2520-01-198-0495
Output Oil Pump
2520011980495 011980495 23018062
March 2025
14
Marketplace 2520-01-198-0495
Request a Quotation from participating marketplace vendors
Related Documents 2520-01-198-0495 1+ Documents (More...)
Count 14 NATO Data Quality 2520-01-198-0495 Photo 1/1 1.
United States (US) 4. 2520-01-198-0495 Marketplace Restrictions Approved Sources Datasheet Management
Restrictions 2520-01-198-0495
2520-01-198-0495 is a Output Oil Pump The DCMO has forced the Demilization requirements for this item as the ICP has not collaborated. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 2520-01-198-0495
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2520-01-198-0495
- US Army (A202)
- Effective Date:
- 1 Apr 1991
- Lithuania (WI01)
- Effective Date:
- 1 May 2001
- Canada (ZC01)
- Effective Date:
- 1 Jun 2006
- Republic of Korea (ZH01)
- Effective Date:
- 1 Jan 2005
- Turkey (ZW01)
- Effective Date:
- 1 Oct 2001
Approved Sources 2520-01-198-0495
- Part Number
- Manufacturer
- Status
- 23018062
- Manufacturer
- 73342 - Allison Transmission Inc (Active)
- Primary Buy
- Primary Buy
Datasheet 2520-01-198-0495
- Characteristic
- Specifications
- FIIG
- Specifications
- A23900
- General Characteristics Item Description [TEXT]
- Consist Of:1Ea.Bolt,Cage 24617,Pn 9409224;6Ea.Washer,Cage 24617,Pn 9422846;1Ea.Cover Assembly,Cage 73342,Pn 23018067;1Ea.Gear,Cage 73342,Pn 23018066;1Ea.Nut,Cage 19207,Pn 11649930;1Ea.Key,Cage 24617,Pn 427261;1Ea.Gear,Cage 73342,Pn23018070;1Ea.Gear,Cage 73342,Pn 23018065;5Ea.Bolt,Cage 24617,Pn 9409225;Direction Of Rotation Counter Clockwise,Drawing No.23018062,Cage 73342
- End Item Identification [AGAV]
- 2520012014784
Management Data 2520-01-198-0495
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Army (DA)
- L
- R
- Refer To Net Price 2442.00
- NET PRICE 2442.00
- R
Army
- Materiel Category and Inventory Manager:
- K
- Tactical and Support Vehicles, Combat and Automotive Materiel
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- M5
- Armored Carriers
M113 Family of Vehicles, Block 1 Modification
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
NATO Stock Numbers Related to 2520-01-198-0495
Freight Information 2520-01-198-0495
2520-01-198-0495 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 132330. A Sub NMFC of X. It has a NMFC Description of TRANSMISSIONS/CLUTCHES/PARTS,NOI. 2520-01-198-0495 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. 2520-01-198-0495 is rated as class 85 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 64340 which rates the freight between FCL and LCL. 2520-01-198-0495 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 586 for ocean manifesting and military sealift. 2520-01-198-0495 is not classified as a special type of cargo when transported by water. 2520-01-198-0495 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 2520-01-198-0495
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- 8.5" H x 7.7" W x 4.1" L
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 10.5" H x 8.8" W x 5.2" L
- --
- --
- --
- Special Requirements
- 10.5" H x 8.8" W x 5.2" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- MIL-PRF-32033, Lubricating Oil, General Purpose Preservative (Water Displacing, Low Temperature)
- MIL-PRF-121, Type II, Light Duty, Greaseproof, Waterproof Barrier
- A-A-1051, Paperboard Cushioning
- Not Applicable
- ASTM-D5118, Type CF, Class Weather-Resistant, Corrugated Fiberboard Box
- No special marking
- MIL-PRF-121, Type II, Light Duty, Greaseproof, Waterproof Barrier
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- --
