2920-00-294-4164
Engine Generator Regulator
2920002944164 002944164 7010592 5618349 913344 225183 344909 DX48-17 327576 GPA10505B 597975 VRH4104A1
A regulator designed to automatically maintain the current and/or voltage output of an engine generator within specified limits, regardless of variation of load or input voltages. May include cutout relay. Does not include items in which regulation is accomplished by transformer action. See also REGULATOR, CURRENT and REGULATOR, VOLTAGE. View more Engine Generator Regulator
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
November 2023
November 2023
NATO Update Count
24
24
NATO Data Quality
Marketplace 2920-00-294-4164
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 2920-00-294-4164 5+ Documents (More...)
Supply Items Approved for CAGE 89266 Page 1 of 1 2920-00-294-4164 Engine Generator Regulator 327576RNCC
Documents 2920-00-445-5383 5+ Documents ( More... ) https//www.nsnlookup.com /fsg-29/fsc-2920/us 2920-00-294-4164
Engine Generator Regulator 2920002944164 //www.nsnlookup.com /nato/nato-stock-numbers/inc Engine
Engine Generator Regulator 2920002944164 //www.nsnlookup.com /nato/nato-stock-numbers/inc Engine
//www.nsnlookup.com /nato/nato-stock-numbers/inc Engine Generator Regulator (INC 17169) 1963 2920-00-294-4164
RNVC: 9 | DAC: X 1 Jan 1963 5330-00-291-7418 Gasket 319878RNCC: 5 | RNVC: 9 | DAC: X 1 Jan 1963 2920-00-294-4164
1962 2920-00-445-5383 Engine Generator Regulator AM2702TRNCC: 5 | RNVC: 2 | DAC: 6 1 Jan 1963 2920-00-294-4164
Restrictions 2920-00-294-4164
2920-00-294-4164 is a Engine Generator Regulator that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 2920-00-294-4164
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2920-00-294-4164
- US Air Force (FUGC)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- FUAX
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- France (ZF01)
- Effective Date:
- 1 May 2015
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 2920-00-294-4164
- Part Number
- Manufacturer
- Status
- 913344
- Manufacturer
- 12204 - Chrysler Realty Company Llc (Active)
- Original Design
- Original Design
- 7010592
- 19207 - U S Army Tank Automotive Command (Active)
- Secondary Buy
- Secondary Buy
- 5618349
- 19207 - U S Army Tank Automotive Command (Active)
- Secondary Buy
- Secondary Buy
- 327576
- 1ML14 - Brinkley Technology Group Llc (Active)
- Secondary Buy
- Secondary Buy
- 225183
- 08683 - Brockway Motor Trucks Div Of Mack (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 344909
- 65282 - White Motor Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- DX48-17
- 56442 - Diamond Reo Truck Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 327576
- 28265 - Hercules Engine Co Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- GPA10505B
- 57526 - Ford Motor Company (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 597975
- 12204 - Chrysler Realty Company Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- VRH4104A1
- 45320 - Paccar Government Group Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 327576
- 89266 - Seymour Woolen Mills (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- GPA10505B
- 23040 - Ford Motor Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 327576
- 00006 - Acf-Brill Motors Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 2920-00-294-4164
- Characteristic
- Specifications
- FIIG
- Specifications
- A18400
- Circuit Control Device Type [ANYR]
- Cutout Relay
- Current Regulator Unit Type [ANYJ]
- Wire Wound Coil
- Current Regulator Unit Quantity [ANYK]
- 1
- Cut-In Voltage Rating [ANYS]
- 14.1 Minimum Err-100 Err-100
- Cut-In Voltage Rating [ANYS]
- 14.3 Maximum Err-100 Err-100
- Cutout Current Rating In Amps [ANYZ]
- 0.5 Minimum Err-100 Err-100
- Cutout Current Rating In Amps [ANYZ]
- 6.0 Maximum Err-100 Err-100
- Cutout Voltage Rating [ANYX]
- 13.0 Minimum Err-100 Err-100
- Cutout Voltage Rating [ANYX]
- 13.5 Maximum Err-100 Err-100
- Distance Between Holes Along Length [ADNY]
- 6.000 Inches Nominal
- Distance Between Holes Along Width [ADNZ]
- 5.125 Inches Nominal
- Environmental Protection [ADZC]
- Fungus Resistant
- Field Relay Unit [ANZC]
- Not Included
- Mounting Hole Diameter [ABTB]
- 0.344 Inches Nominal
- Mounting Style [ADER]
- Four Hole Rectangular
- Output Current Rating In Amps [ANYP]
- 54.0 Minimum Err-100 Err-100
- Output Current Rating In Amps [ANYP]
- 56.0 Maximum Err-100 Err-100
- Output Voltage Rating In Volts [ANPP]
- 14.5 Maximum Err-100 Err-100
- Output Voltage Rating In Volts [ANPP]
- 14.0 Minimum Err-100 Err-100
- Radio Interference Shielding [ALBH]
- Not Provided
- Reverse Current Overload Circuit Breaker [ANZB]
- Not Included
- Shock Mount [AGBC]
- Not Provided
- Voltage Regulator Unit Quantity [ANYH]
- 1
- Voltage Regulator Unit Type [ANYE]
- Wire Wound Coil
- System Ground Polarity [ANYD]
- Negative Err-100 Err-100
- System Ground Polarity [ANYD]
- Positive Err-100 Err-100
- System Voltage Rating [ANYC]
- 12.0
- Terminal Encasement [ANZE]
- Not Encased
- Terminal Quantity [AARA]
- 3
- Terminal Type [AARB]
- Screw
DLA Procurement Analysis 2920-00-294-4164
Management Data 2920-00-294-4164
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SU
- AF SICA RESIDUAL MMAC-OO-ALC
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
NATO Stock Numbers Related to 2920-00-294-4164
2925-14-549-8745 2920-12-123-8954 2920-99-203-4217 2920-66-037-1509 2920-12-322-0280 2920-27-019-0426 2920-99-714-5251 2920-21-864-9137 2920-14-413-9755 2920-14-386-0149 2920-15-156-8910 2920-27-032-9321 2920-12-166-3089 2925-00-172-8328 2920-21-896-1470 2920-99-202-6198 2920-14-357-0895 2925-14-208-8707
Freight Information 2920-00-294-4164
2920-00-294-4164 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062900. A Sub NMFC of X. It has a NMFC Description of RECTIFIERS NOI/BATTERY ELIMINATORS. 2920-00-294-4164 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 35110 which rates the freight between FCL and LCL. 2920-00-294-4164 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 2920-00-294-4164 is not classified as a special type of cargo when transported by water. 2920-00-294-4164 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
