2530-01-201-4816

Solid Rubber Tire M1 Abrams Wheel

2530012014816 012014816 12324548 2520012014816

A wheel with an integral or removable rim having or designed to mount a solid rubber tire. View more Solid Rubber Tire Wheel

Managed by United States

NSN Created on 19 Feb 1985

Data Last Changed
March 2025

NATO Update Count
15

NATO Data Quality

2530-01-201-4816 WHEEL,SOLID RUBBER TIRE M1 ABRAMS 2530012014816 012014816 1/1 — 2530-01-201-4816 Photo 1/1

Marketplace 2530-01-201-4816

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

2530-01-201-4816 WHEEL,SOLID RUBBER TIRE M1 ABRAMS 7 EA NS

Updated Every Day

2530-01-201-4816 RQST NE

Restrictions 2530-01-201-4816

2530-01-201-4816 is a Solid Rubber Tire M1 Abrams Wheel Demilitarization of this item has been confirmed and is not currently subject to changes. The Demilitarization Program Office (DDPO) will provide instructions for demilitarization of this item. This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.

Import and Export 2530-01-201-4816

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 2530-01-201-4816

US Army (A202)
Effective Date:: 1 Apr 1991; AMC 1 AMSC G AMSC A IMC E IMCACTY AZ DSOR AI

US Marine Corps (MA5T)
Effective Date:: 1 Dec 1995; AMC 1 AMSC G AMSC 5 IMC E DSOR AI

Morocco (YP01)
Effective Date:: 1 Apr 2016

Australia (ZA01)
Effective Date:: 1 Dec 2005

Approved Sources 2530-01-201-4816

Part Number
Manufacturer
Status
12324548: 19207 - U S Army Tank Automotive Command (Active); Primary Buy; RNCC 3 RNVC 2 DAC 1
12324548: B1478 - Varec Nv (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 1
2520012014816: A00AM - E.C.A Etablissement Central Des (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
2530012014816: A00AM - E.C.A Etablissement Central Des (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9

Datasheet 2530-01-201-4816

Characteristic
Specifications
FIIG: T307-T
Design Type [APGF]: Solid Cast Disk
Hub Cap Mounting Feature [CFHW]: Not Included
Hub Characteristic [CFJH]: Integral
Material [MATT]: Rubber
Integral Rim Type [CFJM]: Concave Lug Base
Load Capacity [ALDK]: 6200.0 Pounds Nominal
Rim Characteristic [CFJK]: Integral
Rim [ATGL]: Included
Size Designator [AJXE]: 6
Tire Arrangement Characteristic [CHSQ]: Single
Tire Characteristic [CHSP]: Demountable
Tire Type [ALRE]: Round Solid, Crowned Tread
Tire [CFHR]: Included
Tread Pattern [AAGC]: Smooth Tread

Management Data 2530-01-201-4816

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Nov 2022: US Marine Corps (DM); EA; Subscribe; 1
Oct 2022: Department of the Army (DA); EA; Subscribe; 1
Oct 2021: Department of the Army (DA); EA; Subscribe; 1
Nov 2020: Department of the Army (DA); EA; Subscribe; 1
Oct 2020: US Marine Corps (DM); EA; Subscribe; 1
Nov 2019: Department of the Army (DA); EA; Subscribe; 1
Oct 2019: US Marine Corps (DM); EA; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
Department of the Army (DA): L; R; Refer To Net Price 785.00; NET PRICE 785.00

Army

Materiel Category and Inventory Manager:

K: Tactical and Support Vehicles, Combat and Automotive Materiel

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

1: Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.

Weapons System / End Item / Homogeneous Group:

LN: Other Weapons Categories
Track and Road Wheels

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Marine Corps

Stores Account:

2: Appropriation Stores Account Secondary Item

Combat Essentiality:

5: Critical Repair Part to a Combat Essential End Item

Echelon Management:

22

Operational Test:

: No Special Procedures

Physical Category:

1: Bin

Similar Supply Items to 2530-01-201-4816

Freight Information 2530-01-201-4816

2530-01-201-4816 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 197592. A Sub NMFC of Z. It has a NMFC Description of WHEELS NOI. 2530-01-201-4816 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 96684 which rates the freight between FCL and LCL. 2530-01-201-4816 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 586 for ocean manifesting and military sealift. 2530-01-201-4816 is not classified as a special type of cargo when transported by water. 2530-01-201-4816 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 2530-01-201-4816

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); Packaging Data does not meet current MIL-STD-2073-1E

Storage Environment: Unheated General Purpose

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: 25.0" H x 25.0" W x 8.0" L; --; --; Over 10lb; Less than 85G; Special Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; 25.0" H x 25.0" W x 8.0" L; --; --; --; Special Requirements

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: Special Requirement; Special Requirements – see Specific Instructions or Drawings provided; Special Requirements. See Specific Instructions or Drawings Provided; Special Requirements. See Specific Instructions or Drawings Provided; Special requirement – See specific instructions or drawings provided; --

Intermediate Pack Level

Quantity of Unit Packs
Container: --
