2920-00-818-8635
Engine Accessory Generator
2920008188635 008188635 5300GP 25276 MS51310-1 10500111 5120177 76-0077 JHP39-58 00076-0077 5300G12P 7954720 A0015300GP 5300G12
A generator primarily designed to be mounted on an internal combustion engine, and to be driven by the engine to keep the battery in a charged condition. May also supply current for the engine ignition system and/or electrical equipment which is connected to the battery circuit. Includes alternating current generators designed for use with a rectifier. Excludes the major generator of "GENERATING SETS". For generators specifically designed for aircraft use and not mounted on the engine, see GENERATOR, DIRECT CURRENT. View more Engine Accessory Generator
November 2023
50
Marketplace 2920-00-818-8635
Request a Quotation from participating marketplace vendors
Related Documents 2920-00-818-8635 5+ Documents (More...)
Engine Accessory Generator 2920008188635 2920-00-818-8635 2920008188635 008188635 is a generator
, NSN 2920-00-818-8635 - - - - - - - -- - - --- ---- NOTE: I I i I THE STYLE OF THIS TM IS I I I EXPERIMENTAL
, NSN 2920-00-818-8635 REPORTING OF ERRORS AND RECOMMENDING IMPROVEMENTS You can help improve this manual
Restrictions 2920-00-818-8635
2920-00-818-8635 is a Engine Accessory Generator The DCMO has forced the Demilization requirements for this item as the ICP has not collaborated. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 2920-00-818-8635
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2920-00-818-8635
- US Army (A204)
- Effective Date:
- 1 Jun 1997
- Former MOE Rule:
- A203
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Israel (YD01)
- Effective Date:
- 1 Jul 2016
- Morocco (YP01)
- Effective Date:
- 1 Nov 2008
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 2920-00-818-8635
- Part Number
- Manufacturer
- Status
- 5300GP
- Manufacturer
- 24975 - Prestolite Electric Inc (Active)
- Primary Buy
- Primary Buy
- 25276
- 95201 - Napco International Llc (Active)
- Secondary Buy
- Secondary Buy
- 00076-0077
- 79343 - Asrc Federal Facilities Logistics, (Active)
- Secondary Buy
- Secondary Buy
- 7954720
- 19207 - U S Army Tank Automotive Command (Active)
- Secondary Buy
- Secondary Buy
- MS51310-1
- 96906 - Military Standards (Active)
- Secondary Buy
- Secondary Buy
- 7954720
- 21699 - Electro-Tech Inc. (Active)
- Secondary Buy
- Secondary Buy
- 10500111
- 23382 - Fwd Seagrave Holdings Lp (Active)
- Secondary Buy
- Secondary Buy
- 5120177
- 72582 - Rolls-Royce Solutions America Inc (Active)
- Secondary Buy
- Secondary Buy
- 5120177
- 24617 - General Motors Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 76-0077
- 93568 - Harsco Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- JHP39-58
- 02032 - Hollingsworth John R Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 00076-0077
- 93568 - Harsco Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 5300G12P
- 35510 - Prestolite Electric Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 5300GP
- 35510 - Prestolite Electric Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 7954720
- 85924 - Electro Mechanical Devices Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- A0015300GP
- 35510 - Prestolite Electric Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 5120177
- 35510 - Prestolite Electric Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 5300G12
- 35510 - Prestolite Electric Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 2920008188635
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
- 5120177
- 7X677 - General Motors Llc (Active)
- Advisory Reference
- Advisory Reference
Datasheet 2920-00-818-8635
- Characteristic
- Specifications
- FIIG
- Specifications
- A14700
- Distance From End To Keyway Center [ANTX]
- 1.375 Inches Nominal
- Angular Deviation Of First Hole From Top Center In Deg [BCMB]
- 201.0
- Angular Deviation Of Second Hole From First Hole In Deg [BCMC]
- 159.0
- Armature Minimum Speed In Rpm At Full Current Output [BCGD]
- 2000
- Bottom Mounting Hole Diameter [BCMH]
- 0.453 Inches Nominal
- Distance Between Inside Surfaces Of Hinge Bracket [BCMD]
- 7.250 Inches Nominal
- Distance Between Outside Surfaces Of Hinge Bracket [BCMF]
- 8.118 Inches Nominal
- Distance Between Shaft Center And Bottom Mounting Hole Center [BCLY]
- 4.125 Inches Nominal
- Distance Between Shaft Center And Top Mounting Hole Center [BCLZ]
- 4.025 Inches Nominal
- Environmental Protection [ADZC]
- Corrosion Resistant
- Maximum Rated Armature Speed In Rpm [BCND]
- 8000
- Minimum Current Cut-In Speed In Rpm [BCGG]
- 750
- Mounting Hole Thread Diameter [CMLL]
- 0.375 Inches Nominal
- Mounting Hole Thread Quantity Per Inch [CMLM]
- 16
- Mounting Hole Thread Series Designator [CMLK]
- Unc
- Mounting Style [ADER]
- Bracket Mtd W/Three Mtg Holes, Top Hole Threaded
- Maximum Output Current Rating In Amps [BCGF]
- 100.0
- Keyway Length [AFYS]
- 0.308 Inches Minimum And 0.313 Inches Maximum
- Keyway Width [ABRR]
- 0.249 Inches Minimum And 0.251 Inches Maximum
- Second Step Diameter [ABPT]
- 0.874 Inches Minimum
- Shaft Drive End Style [BCGS]
- Straight Shaft End, Threaded, W/Keyway
- Shaft Rotation Direction [AKCT]
- Counterclockwise
- Unthreaded Portion Length [ABVA]
- 1.125 Inches Nominal
- Voltage In Volts [ELEC]
- 28.0
- Submersibility [AHZV]
- Submersible
- Thread Length [AASA]
- 0.750 Inches Nominal
- Thread Series [BZRR]
- Unf
- Thread Quantity Per Inch [CMLP]
- 16
Management Data 2920-00-818-8635
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Army (DA)
- A
- R
- Refer To Net Price 1745.00
- NET PRICE 1745.00
- R
Army
- Materiel Category and Inventory Manager:
- K
- Tactical and Support Vehicles, Combat and Automotive Materiel
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- MC
- Armored Carriers
M113A1/A2 Armored Personnel Carrier, Combat Vehicle, Anti-tank
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
NATO Stock Numbers Related to 2920-00-818-8635
Freight Information 2920-00-818-8635
2920-00-818-8635 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062120. A Sub NMFC of Z. It has a NMFC Description of GENERATORS/MOTORS/PARTS NOI. 2920-00-818-8635 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 2920-00-818-8635 is rated as a variable freight class when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34760 which rates the freight between FCL and LCL. 2920-00-818-8635 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 590 for ocean manifesting and military sealift. 2920-00-818-8635 is not classified as a special type of cargo when transported by water. 2920-00-818-8635 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 2920-00-818-8635
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- --
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Weather-Resistant, Corrugated Fiberboard Box
