2925-00-142-9915
Ignition Magneto
2925001429915 001429915 4701MJR9A6 AN9500 SB9R03 MJR9A6
An electric generator whose field poles are permanent magnets and which is used to generate electrical energy for the purpose of igniting the combustible mixture in internal combustion engine cylinders. Spark distribution may be accomplished by a distributor portion of the magneto or by a separate item. View more Ignition Magneto
May 2023
21
Marketplace 2925-00-142-9915
Request a Quotation from participating marketplace vendors
Related Documents 2925-00-142-9915 2+ Documents (More...)
SB9R03 MAGNETO,IGNITION 4 EA NS Request Quotation Updated Every Day 2925-00-142-9915 RQST NE Updated
Every Day 2925-00-142-9915 RQST Updated Every Day 2925-00-142-9915 RQST NE Related Documents 2925-00-
Restrictions 2925-00-142-9915
2925-00-142-9915 is a Ignition Magneto that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 2925-00-142-9915
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2925-00-142-9915
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Dec 2007
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 2925-00-142-9915
- Part Number
- Manufacturer
- Status
- MJR9A6
- Manufacturer
- 04998 - Adams Aircraft International Inc (Obsolete)
- Original Design
- Original Design
- 4701MJR9A6
- 88041 - Air Corps Standards (Active)
- Secondary Buy
- Secondary Buy
- AN9500
- 88044 - Aeronautical Standards Group (Active)
- Secondary Buy
- Secondary Buy
- SB9R03
- 01843 - Ambac International Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MJR9A6
- 01854 - Thornton-Fuller Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- SB9R03
- 04998 - Adams Aircraft International Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- MJR9A6
- 01843 - Ambac International Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 2925-00-142-9915
- Characteristic
- Specifications
- FIIG
- Specifications
- A12200
- Distributor Cap [ARFE]
- Not Included
- Drive Connection Type [AAYX]
- Coupling Half
- Drive Shaft Type [AJAB]
- Straight Spline
- Body Material [AAFZ]
- Aluminum
- Contact Set Quantity [AYKN]
- 1
- Distance Between Mounting Facility Centers [AEJN]
- 1.968 Inches Nominal
- Features Provided [CBBL]
- Radio Interference Shielding
- Fsc Application Data [ZZZV]
- Engine Electrical System,Aircraft
- Ignition Type For Which Designed [AXRW]
- Single
- Mounting Facility Quantity [AKPV]
- 4
- Mounting Facility Thread Diameter [CPWR]
- 0.375 Inches Nominal
- Mounting Facility Thread Series [CPWN]
- Unf
- Mounting Facility Thread Quantity Per Inch [CPWS]
- 16
- Mounting Facility [AZGM]
- Threaded Hole
- Mounting Method [AXGY]
- Base
- Impulse Quantity Per Revolution [AXRT]
- 9
- Pole Quantity [AKPX]
- 4
- Rotation Element Type [AYKH]
- Permanent Magnet Rotor
- Shaft Rotation Direction [AKCT]
- Clockwise
- Spark Distribution Method [CPWB]
- Gap
- Performance Type [AGLD]
- High Tension
- Surface Treatment [SFTT]
- Enamel
Similar Supply Items to 2925-00-142-9915
Freight Information 2925-00-142-9915
2925-00-142-9915 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062460. A Sub NMFC of X. It has a NMFC Description of MAGNETOS/PARTS NOI IN BOXES/CRATES. 2925-00-142-9915 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. 2925-00-142-9915 is rated as class 85 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34940 which rates the freight between FCL and LCL. 2925-00-142-9915 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 2925-00-142-9915 is classified as a Magnetic Material when transported by water. 2925-00-142-9915 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
