: BGX1
Effective Date:: 21 May 2013
Former MOE Rule:: BAX1; AMC 3 AMSC Z

US Air Force (FUGC)
Effective Date:: 1 Jun 2006
Former MOE Rule:: FUAX; AMC 3 AMSC Z IMC Z IMCACTY SU

NASA (G280)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC C

NASA (G860)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC C

NASA (G900)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC L

US Marine Corps (MC40)
Effective Date:: 1 Jun 2006
Former MOE Rule:: MC01; AMC 3 AMSC Z IMC Z IMCACTY PA

US Navy (N9BC)
Effective Date:: 1 Jun 2006
Former MOE Rule:: NICD
Supplementary Collaborators:: GTHXHD; AMC 3 AMSC Z IMC Z IMCACTY GH

Brazil (YA01)
Effective Date:: 1 Dec 1999

Spain (YB01)
Effective Date:: 1 Oct 1998

Israel (YD01)
Effective Date:: 1 Jul 2016

Singapore (YJ01)
Effective Date:: 1 Apr 1991

Kuwait (YK01)
Effective Date:: 1 Jan 2015

Morocco (YP01)
Effective Date:: 1 Nov 2008

Malaysia (YW01)
Effective Date:: 1 Apr 1991

Australia (ZA01)
Effective Date:: 1 Apr 1991

Canada (ZC01)
Effective Date:: 1 Apr 1991

France (ZF01)
Effective Date:: 1 Apr 1991

Germany (ZG01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

United Kingdom (ZK01)
Effective Date:: 1 Apr 1991

Portugal (ZP01)
Effective Date:: 1 Apr 1991

Denmark (ZS01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Nov 1998

NATO Maintenance and Supply Agency (ZX01)
Effective Date:: 1 Nov 2003

Approved Sources 2940-00-073-3316

Part Number
Manufacturer
Status
LF0051600: 33457 - Cummins Filtration Inc (Active); Primary Buy; RNCC 3 RNVC 2 DAC 6
244523R91: 89346 - Navistar Intl Corp Truck Br Ohio (Active); Primary Buy; RNCC 3 RNVC 2 DAC E
998445R91: 89346 - Navistar Intl Corp Truck Br Ohio (Active); Primary Buy; RNCC 3 RNVC 2 DAC 6
51954: 79396 - Wix Corp (Active); Primary Buy; RNCC 3 RNVC 2 DAC E
P41: 64829 - Arvinmeritor Inc (Active); Primary Buy; RNCC 3 RNVC 2 DAC 6
158139: 15434 - Cummins Inc. (Active); Primary Buy; RNCC 3 RNVC 2 DAC 6
P428: 74069 - Hastings Manufacturing Co (Active); Secondary Buy; RNCC 5 RNVC 2 DAC E
1954: 0HYJ6 - Genuine Parts Company (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
P999: 12658 - Baldwin Filters (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
CH211A: 73370 - Honeywell International Inc (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
1CD77: 75Q65 - Oshkosh Defense Llc (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
S196CP: 79512 - W G B Oil Clarifier Inc (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
LF516: 33457 - Cummins Filtration Inc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
LF516: 22952 - Lee Filter Div Of (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
LF516: 15434 - Cummins Inc. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
149557: 73370 - Honeywell International Inc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
LF516: 45152 - Oshkosh Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
244523R91: 31007 - Navistar International Corporation (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
FL170: 57526 - Ford Motor Company (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
CH211: 73370 - Honeywell International Inc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
158139: 33457 - Cummins Filtration Inc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
FL170: 23040 - Ford Motor Co Ford Parts And Service (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
1954: 050Q3 - National Automotive Parts Assn/Napa/ (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
CW954MP: 79396 - Wix Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
1CD77: 45152 - Oshkosh Corp (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
PM-343MA: 56367 - Parma Industries Inc (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
PF432: 70040 - General Motors Llc (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
2940000733316: A00AM - E.C.A Etablissement Central Des (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
PF432: 7X677 - General Motors Llc (Active); Advisory Reference; RNCC C RNVC 1 DAC E

Datasheet 2940-00-073-3316

Characteristic
Specifications
FIIG: A24000
Style Designator [STYL]: Cylindrical W/ Container (Rigid)
Body Diameter [ABPM]: 4.875 Inches Nominal
Body Inside Diameter [ADAS]: 1.500 Inches Nominal
Body Overall Length [AZTL]: 9.719 Inches Nominal
Material [MATT]: Metal Container/Cartridge
Material [MATT]: Paper Filtering Medium
Filtering Media Design [CRXW]: Pleated Single Filtering Media Response
Design Type [APGF]: Nonreusable
Flow Direction [ADNK]: Outside In
Media For Which Designed [MEDA]: Fuel/Oil, Hydrocarbon
Special Features [FEAT]: Used On Grumman Aircraft,Model A10;Weapon System Essential
Criticality Code Justification [CRTL]: Feat
End Item Identification [AGAV]: Shipboard Material Handling Equipment (Mhe); Armored Combat Earthmover (M9); Sealift Support Facilities Program (Ssfp) Equipment; Filters; Truck, Dump, 20-Ton, Dsl Drv, 12 Cu Yd, F5070; Vehicle, Aircraft Refueler R-9; 485L Tacs; Cobra Dan Sys, Fps-108; Assault Amphibious Vehicle Command (Aavc-7A1); Truck, Wrecker, 5-Ton (M936)

Weapon Systems (WSDC) 2940-00-073-3316

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 2940-00-073-3316

Last Stock Position:: 280 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 2940-00-073-3316

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Jul 2023: Department of the Army (DA); EA; Subscribe; 1
Oct 2022: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2021: Defense Logistics Agency (DS); EA; Subscribe; 1
Oct 2020: Defense Logistics Agency (DS); EA; Subscribe; 1
Oct 2019: Department of the Air Force (DF); EA; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
US Marine Corps (DM): M; 0; Reversal Of Phrase Code Z 2910-00-787-6552

Army

Materiel Category and Inventory Manager:

J: Ground Forces Support Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Air Force

Fund:

SF: Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point

Budget:

9: 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors

Aggregation Code:

SU: AF SICA RESIDUAL MMAC-OO-ALC

Price Validation Code:

V: The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

2: Non-Critical Repair Part

Echelon Management:

B2

Material Identification:

B: Consumable Repair Parts

Operational Test:

: No Special Procedures

NATO Stock Numbers Related to 2940-00-073-3316

4330-22-624-2446 4330-14-366-1726 4330-14-442-3087 4330-12-312-7638 4330-12-189-7365 4330-12-322-1596 4330-12-320-6566 4330-98-201-5889 4330-12-324-1988 4330-14-219-6658 4330-14-549-9191 2940-33-103-2067 4330-14-540-3523 4330-15-152-9697 2940-15-204-3155 4330-14-392-6456 2940-14-236-3204 2940-14-422-0328

Freight Information 2940-00-073-3316

2940-00-073-3316 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 069100. A Sub NMFC of Z. It has a NMFC Description of FILTERS:CARTRIDGES/ELEMENTS. 2940-00-073-3316 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 21275 which rates the freight between FCL and LCL. 2940-00-073-3316 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 2940-00-073-3316 is not classified as a special type of cargo when transported by water. 2940-00-073-3316 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 2940-00-073-3316

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Plated/Coated Item; Over 10lb; Less than 85G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; No Requirement; --; --; Vendor's Fiberboard Box; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: Any Suitable Fiber Box

Procurement History 2940-00-073-3316 1 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE7L321V9757: 31 Aug 2021; Subscribe; 220; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 2940-00-073-3316 October 2021

Criticality and Quality

Critical Item Code:: X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: N
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...

Marketplace 2940-00-073-3316

Related Documents 2940-00-073-3316 5+ Documents (More...)

Restrictions 2940-00-073-3316

Import and Export 2940-00-073-3316

End Users 2940-00-073-3316

Approved Sources 2940-00-073-3316

Datasheet 2940-00-073-3316

Weapon Systems (WSDC) 2940-00-073-3316

DLA Procurement Analysis 2940-00-073-3316

Management Data 2940-00-073-3316

Army

Air Force

Navy

Marine Corps

NATO Stock Numbers Related to 2940-00-073-3316

Freight Information 2940-00-073-3316

Packaging Data 2940-00-073-3316

Item Pack Level (Unpackaged)

Unit Pack Level (Packaged)

Intermediate Pack Level

Procurement History 2940-00-073-3316 1 Records

Contracting Technical Data File (CTDF) 2940-00-073-3316 October 2021

Criticality and Quality

Commercial Properties

Restrictions

Packaging Requirements
