2805-00-357-5773
Engine Poppet Valve
2805003575773 003575773 11681708
A mushroom or tulip-shaped item having a circular head with a conical face and an extended stem used to regulate the flow of incoming fuel-air mixture or air into the combustion chamber or exhaust gases from the combustion chamber of a reciprocating internal combustion engine. View more Engine Poppet Valve
Managed by United States
NSN Created on 18 Feb 1974
Data Last Changed
May 2023
May 2023
NATO Update Count
20
20
NATO Data Quality
Marketplace 2805-00-357-5773
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 2805-00-357-5773 5+ Documents (More...)
11681708 A mushroom or tulip-shaped item having a circular head with a conical face and an extended
(Identification) 1/2 NSN 2805-00-357-5773 (Identification) 2/2 - - 1.
United States (US) 4. 2805-00-357-5773 Marketplace Restrictions Approved Sources Datasheet Management
(Identification) 1/2 NSN 2805-00-357-5773 (Identification) 2/2 - - 1.
United States (US) 4. 2805-00-357-5773 Marketplace Restrictions Approved Sources Datasheet Management
$1 a day Upgrade your Account Upgrade 2805-00-378-8996Engine Poppet Valve2805003788996 003788996 11681708
www.nsnlookup.com /fsg-28/fsc-2805/us 2805-00-378-8996 Engine Poppet Valve 2805003788996003788996 11681708
Engine Poppet Valve 2805003575773 003575773 9999Engine Poppet Valve2805003759999 003759999 11681708
www.nsnlookup.com /fsg-28/fsc-2805/us 2805-00-378-8996 Engine Poppet Valve 2805003788996003788996 11681708
Engine Poppet Valve 2805003575773 003575773 9999Engine Poppet Valve2805003759999 003759999 11681708
$1 a day Upgrade your Account Upgrade 2805-00-375-9999Engine Poppet Valve2805003759999 003759999 11681708
www.nsnlookup.com /fsg-28/fsc-2805/us 2805-00-375-9999 Engine Poppet Valve 2805003759999003759999 11681708
Agency (DS)IZDiscontinued-Use 2805-00-375-9999 https//www.nsnlookup.com /fsg-28/fsc-2805/us 2805-00-357-5773
www.nsnlookup.com /fsg-28/fsc-2805/us 2805-00-375-9999 Engine Poppet Valve 2805003759999003759999 11681708
Agency (DS)IZDiscontinued-Use 2805-00-375-9999 https//www.nsnlookup.com /fsg-28/fsc-2805/us 2805-00-357-5773
$1 a day Upgrade your Account Upgrade 2805-00-363-7101Engine Poppet Valve2805003637101 003637101 11681708
-1 VALVE,POPPET,ENGINE 4 EA NS Request Quotation 11681708-1 VALVE POPPET ENGINE 2 EA NS Request Quotation
www.nsnlookup.com /fsg-28/fsc-2805/us 2805-00-363-7101 Engine Poppet Valve 2805003637101003637101 11681708
-1 VALVE,POPPET,ENGINE 4 EA NS Request Quotation 11681708-1 VALVE POPPET ENGINE 2 EA NS Request Quotation
www.nsnlookup.com /fsg-28/fsc-2805/us 2805-00-363-7101 Engine Poppet Valve 2805003637101003637101 11681708
Restrictions Approved Sources Datasheet Management https//www.nsnlookup.com /fsg-28/fsc-2805/us 2805-00-357-5773
Engine Poppet Valve 2805003575773 003575773 Restrictions Approved Sources Datasheet Management
Engine Poppet Valve 2805003575773 003575773 Restrictions Approved Sources Datasheet Management
Restrictions 2805-00-357-5773
2805-00-357-5773 is a Engine Poppet Valve that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 2805-00-357-5773
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2805-00-357-5773
- US Army (A920)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- A181
- Supplementary Receivers:
- BD
- US Air Force (FUGC)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- FUAX
- US Marine Corps (MC40)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- MC01
- US Navy (N9BC)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GTHD
- Spain (YB01)
- Effective Date:
- 1 Feb 2006
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Kuwait (YK01)
- Effective Date:
- 1 Feb 2015
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Jan 1994
Approved Sources 2805-00-357-5773
- Part Number
- Manufacturer
- Status
- 11681708
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
Datasheet 2805-00-357-5773
- Characteristic
- Specifications
- FIIG
- Specifications
- A11200
- Distance From Minor Diameter To Stem End [ALZF]
- 0.1740 Inches Minimum And 0.1760 Inches Maximum
- Carbon Relief Groove [ALYZ]
- Not Included
- Chamfer Angle In Deg [AATE]
- 45.0
- Chamfer Length [AAZP]
- 0.0300 Inches Nominal
- Head Height [AASU]
- 0.1600 Inches Nominal
- Head Style [AASK]
- Flat
- Metallic Hardness Rating And Location [ASXJ]
- 30.0 Rockwell C Nominal Head Err-100
- Metallic Hardness Rating And Location [ASXJ]
- 30.0 Rockwell C Nominal Seat Face Err-100
- Metallic Hardness Rating And Location [ASXJ]
- 30.0 Rockwell C Nominal Stem Err-100
- Metallic Hardness Rating And Location [ASXJ]
- 50.0 Rockwell C Nominal Tip Err-100
- Minor Diameter Length [AGRA]
- 0.0940 Inches Nominal
- Minor Outside Diameter [ADNA]
- 0.1960 Inches Minimum And 0.2000 Inches Maximum
- Neck Radius [ALZB]
- 0.3200 Inches Nominal
- Outside Diameter [ABKV]
- 1.3270 Inches Minimum And 1.3370 Inches Maximum
- Material And Location [ANNQ]
- Steel,Fed Std 66,Sae 8645,Stem
- Material And Location [ANNQ]
- Steel,Fed Std 66,Sae Ev12,Head
- Seat Angle In Deg [AJFY]
- 45.0
- Stem Diameter [ALZE]
- 0.3090 Inches Minimum And 0.3095 Inches Maximum
- Stem Length [ALZD]
- 4.2350 Inches Minimum And 4.2430 Inches Maximum
- Stem Style [ALYX]
- Tapered
- Taper Angle In Deg [ABGK]
- 15.0
DLA Procurement Analysis 2805-00-357-5773
Management Data 2805-00-357-5773
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- 0
- Reversal Of Phrase Code Z 2805-00-678-1364
- 0
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- SU
- AF SICA RESIDUAL MMAC-OO-ALC
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- T
- Maintenance Float Secondary Non-depot Reparables
- Operational Test:
- No Special Procedures
Similar Supply Items to 2805-00-357-5773
Freight Information 2805-00-357-5773
2805-00-357-5773 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 133300. A Sub NMFC of Z. It has a NMFC Description of MACHINERY/MACHINES NOI. 2805-00-357-5773 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 63220 which rates the freight between FCL and LCL. 2805-00-357-5773 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 2805-00-357-5773 is not classified as a special type of cargo when transported by water. 2805-00-357-5773 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 2805-00-357-5773
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- MIL-PRF-21260, Preservative and Break-in Lubricating Oil, Internal Combustion Engine, Grade 10, 30 or 50
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Weather-Resistant, Corrugated Fiberboard Box
Contracting Technical Data File (CTDF) 2805-00-357-5773 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
