2520-01-120-2169
Vehicular Tx100-1 M113a2 Hydraulic Transmission
2520011202169 011202169 8355951-1 23014434
A device used on vehicular power transmission components to increase torque and/or change ratios between the drive and driven shaft or shafts by the medium of liquid under pressure within the unit. It may include a manual means for reversing rotation and changing speed ranges. Excludes TRANSMISSION, CROSS-DRIVE; and transmissions with controlled differentials. View more Vehicular Hydraulic Transmission
February 2025
37
Product Information 2520-01-120-2169
M113A2 Transmission
Model: Allison Transmission TX100-1
The TX100-1 Automatic Transmission was developed by Allison Transmission for use in the M113 Family of Vehicles and its variants M113A1 and M113A2. The TX100-1 transmission is rated for up to 215 Gross Input Horsepower (GHP) (160 kW) in a vehicle weighing up to 13 tons with up to 3600 RPM input shaft speed.
This TX100-1 Transmission is fitted with a 7C Output Shaft Yoke.
