2805-00-346-5997
Internal Combustion Engine Piston
2805003465997 003465997 20119AS
May 2023
14
Marketplace 2805-00-346-5997
Request a Quotation from participating marketplace vendors
Related Documents 2805-00-346-5997 1+ Documents (More...)
RQST NE Updated Every Day 2805-00-346-5997 RQST Updated Every Day 2805-00-346-5997 RQST NE Related Documents
2805-00-346-5997 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-28/fsc-2805/us 2805-00-346-5997
Restrictions 2805-00-346-5997
2805-00-346-5997 is a Internal Combustion Engine Piston that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 2805-00-346-5997
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2805-00-346-5997
- Thailand (YY01)
- Effective Date:
- 1 Feb 2015
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 2805-00-346-5997
- Part Number
- Manufacturer
- Status
- 20119AS
- Manufacturer
- 1ML14 - Brinkley Technology Group Llc (Active)
- Primary Buy
- Primary Buy
- 20119AS
- 28265 - Hercules Engine Co Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 2805-00-346-5997
- Characteristic
- Specifications
- FIIG
- Specifications
- T267-C
- Distance From Pin Hole Center To Extreme Top [AXPK]
- 2.235 Inches Nominal
- Carbon Groove [BQBL]
- Not Included
- Diameter [ABMZ]
- 4.238 Inches Nominal
- Distance Between Pin Bosses [AXPM]
- 1.250 Inches Nominal
- Finished Size Designation [AXFR]
- Standard
- Head Style [AASK]
- Flat
- Material [MATT]
- Aluminum Alloy
- Oil Groove [AXPH]
- Not Included
- Oil Passage Type [ACXM]
- Hole And Slot
- Retaining Ring Groove [AXPN]
- Not Included
- Ring Groove Quantity [AXFZ]
- 3
- Ring Groove Width [AXGB]
- 0.1000 Inches Nominal And 0.1300 Inches Nominal And 0.1920 Inches Nominal
- Ring Groove Diameter [AXGD]
- 3.817 Inches Nominal
- Ring [AXPR]
- Not Included
- Skirt Bottom Cutaway Feature [AXFX]
- Not Included
- Skirt Slot Style [CXSP]
- Hangman Slot
- Skirt Type [AXFT]
- Solid
- Overall Height [ABKW]
- 4.000 Inches Nominal
- Pin Hole Bushing [AXPL]
- Not Included
- Pin Type For Which Designed [AXPQ]
- Floating
- Pinhole Diameter [ACXU]
- 1.1120 Inches Nominal
- Pin [AXPP]
- Included
- Ring Groove Position [AXGA]
- Unable To Decode
- Weight [WGHT]
- 35.0 Ounces
- Surface Finish [AGYE]
- Finished
NATO Stock Numbers Related to 2805-00-346-5997
Freight Information 2805-00-346-5997
2805-00-346-5997 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 133300. A Sub NMFC of Z. It has a NMFC Description of MACHINERY/MACHINES NOI. 2805-00-346-5997 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 63220 which rates the freight between FCL and LCL. 2805-00-346-5997 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 2805-00-346-5997 is not classified as a special type of cargo when transported by water. 2805-00-346-5997 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 2805-00-346-5997
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- MIL-PRF-21260, Preservative and Break-in Lubricating Oil, Internal Combustion Engine, Grade 10, 30 or 50
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Weather-Resistant, Corrugated Fiberboard Box
