2530-01-102-4532

Vehicular Track Roller Assembly

2530011024532 011024532 12291954 10094599

A cylindrical metallic body of either solid or hollow construction, containing bearings and/or shafts and the like which provides the rolling elements to guide and support a track-type vehicle along its track. View more Vehicular Track Roller Assembly

Managed by United States

NSN Created on 22 Oct 1980

Data Last Changed
November 2023

NATO Update Count
32

NATO Data Quality

2530-01-102-4532 ROLLER ASSEMBLY,TRACK,VEHICULAR 2530011024532 011024532 1/1 — NSN 2530-01-102-4532 (Generic Image) 1/1

Marketplace 2530-01-102-4532

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

12291954 ROLLER ASSEMBLY,TRACK,VEHICULAR RQST NS

Updated Every Day

2530-01-102-4532 RQST NE

Restrictions 2530-01-102-4532

2530-01-102-4532 is a Vehicular Track Roller Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.

Import and Export 2530-01-102-4532

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 2530-01-102-4532

US Army (A920)
Effective Date:: 1 Aug 2006
Former MOE Rule:: A181
Supplementary Receivers:: AZ; AMC 1 AMSC G IMC Z IMCACTY AZ

US Air Force (FXGC)
Effective Date:: 1 Aug 2006
Former MOE Rule:: FXAX; AMC 1 AMSC G IMC Z IMCACTY SX

US Marine Corps (MC40)
Effective Date:: 1 Aug 2006
Former MOE Rule:: MC01; AMC 1 AMSC G IMC Z IMCACTY PA

US Navy (N9BC)
Effective Date:: 1 Dec 2013
Supplementary Collaborators:: GGGT; AMC 1 AMSC G IMC Z IMCACTY GH

Finland (WF01)
Effective Date:: 1 Feb 2008

Singapore (YJ01)
Effective Date:: 1 Sep 2003

France (ZF01)
Effective Date:: 1 Apr 1991

Germany (ZG01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Aug 1998

United Kingdom (ZK01)
Effective Date:: 1 Nov 2010

Italy (ZR01)
Effective Date:: 1 Apr 1991

Denmark (ZS01)
Effective Date:: 1 Sep 1997

Norway (ZT01)
Effective Date:: 1 Feb 1997

Greece (ZU01)
Effective Date:: 1 May 2006

Turkey (ZW01)
Effective Date:: 1 Dec 2005

NATO Maintenance and Supply Agency (ZX01)
Effective Date:: 1 Apr 1991

Approved Sources 2530-01-102-4532

Part Number
Manufacturer
Status
12291954: 19207 - U S Army Tank Automotive Command (Active); Primary Buy; RNCC 3 RNVC 2 MEDALS DAC D
12291954: A9271 - Goriziane Group Spa (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
10094599: A486G - Nimikkeistokeskus Ncb Finland (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9

Datasheet 2530-01-102-4532

Characteristic
Specifications
FIIG: A518B0
Material [MATT]: Steel
Special Features [FEAT]: 19.970 In.Min,20.030 In.Max Od Dia;3.690 In.Wide;12 Mounting Holes 0.654 In.Min,0.702 In.Max Dia;Center Hole 7.687 In.Min,7.693 In.Max Dia;Material Hardness Rating:45.0 To 55.0 Rockwell C

Weapon Systems (WSDC) 2530-01-102-4532

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 2530-01-102-4532

Last Stock Position:: 8 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 2530-01-102-4532

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Navy (DN); EA; Subscribe; 1
Oct 2021: Department of the Air Force (DF); EA; Subscribe; 1
Apr 2021: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2020: US Marine Corps (DM); EA; Subscribe; 1
Oct 2019: Department of the Army (DA); EA; Subscribe; 1

Army

Materiel Category and Inventory Manager:

J: Ground Forces Support Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

MM: Armored Carriers
Infantry Fighting Vehicle (M2, M2A1, M2A2), Cavalry Fighting Vehicle (M3, M3A1, M3A2)

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Air Force

Fund:

SF: Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point

Budget:

9: 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors

Price Validation Code:

N: The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

5: Critical Repair Part to a Combat Essential End Item

Echelon Management:

B2

Operational Test:

: No Special Procedures

NATO Stock Numbers Related to 2530-01-102-4532

2530-15-180-6792 2530-14-466-0491 2530-16-003-3828 2530-14-538-7749 2530-12-385-1126 2530-27-046-4237 2530-99-242-9595 2530-15-170-3176 2530-27-043-7764 2530-15-170-9186 2530-99-403-3052 2530-01-557-9632 2530-01-618-9013 2530-00-628-0571 2530-01-475-9967 2530-01-558-8405 2530-01-584-3267 2530-01-582-7174

Freight Information 2530-01-102-4532

2530-01-102-4532 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 018870. A Sub NMFC of X. It has a NMFC Description of AUTO HUBS I/S. 2530-01-102-4532 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 08780 which rates the freight between FCL and LCL. 2530-01-102-4532 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 585 for ocean manifesting and military sealift. 2530-01-102-4532 is not classified as a special type of cargo when transported by water. 2530-01-102-4532 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 2530-01-102-4532

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Bare Metal Item; Over 10lb; Less than 85G; Special Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; 22.0" H x -- W x -- L; --; --; Preservative Coating Only; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: --; --; ASTM-D4727, Fiberboard used as Pads, Cells, Die-cuts or Sleeves; --; ASTM - D5118, Fiberboard Box; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: --; No Requirement

Procurement History 2530-01-102-4532 Most Recent 51 Records
