2530-00-741-1070
Master Hydraulic Brake Cylinder Assembly
2530007411070 007411070 F112398 F55883 90-F55883 90-FF14130 101199R91 12356931 FF14130E0 105878 E105878 KC6080 7411070
A device consisting of a reservoir and/or CYLINDER, HYDRAULIC BRAKE, MASTER with other components necessary to displace fluid from a central source for actuating the slave or wheel cylinders of a hydraulic brake system. View more Master Hydraulic Brake Cylinder Assembly
Managed by United States
NSN Created on 1 Jan 1961
Data Last Changed
October 2025
October 2025
NATO Update Count
60
60
NATO Data Quality
Marketplace 2530-00-741-1070
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Updated 57 Days Ago
12356931 CYLINDER 1 EA SV
12356931 CYLINDER 3 EA NS
12356931 CYLINDER 6 EA NS
F112398 CYLINDER 1 EA AR
F112398 MASTER CYLINDER 4 EA NS
F55883 CYLINDER ASSEMBLY 2 EA NS
7411070 CYLINDER ASSEMBLY,HYDRAULIC BRAKE,MASTER 2 EA NS
2530-00-741-1070 CYLINDER ASSEMBLY,HYDRAULIC BRAKE,MASTER 3 EA NS
1549159 CYLINDER ASSEMBLY,HYDRAULIC BRAKE,MASTER 37 EA NS
007411070.2530 CYLINDER ASSEMBLY,HYDRAULIC BRAKE,MASTER 1 EA NS
101199R91 RQST NE
Updated Every Day 2530-00-741-1070 RQST NE
Updated Every Day 2530-00-741-1070 RQST
Updated Every Day 2530-00-741-1070 RQST NE
Related Documents 2530-00-741-1070 5+ Documents (More...)
F112398 F55883 90-F55883 90-FF14130 101199R91 12356931 FF14130E0 105878 E105878 KC6080 7411070 A device
12356931 CYLINDER 6 EA NS Request Quotation F112398 CYLINDER 1 EA AR Request Quotation F112398 MASTER
... 7411070 CYLINDER ASSEMBLY,HYDRAULIC BRAKE,MASTER 2 EA NS Request Quotation 2530-00-741-1070 CYLINDER
12356931 CYLINDER 6 EA NS Request Quotation F112398 CYLINDER 1 EA AR Request Quotation F112398 MASTER
... 7411070 CYLINDER ASSEMBLY,HYDRAULIC BRAKE,MASTER 2 EA NS Request Quotation 2530-00-741-1070 CYLINDER
105878 Motor Rotor 6105143820936 143820936,105878 how to enable JavaScript in your web browser . 6105
Windshield Wiper Blade 2540123225356,105878 382-0936Motor Rotor6105143820936 143820936 105878 https
https//www.nsnlookup.com /fsg-25/fsc-2530/us 2530-00-741-1070 Master Hydraulic Brake Cylinder Assembly
Windshield Wiper Blade 2540123225356,105878 382-0936Motor Rotor6105143820936 143820936 105878 https
https//www.nsnlookup.com /fsg-25/fsc-2530/us 2530-00-741-1070 Master Hydraulic Brake Cylinder Assembly
Request a Quotation from participating marketplace vendors Request Subscribe to View Vendor Details... 105878
GEAR,SPUR 32 EA NS Request Quotation Subscribe to View Vendor Details... 105878 GEAR,SPUR 5 EA NS Request
from participating marketplace vendors Request https//www.nsnlookup.com /fsg-25/fsc-2530/us 2530-00-741-1070
GEAR,SPUR 32 EA NS Request Quotation Subscribe to View Vendor Details... 105878 GEAR,SPUR 5 EA NS Request
from participating marketplace vendors Request https//www.nsnlookup.com /fsg-25/fsc-2530/us 2530-00-741-1070
how to enable JavaScript in your web browser . 6105-14-382-0936Motor Rotor6105143820936 143820936 105878
A rotor which Motor Rotor 6105143820936 143820936,105878 105878 enable JavaScript Motor Rotor 6105143820936
143820936,105878 105878 enable JavaScript in your Motor Rotor 6105143820936 143820936,105878 105878
A rotor which Motor Rotor 6105143820936 143820936,105878 105878 enable JavaScript Motor Rotor 6105143820936
143820936,105878 105878 enable JavaScript in your Motor Rotor 6105143820936 143820936,105878 105878
$1 a day Upgrade your Account Upgrade 1650-00-934-8456Hydra Servo Housing1650009348456 009348456 105878
HOUSING,SERVO,HYDRA 14 EA NS Request Quotation Subscribe to View Vendor Details... 105878 HOUSING,SERVO
how to enable JavaScript in your web browser . 6105-14-382-0936Motor Rotor6105143820936 143820936 105878
HOUSING,SERVO,HYDRA 14 EA NS Request Quotation Subscribe to View Vendor Details... 105878 HOUSING,SERVO
how to enable JavaScript in your web browser . 6105-14-382-0936Motor Rotor6105143820936 143820936 105878
Restrictions 2530-00-741-1070
2530-00-741-1070 is a Master Hydraulic Brake Cylinder Assembly that does not have a nuclear hardened feature, but does have another critical feature or features such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 2530-00-741-1070
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2530-00-741-1070
- US Army (A920)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZBS
- US Air Force (FGGC)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- FGAX
- US Marine Corps (MC40)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- MC01
- US Navy (N9BC)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GTHD
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Brazil (YA01)
- Effective Date:
- 1 Dec 2001
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Israel (YD01)
- Effective Date:
- 1 Jul 2016
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Kuwait (YK01)
- Effective Date:
- 1 Feb 2015
- Morocco (YP01)
- Effective Date:
- 1 Jun 2010
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 May 2015
- Germany (ZG01)
- Effective Date:
- 1 Sep 1993
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Apr 2002
Approved Sources 2530-00-741-1070
- Part Number
- Manufacturer
- Status
- F112398
- Manufacturer
- 63477 - Federal Mogul Corp (Active)
- Primary Buy
- Primary Buy
- F55883
- 63477 - Federal Mogul Corp (Active)
- Secondary Buy
- Secondary Buy
- 90-F55883
- 3NNX8 - Brighton Cromwell Llc (Active)
- Secondary Buy
- Secondary Buy
- 90-FF14130
- 3NNX8 - Brighton Cromwell Llc (Active)
- Secondary Buy
- Secondary Buy
- 101199R91
- 89346 - Navistar Intl Corp Truck Br Ohio (Active)
- Secondary Buy
- Secondary Buy
- 12356931
- 19207 - U S Army Tank Automotive Command (Active)
- Secondary Buy
- Secondary Buy
- FF14130E0
- 63477 - Federal Mogul Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 90-FF14130
- 52993 - Ar Bee Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 105878
- 80724 - Eis Brake Parts Div Of Standard (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- E105878
- 80724 - Eis Brake Parts Div Of Standard (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 101199R91
- 31007 - Navistar International Corporation (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 90-FF14130
- 16662 - Lift Parts Mfg Co Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 2530007411070
- SCY13 - E.C.A Etablissement (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 90-F55883
- 52993 - Ar Bee Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- KC6080
- 56442 - Diamond Reo Truck Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 7411070
- 19207 - U S Army Tank Automotive Command (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 2530007411070
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
Datasheet 2530-00-741-1070
- Characteristic
- Specifications
- FIIG
- Specifications
- A34200
- Actuation Method [AFLW]
- Direct
- Bleeding Feature Quantity [CLND]
- 1
- Body Material [AAFZ]
- Any Acceptable
- Compressed Length [AMQZ]
- 10.688 Inches Nominal
- Criticality Code Justification [CRTL]
- Feat
- Extended Length [ATEM]
- 13.188 Inches Nominal
- Features Provided [CBBL]
- Filler Plug And Rubber Boot
- First Piston Rod End Thread Diameter [CKSH]
- 0.562 Inches Nominal
- First Piston Rod End Thread Class [CKSK]
- 2B
- First Piston Rod End Thread Direction [CKSL]
- Right-Hand
- First Piston Rod End Thread Series Designator [CKSG]
- Unf
- First Piston Rod End Thread Quantity Per Inch [CKSJ]
- 18
- Mounting Facility Diameter [CLMQ]
- 0.406 Inches Nominal
- Mounting Provision Arrangement Style [BBBW]
- Four Hole Rectangular
- Mounting Provision [ABDR]
- Unthreaded Mounting Holes
- Mounting Type And Location [CLML]
- Flange Piston Rod End
- End Item Identification [AGAV]
- Truck,Cargo,Dropside,5-Ton,6X6;Truck,Cargo,5-Ton,6X6,Xlwb W/E;Truck,Dump,5-Ton,6X6;Shipboard Material Handling Equipment (Mhe)
- Longest Horizontal Distance Between Mounting Centers [AFDS]
- 2.500 Inches Nominal
- Longest Vertical Distance Between Mounting Centers [AFDV]
- 2.406 Inches Nominal
- Port Location And Quantity [CLMS]
- 2 Cylinder Head End
- Port Style [CLMT]
- Gasket Seal
- Port Thread Class [CLNB]
- 2B
- Port Thread Diameter [CLMX]
- 0.500 Inches Nominal
- Port Thread Quantity Per Inch [CLMY]
- 20
- Port Thread Series Designator [CLMW]
- Unf
- Overall Height [ABKW]
- 6.000 Inches Nominal
- Overall Width [ABMK]
- 3.500 Inches Nominal
- Special Features [FEAT]
- Piston Rod End Thd Female Style,1.000 In. Deep Thd;Weapon System Essential
- Stoplight Switch Nominal Pipe Thread Size [CLNM]
- 0.125 Inches
- Stoplight Switch Thread Quantity Per Inch [CLNK]
- 27
- Straight Bore Inside Diameter [BYXG]
- 1.750 Inches Nominal
DLA Procurement Analysis 2530-00-741-1070
- Last Stock Position:
- 1 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 2530-00-741-1070
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Feb 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Army (DA)
- A
- V
- Discontinued Without Replacement
- V
- Defense Logistics Agency (DS)
- I
- V
- Discontinued Without Replacement
- V
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- NL
- Tactical Vehicles
5 Ton Vehicle Configuration, Diesel
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 3B
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- T
- Maintenance Float Secondary Non-depot Reparables
- Operational Test:
- No Special Procedures
Similar Supply Items to 2530-00-741-1070
Freight Information 2530-00-741-1070
2530-00-741-1070 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 018400. A Sub NMFC of X. It has a NMFC Description of AUTO BRAKES/SHOES R PADS ETC. 2530-00-741-1070 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 08480 which rates the freight between FCL and LCL. 2530-00-741-1070 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 585 for ocean manifesting and military sealift. 2530-00-741-1070 is not classified as a special type of cargo when transported by water. 2530-00-741-1070 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 2530-00-741-1070
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Contracting Technical Data File (CTDF) 2530-00-741-1070 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
