2910-01-423-2859
Fluid Filter Element
2910014232859 014232859 23530706 P556915 BW723 EB5632 TP915D 23518481 65190001 2910PL1029726
A replaceable device designed to remove solid particles from fluids ranging in density from heavy liquids to gases. The removal of particles is accomplished by porous material (metallic or non-metallic), stacked disks, wound wire, or the like, constructed so the fluid can flow through the device while the solid particles are retained. It may be designed to fit into a FILTER, FLUID (or similar cavity), or it may have an integral outer casing and mounting facilities and be designed to connect directly to an engine, compressor, or the like. The degree of removal of particles must be nominally rated at less than 50 microns or absolutely rated at less than 75 microns. Excludes FILTER ELEMENT, AIR CONDITIONING. See also STRAINER ELEMENT, SEDIMENT. View more Fluid Filter Element
March 2025
33
Marketplace 2910-01-423-2859
Request a Quotation from participating marketplace vendors
Related Documents 2910-01-423-2859 2+ Documents (More...)
BW723 FILTER ELEMENT 1 EA NS Request Quotation 23530706 FILTER 2 EA NS Request Quotation P556915 FILTER
RQST NE Updated Every Day 2910-01-423-2859 RQST NE Updated Every Day 2910-01-423-2859 RQST Updated Every
More... ) https//www.nsnlookup.com /fsg-59/fsc-5970/us 5970-00-447-4212 Hub 5970004474212004474212,BW723
Element 2910014232859 014232859 your Account Upgrade 2910-01-423-2859Fluid Filter Element2910014232859
Restrictions 2910-01-423-2859
2910-01-423-2859 is a Fluid Filter Element that does not have a nuclear hardened feature, but does have another critical feature or features such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 2910-01-423-2859
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2910-01-423-2859
- US Army (A920)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZ
- US Air Force (FUGC)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- FUAX
- US Marine Corps (MC40)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- MC01
- US Navy (N9BC)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GTKEHD
- Poland (WP01)
- Effective Date:
- 1 Sep 2008
- Brazil (YA01)
- Effective Date:
- 1 Jan 2004
- Singapore (YJ01)
- Effective Date:
- 1 Jan 2002
- Australia (ZA01)
- Effective Date:
- 1 Jan 1997
- Belgium (ZB01)
- Effective Date:
- 1 May 2007
- Republic of Korea (ZH01)
- Effective Date:
- 1 Mar 2000
- United Kingdom (ZK01)
- Effective Date:
- 1 Nov 2010
- Italy (ZR01)
- Effective Date:
- 1 Dec 2007
- Greece (ZU01)
- Effective Date:
- 1 Jun 2005
- Turkey (ZW01)
- Effective Date:
- 1 Oct 2001
Approved Sources 2910-01-423-2859
- Part Number
- Manufacturer
- Status
- 23530706
- Manufacturer
- 72582 - Rolls-Royce Solutions America Inc (Active)
- Primary Buy
- Primary Buy
- P556915
- 18265 - Donaldson Company, Inc. (Active)
- Secondary Buy
- Secondary Buy
- BW723
- K4664 - Carmichael International Ltd (Active)
- Secondary Buy
- Secondary Buy
- EB5632
- 0SMN2 - Itw Gse Inc. (Active)
- Secondary Buy
- Secondary Buy
- TP915D
- 72582 - Rolls-Royce Solutions America Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 23518481
- K0030 - Rheinmetall Bae Systems Land Limited (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 65190001
- K4664 - Carmichael International Ltd (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 23518481
- U5259 - Alvis Vehicles Ltd (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- EB5632
- 12867 - Gse Holdings Inc. (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 23518481
- 72582 - Rolls-Royce Solutions America Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 2910PL1029726
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
Datasheet 2910-01-423-2859
- Characteristic
- Specifications
- FIIG
- Specifications
- A24000
- Style Designator [STYL]
- Cylindrical W/ Integral Outer Casing
- Body Diameter [ABPM]
- 3.660 Inches Nominal
- Body Overall Length [AZTL]
- 7.780 Inches Nominal
- Thread Series Designator [THSD]
- Anpt
- Nominal Thread Size [CQJX]
- 1.000 Inches
- Material [MATT]
- Steel Body
- Filtering Media Design [CRXW]
- Pleated 1St Filtering Media Response
- Design Type [APGF]
- Nonreusable
- Filtration Rating In Microns [ADNH]
- 45.0 Nominal
- Flow Direction [ADNK]
- Inside Out
- Media For Which Designed [MEDA]
- Fuel/Oil, Hydrocarbon
- Drop Pressure [ADNP]
- 5.000 Pounds Per Square Inch
- Face Velocity [ADNS]
- 45.000 Feet Per Minute
- Filtering System For Which Designed [CXZX]
- Full Flow
- Special Features [FEAT]
- Weapon System Essential
- Criticality Code Justification [CRTL]
- Feat
- Storage Type [BBRG]
- Unheated Warehouse
- End Item Identification [AGAV]
- 3990-01-307-7676
Weapon Systems (WSDC) 2910-01-423-2859
DLA Procurement Analysis 2910-01-423-2859
- Last Stock Position:
- 573 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 2910-01-423-2859
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Mar 2023
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2022
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Apr 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SU
- AF SICA RESIDUAL MMAC-OO-ALC
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 2910-01-423-2859
Freight Information 2910-01-423-2859
2910-01-423-2859 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 190600. A Sub NMFC of Z. It has a NMFC Description of VEHICLE PTS:AXLES NOI. 2910-01-423-2859 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 93500 which rates the freight between FCL and LCL. 2910-01-423-2859 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 671 for ocean manifesting and military sealift. 2910-01-423-2859 is not classified as a special type of cargo when transported by water. 2910-01-423-2859 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 2910-01-423-2859
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Non-Metallic Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-PRF-121, Type II, Light Duty, Greaseproof, Waterproof Barrier
- No Requirement
- Not Applicable
- Vendor's Setup or Folding Box
- No special marking
- MIL-PRF-121, Type II, Light Duty, Greaseproof, Waterproof Barrier
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM - D5118, Fiberboard Box
Procurement History 2910-01-423-2859 8 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE7L723V0377
- 01 Feb 2023
- Subscribe
- 291
- Subscribe
- Subscribe
- Subscribe
- SPE7L122V5065
- 01 Mar 2022
- Subscribe
- 74
- Subscribe
- Subscribe
- Subscribe
- SPE7L122V1939
- 08 Nov 2021
- Subscribe
- 151
- Subscribe
- Subscribe
- Subscribe
- SPE7L521V2605
- 19 Aug 2021
- Subscribe
- 20
- Subscribe
- Subscribe
- Subscribe
- SPE7L321F032Q
- 15 Apr 2021
- Subscribe
- 77
- Subscribe
- Subscribe
- Subscribe
- SPE7L321F032Q
- 15 Apr 2021
- Subscribe
- 77
- Subscribe
- Subscribe
- Subscribe
- SPE7L518V0676
- 11 Jan 2018
- Subscribe
- 590
- Subscribe
- Subscribe
- Subscribe
- SPE7L517V0741
- 08 Mar 2017
- Subscribe
- 559
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 2910-01-423-2859 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
