2910-01-192-4622

Fluid Filter Element

2910011924622 011924622 33357 6742-01-0020 0 986 450 713 FS1280HD BF1280 FS1280 HC12428105 FS-1280 91301 851-01-0262 4700950301 J925274 3903410 9414101066 9-414-100790 124-28105 161623 6732-71-6120 3925274 3930942 FF5038 3357 FS0128000 205266 6-28105

A replaceable device designed to remove solid particles from fluids ranging in density from heavy liquids to gases. The removal of particles is accomplished by porous material (metallic or non-metallic), stacked disks, wound wire, or the like, constructed so the fluid can flow through the device while the solid particles are retained. It may be designed to fit into a FILTER, FLUID (or similar cavity), or it may have an integral outer casing and mounting facilities and be designed to connect directly to an engine, compressor, or the like. The degree of removal of particles must be nominally rated at less than 50 microns or absolutely rated at less than 75 microns. Excludes FILTER ELEMENT, AIR CONDITIONING. See also STRAINER ELEMENT, SEDIMENT. View more Fluid Filter Element

Managed by United States

NSN Created on 20 Oct 1984

Data Last Changed
May 2025

NATO Update Count
96

NATO Data Quality

2910-01-192-4622 FILTER ELEMENT,FLUID 2910011924622 011924622 1/2 — 2910-01-192-4622 Photo 1/2

STYL Style A14 for 2910-01-192-4622 2/2 — NSN 2910-01-192-4622 (Identification) 2/2

Marketplace 2910-01-192-4622

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

3357 FILTER ELEMENT,FLUID 2 EA NS

Subscribe to View Vendor Details...

3357 FILTER ELEMENT,FLUID 5 EA NS

Subscribe to View Vendor Details...

T1068 FILTER ELEMENT,FLUID 1 EA NS

T10-68 FILTER ELEMENT,FLUID 1 EA NS

Subscribe to View Vendor Details...

205266 FILTER ELEMENT,FLUID 148 EA NS

FS1280 FILTER ELEMENT,FLUID 36 EA NS

Subscribe to View Vendor Details...

33357 FILTER ELEMENT 1 EA NS

Subscribe to View Vendor Details...

FS1280 FILTER ELEMENT,FLUID 11 EA NS

Subscribe to View Vendor Details...

2910-01-192-4622 FILTER ELEMENT FLUID 3 EA NS

Subscribe to View Vendor Details...

6732-71-6120 FILTER ELEMENT,FLUID 1 EA NS

Subscribe to View Vendor Details...

3357 FILTER ELEMENT,FLUID 3 EA NS

Subscribe to View Vendor Details...

3925274 FILTER ELEMENT,FLUID 2 EA NS

6732-71-6120 FILTER ELEMENT,FLUID 2 EA NS

FS-1280 FILTER ELEMENT,FLUID 2 EA NS

33357 FILTER ELEMENT,FLUID 2 EA NS

161623 FILTER ELEMENT,FLUID 2 EA NS

9-414-100790 FILTER ELEMENT,FLUID 2 EA NS

FF5038 FILTER ELEMENT,FLUID 4 EA NS

205266 FILTER ELEMENT,FLUID 2 EA NS

6-28105 FILTER ELEMENT,FLUID 2 EA NS

3903410 FILTER ELEMENT,FLUID 2 EA NS

J925274 FILTER ELEMENT,FLUID 2 EA NS

Subscribe to View Vendor Details...

1549159 FILTER ELEMENT,FLUID 3 EA NS

011924622.2910 FILTER ELEMENT,FLUID 33 EA NS

9-414-100790 RQST NE

2910-01-192-4622 RQST NE

Updated Every Day

2910-01-192-4622 RQST

Updated Every Day

2910-01-192-4622 RQST NE

Restrictions 2910-01-192-4622

2910-01-192-4622 is a Fluid Filter Element that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 2910-01-192-4622

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 2910-01-192-4622

US Army (A920)
Effective Date:: 1 Aug 2006
Former MOE Rule:: A181
Supplementary Receivers:: AZBS; AMC 1 AMSC C IMC Z IMCACTY AZ

MOE Rule:: BGX1
Effective Date:: 6 Dec 2010
Former MOE Rule:: BAX1; AMC 3 AMSC D

US Air Force (FUGC)
Effective Date:: 1 Aug 2006
Former MOE Rule:: FUAX; AMC 1 AMSC C IMC Z IMCACTY SU

NASA (G860)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AAC C

US Marine Corps (MC40)
Effective Date:: 1 Aug 2006
Former MOE Rule:: MC01; AMC 1 AMSC C IMC Z IMCACTY PA

US Navy (N9BC)
Effective Date:: 1 Aug 2006
Former MOE Rule:: N9CD
Supplementary Collaborators:: GTKEHD; AMC 1 AMSC C IMC Z IMCACTY GH

MOE Rule:: RGX1
Effective Date:: 1 Aug 2006
Former MOE Rule:: R477
Supplementary Collaborators:: TR; AMC 1 AMSC C

Poland (WP01)
Effective Date:: 1 Jan 2008

Brazil (YA01)
Effective Date:: 1 Nov 2001

Spain (YB01)
Effective Date:: 1 Feb 2004

Singapore (YJ01)
Effective Date:: 1 Apr 2000

Malaysia (YW01)
Effective Date:: 1 Aug 2000

Australia (ZA01)
Effective Date:: 1 Apr 1991

Belgium (ZB01)
Effective Date:: 1 Oct 2000

Canada (ZC01)
Effective Date:: 1 Nov 2000

South Africa (ZD01)
Effective Date:: 1 Aug 2015

New Zealand (ZE01)
Effective Date:: 1 Apr 1991

France (ZF01)
Effective Date:: 1 Apr 1991

Germany (ZG01)
Effective Date:: 1 Aug 1993

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

United Kingdom (ZK01)
Effective Date:: 1 Nov 2006

Netherlands (ZN01)
Effective Date:: 1 Dec 1997

Portugal (ZP01)
Effective Date:: 1 Jul 1998

Norway (ZT01)
Effective Date:: 1 Jul 2003

Greece (ZU01)
Effective Date:: 1 May 2008

Turkey (ZW01)
Effective Date:: 1 Nov 1998

NATO Maintenance and Supply Agency (ZX01)
Effective Date:: 1 Jan 2014

Approved Sources 2910-01-192-4622

Part Number
Manufacturer
Status
33357: 79396 - Wix Corp (Active); Primary Buy; RNCC 3 RNVC 2 DAC 6
J925274: 10988 - Cnh Industrial America Llc (Active); Original Design; RNCC 3 RNVC 9 DAC 6
6742-01-0020: ZV961 - Komatsu Australia Pty Ltd (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 3
0 986 450 713: D8015 - Robert Bosch Gesellschaft Mit (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 3
FS1280HD: F8779 - Cummins Filtration Sarl (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 4
BF1280: FAQ50 - Societe Motorest (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 4
FS1280: Z0EH3 - Raytheon Australia Pty Ltd (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
HC12428105: 7P354 - Superior Compressor Company (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
FS1280: 15434 - Cummins Inc. (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
FS-1280: 33457 - Cummins Filtration Inc (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
161623: 45RP7 - Dressta North America Ltd (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
6732-71-6120: 45RP7 - Dressta North America Ltd (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
91301: 1777B - Langa Industrial Sa (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 3
3930942: ZC672 - Cummins South Pacific Pty Ltd Head (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 3
851-01-0262: 0220H - Huta Stalowa Wola S A (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
FS-1280: H2307 - Heli-One (Netherlands) B.V. (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
6732-71-6120: ZV961 - Komatsu Australia Pty Ltd (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 3
6732-71-6120: 0SAT8 - Komatsu America Corp. (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
900827: D9797 - Dynapac Gmbh (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
4700950301: F9222 - Epiroc France (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 6
3903410: 12361 - Grove U.S. Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
9414101066: 12361 - Grove U.S. Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
9-414-100790: 15434 - Cummins Inc. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
124-28105: 7P354 - Superior Compressor Company (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
161623: 29510 - Komatsu American Intl Co (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
6732-71-6120: 29510 - Komatsu American Intl Co (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
161623: 0SAT8 - Komatsu America Corp. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
3925274: 15434 - Cummins Inc. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
3930942: 15434 - Cummins Inc. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
FF5038: 33457 - Cummins Filtration Inc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
3903410: 67271 - Kohler Co. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
9-414-100790: 12361 - Grove U.S. Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
3357: 050Q3 - National Automotive Parts Assn/Napa/ (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
3357: 0HYJ6 - Genuine Parts Company (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
FS0128000: 33457 - Cummins Filtration Inc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
205266: 81495 - Koehring Cranes, Inc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC A
6-28105: 7P354 - Superior Compressor Company (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
9414101066: 0MKW7 - Minnpar, Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
T1068: 70040 - General Motors Llc (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
900827: D3562 - Dynapac Gmbh (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
3903410: 15434 - Cummins Inc. (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
75208274: F2314 - Iveco France Sa (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
FS-1280: F8779 - Cummins Filtration Sarl (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
2910PL1602512: 9009H - Jednolity Indeks Materialowy - (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
2910PL1602514: 9009H - Jednolity Indeks Materialowy - (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
2910PL1038767: 9009H - Jednolity Indeks Materialowy - (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9

Datasheet 2910-01-192-4622

Characteristic
Specifications
FIIG: A24000
End Item Identification [AGAV]: Loader;J.I.Case,Model450c,480E,580E; 3990-01-444-5196 Cement Mixer
Body Diameter [ABPM]: 3.810 Inches Nominal
Body Overall Length [AZTL]: 6.400 Inches Nominal
Design Type [APGF]: Nonreusable
Features Provided [CBBL]: By-Pass Valve And Drain Plug
Filtering Media Design [CRXW]: Pleated Single Filtering Media Response
Filtering System For Which Designed [CXZX]: Full Flow
Flow Direction [ADNK]: Outside In
Material [MATT]: Paper Filtering Medium
Material [MATT]: Rubber Seal
Material [MATT]: Steel Container/Cartridge
Media For Which Designed [MEDA]: Fuel/Oil, Hydrocarbon
Nominal Thread Size [CQJX]: 0.812 Inches
Style Designator [STYL]: Cylindrical W/ Integral Outer Casing
Special Features [FEAT]: Spin-On Fuel/Water Separator; Also Used On J.I. Case Model 721B Loader 6T-830 Engine
Special Test Features [SPCL]: Fuel Filter Separator
Surface Treatment [SFTT]: Paint Container/Cartridge
Thread Series Designator [THSD]: Uns

Weapon Systems (WSDC) 2910-01-192-4622

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 2910-01-192-4622

Last Stock Position:: 2346 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 2910-01-192-4622

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Mar 2023: Department of the Navy (DN); EA; Subscribe; 1
Oct 2022: US Marine Corps (DM); EA; Subscribe; 1
Oct 2021: Department of the Air Force (DF); EA; Subscribe; 1
Apr 2021: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2020: US Marine Corps (DM); EA; Subscribe; 1
Oct 2019: Department of the Air Force (DF); EA; Subscribe; 1

Army

Materiel Category and Inventory Manager:

J: Ground Forces Support Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Air Force

Fund:

SF: Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point

Budget:

9: 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors

Aggregation Code:

SU: AF SICA RESIDUAL MMAC-OO-ALC

Price Validation Code:

N: The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

5: Critical Repair Part to a Combat Essential End Item

Echelon Management:

B2

Operational Test:

: No Special Procedures

NATO Stock Numbers Related to 2910-01-192-4622

4330-22-624-2446 4330-14-366-1726 4330-14-442-3087 4330-12-312-7638 4330-12-189-7365 4330-12-322-1596 4330-12-320-6566 4330-98-201-5889 4330-12-324-1988 4330-14-219-6658 4330-14-549-9191 2940-33-103-2067 4330-14-540-3523 4330-15-152-9697 2940-15-204-3155 4330-14-392-6456 2940-14-236-3204 2940-14-422-0328

Freight Information 2910-01-192-4622

2910-01-192-4622 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 069100. A Sub NMFC of Z. It has a NMFC Description of FILTERS:CARTRIDGES/ELEMENTS. 2910-01-192-4622 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 21275 which rates the freight between FCL and LCL. 2910-01-192-4622 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 2910-01-192-4622 is not classified as a special type of cargo when transported by water. 2910-01-192-4622 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 2910-01-192-4622

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Bare Metal Item; Over 10lb; Less than 85G; Special Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; --

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: --; --; --; --; --; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: See Method of Preservation; --

Procurement History 2910-01-192-4622 8 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE7L724P0142: 13 Oct 2023; Subscribe; 1425; Subscribe; Subscribe
SPE7L118V5556: 21 May 2018; Subscribe; 8343; Subscribe; Subscribe
SPE7L117V1992: 10 Jan 2017; Subscribe; 11434; Subscribe; Subscribe
SPE7L015V1517: 10 Nov 2014; Subscribe; 900; Subscribe; Subscribe
SPE7L415M0105: 07 Oct 2014; Subscribe; 8000; Subscribe; Subscribe
SPE7L513V0254: 24 Sep 2013; Subscribe; 9143; Subscribe; Subscribe
SPM7L513V1955: 03 May 2013; Subscribe; 1966; Subscribe; Subscribe
SPM7L513M1365: 04 Feb 2013; Subscribe; 1760; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 2910-01-192-4622 October 2021

Criticality and Quality

Critical Item Code:: X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: N
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...

Marketplace 2910-01-192-4622

Related Documents 2910-01-192-4622 5+ Documents (More...)

Restrictions 2910-01-192-4622

Import and Export 2910-01-192-4622

End Users 2910-01-192-4622

Approved Sources 2910-01-192-4622

Datasheet 2910-01-192-4622

Weapon Systems (WSDC) 2910-01-192-4622

DLA Procurement Analysis 2910-01-192-4622

Management Data 2910-01-192-4622

Army

Air Force

Navy

Marine Corps

NATO Stock Numbers Related to 2910-01-192-4622

Freight Information 2910-01-192-4622

Packaging Data 2910-01-192-4622

Item Pack Level (Unpackaged)

Unit Pack Level (Packaged)

Intermediate Pack Level

Procurement History 2910-01-192-4622 8 Records

Contracting Technical Data File (CTDF) 2910-01-192-4622 October 2021

Criticality and Quality

Commercial Properties

Restrictions

Packaging Requirements
