2805-00-517-9905
Engine Poppet Valve
2805005179905 005179905 23922
A mushroom or tulip-shaped item having a circular head with a conical face and an extended stem used to regulate the flow of incoming fuel-air mixture or air into the combustion chamber or exhaust gases from the combustion chamber of a reciprocating internal combustion engine. View more Engine Poppet Valve
May 2023
21
Marketplace 2805-00-517-9905
Request a Quotation from participating marketplace vendors
Related Documents 2805-00-517-9905 5+ Documents (More...)
Photo 1/4 2805-00-517-9905 Photo 2/4 NSN 2805-00-517-9905 (Identification) 3/4 NSN 2805-00-517-
Request Quotation Updated Every Day 2805-00-517-9905 RQST NE Updated Every Day 2805-00-517-9905 RQST
Quotation Subscribe to View Vendor Details... 23922 JET 15 EA NS Request Quotation Updated Every Day
CIRCUIT CARD ASSEMBLY RQST NS Request Quotation Subscribe to View Vendor Details... 23922 CIRCUIT CARD
enable JavaScript in your web browser . 5985-99-971-7721Directive Waveguide5985999717721 999717721 23922
ASSEMBLY 10 EA NS Request Quotation Subscribe to View Vendor Details... 23922 CIRCUIT CARD ASSEMBLY
www.nsnlookup.com /fsg-43/fsc-4310/fr 4310-14-424-6018 Reciprocating Compressor Cylinder 144246018 23922
enable JavaScript in your web browser . 5340-15-237-6504Cuffia Copri Occhio5340152376504 152376504 23922
to View Vendor Details... 2392-2 JET 5 EA NS Request Quotation Subscribe to View Vendor Details... 23922
JET RQST NS Request Quotation Subscribe to View Vendor Details... 23922 JET 10 EA NS Request Quotation
Restrictions 2805-00-517-9905
2805-00-517-9905 is a Engine Poppet Valve that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 2805-00-517-9905
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2805-00-517-9905
- US Army (A920)
- Effective Date:
- 1 Aug 2004
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZ
- US Coast Guard (C911)
- Effective Date:
- 1 Aug 2004
- Former MOE Rule:
- C001
- US Navy (N9BC)
- Effective Date:
- 1 Aug 2004
- Former MOE Rule:
- NICD
- Supplementary Collaborators:
- HD
- Kuwait (YK01)
- Effective Date:
- 1 Feb 2015
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 2805-00-517-9905
- Part Number
- Manufacturer
- Status
- 23922
- Manufacturer
- 08645 - Briggs And Stratton Corp (Active)
- Primary Buy
- Primary Buy
Datasheet 2805-00-517-9905
- Characteristic
- Specifications
- FIIG
- Specifications
- A11200
- Material And Location [ANNQ]
- Steel, Fed Std 66, Aisi/Sae 3140 Overall
- Head Style [AASK]
- Mushroom
- Head Height [AASU]
- 0.1562 Inches Nominal
- Outside Diameter [ABKV]
- 1.2500 Inches Nominal
- Neck Radius [ALZB]
- 0.3125 Inches Nominal
- Seat Angle In Deg [AJFY]
- 45.0
- Stem Style [ALYX]
- Grooved
- Groove Diameter [AAVZ]
- 0.2530 Inches Nominal
- Chamfer Length [AAZP]
- 0.0469 Inches Nominal
- Groove Width [ABGF]
- 0.2650 Inches Nominal
- Stem Length [ALZD]
- 4.6730 Inches Nominal
- Stem Diameter [ALZE]
- 0.3100 Inches Nominal
- Distance From Groove To Stem End [ALZG]
- 0.2500 Inches Nominal
- Chamfer Angle In Deg [AATE]
- 30.0
- Carbon Relief Groove [ALYZ]
- Not Included
- Fsc Application Data [ZZZV]
- Gasoline Engine
DLA Procurement Analysis 2805-00-517-9905
Management Data 2805-00-517-9905
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 2805-00-517-9905
Freight Information 2805-00-517-9905
2805-00-517-9905 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051080. A Sub NMFC of Z. It has a NMFC Description of FAUCETS,BIBCOCKS,GATES VALVES. 2805-00-517-9905 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 29300 which rates the freight between FCL and LCL. 2805-00-517-9905 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 2805-00-517-9905 is not classified as a special type of cargo when transported by water. 2805-00-517-9905 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 2805-00-517-9905
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- MIL-PRF-21260, Preservative and Break-in Lubricating Oil, Internal Combustion Engine, Grade 10, 30 or 50
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Weather-Resistant, Corrugated Fiberboard Box
Contracting Technical Data File (CTDF) 2805-00-517-9905 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
