2530-00-880-8254
Steering Tie Rod
2530008808254 008808254 B06061075
An item designed to form a connection or link, either direct or indirectly between the steering knuckle arms. It is used to maintain alignment of the wheels and to facilitate steering of the vehicle. See also DRAG LINK, STEERING. View more Steering Tie Rod
May 2023
4
Marketplace 2530-00-880-8254
Request a Quotation from participating marketplace vendors
Related Documents 2530-00-880-8254 4+ Documents (More...)
B06061075 TIE ROD 3 EA NS Request Quotation B06061075 TIE ROD 3 EA NS Request Quotation Subscribe to
BUY NE FedMall Updated Every Day 2530-00-880-8254 RQST NE Updated Every Day 2530-00-880-8254 RQST
| EDC: | ADPEC : 2530-00-891-6682 is a Steering https//www.nsnlookup.com /fsg-25/fsc-2530/us 2530-00-880-8254
Steering Tie Rod 2530008808254 008808254 TIE ROD 3 EA NS Request Quotation Subscribe to https//
Restrictions 2530-00-880-8254
2530-00-880-8254 is a Steering Tie Rod that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 2530-00-880-8254
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2530-00-880-8254
- US Air Force (FGGC)
- Effective Date:
- 1 Sep 2005
- Former MOE Rule:
- FGAX
Approved Sources 2530-00-880-8254
- Part Number
- Manufacturer
- Status
- B06061075
- Manufacturer
- 09605 - Bomag Usa (Obsolete)
- Original Design
- Original Design
Datasheet 2530-00-880-8254
- Characteristic
- Specifications
- FIIG
- Specifications
- T307-M
- End Connection Type [AWZY]
- Plain Threaded
- Bend Quantity [CFCR]
- 6
- Body Diameter [ABPM]
- 1.500 Inches Nominal
- Construction [ARQS]
- Solid
- Material [MATT]
- Steel Corrosion Resisting
- Metallic Hardness Rating [AETC]
- 38.0 Minimum Rockwell C And 43.0 Maximum Rockwell C
- Rod End Lock Clamp [CFDF]
- Not Included
- Screw Thread Series Designator [AJYP]
- Unf
- Shape [SHPE]
- Bent
- Overall Length [ABHP]
- 34.000 Inches Nominal
- Thread Direction [AAJF]
- Right-Hand
- Thread Length [AASA]
- 3.000 Inches Nominal
- Thread Location [APJC]
- External
- Thread Size [ABUJ]
- 1-1/8-12
Weapon Systems (WSDC) 2530-00-880-8254
DLA Procurement Analysis 2530-00-880-8254
Management Data 2530-00-880-8254
Similar Supply Items to 2530-00-880-8254
Freight Information 2530-00-880-8254
2530-00-880-8254 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 126560. A Sub NMFC of X. It has a NMFC Description of PILE DRIVERS/EXTRACTORS/PULLERS ETC. 2530-00-880-8254 is rated as class 65 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 64190 which rates the freight between FCL and LCL. 2530-00-880-8254 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 585 for ocean manifesting and military sealift. 2530-00-880-8254 is not classified as a special type of cargo when transported by water. 2530-00-880-8254 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 2530-00-880-8254
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- MIL-PRF-21260, Preservative and Break-in Lubricating Oil, Internal Combustion Engine, Grade 10, 30 or 50
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Weather-Resistant, Corrugated Fiberboard Box
Contracting Technical Data File (CTDF) 2530-00-880-8254 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
