2520-01-082-7390
Vehicular Clutch Disk
2520010827390 010827390 6Y7951 308732 9N1655
A solid circular disk of wire-woven lining material or ceramic and metal substance and the like, molded to one or both sides and fastened directly or indirectly to the center spline or hub, which receives and transmits motion or power by engagement with the pressure plate assembly and the flywheel or the like. Includes dry or wet type disk, and may include damper springs. This item is designed to be used on tanks, automobiles, construction equipment, and the like in conjunction with a CLUTCH ASSEMBLY, FRICTION. View more Vehicular Clutch Disk
June 2023
6
Marketplace 2520-01-082-7390
Request a Quotation from participating marketplace vendors
Related Documents 2520-01-082-7390 4+ Documents (More...)
BUY NE FedMall Updated Every Day 2520-01-082-7390 RQST NE Updated Every Day 2520-01-082-7390 RQST
Updated Every Day 2520-01-082-7390 RQST NE Related Documents 2520-01-082-7390 3+ Documents ( More...
www.nsnlookup.com /fsg-29/fsc-2915/uk 2915-99-939-2988 Ma Throttle Control 2915999392988999392988 308732
day Upgrade your Account Upgrade 4810-01-462-5478Solenoid Valve Parts Kit4810014625478 014625478 308732
/fsg-48/fsc-4810/us
day Upgrade your Account Upgrade 4810-01-462-5478Solenoid Valve Parts Kit4810014625478 014625478 308732
Vehicular Clutch Disk 2520010827390 010827390 2915999392988999392988 308732 day Upgrade your Account
Restrictions 2520-01-082-7390
2520-01-082-7390 is a Vehicular Clutch Disk that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 2520-01-082-7390
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2520-01-082-7390
- US Army (A920)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZ
- US Navy (N9BC)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
Approved Sources 2520-01-082-7390
- Part Number
- Manufacturer
- Status
- 6Y7951
- Manufacturer
- 11083 - Caterpillar Inc (Active)
- Primary Buy
- Primary Buy
- 308732
- 1HQE5 - Alto Products Corp. Al (Active)
- Secondary Buy
- Secondary Buy
- 9N1655
- 11083 - Caterpillar Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 2520-01-082-7390
- Characteristic
- Specifications
- FIIG
- Specifications
- A521P0
- Design Type [APGF]
- Wet
- Flexibility [FLEX]
- Rigid
- Disk Type [BPLM]
- Internal Teeth
- Construction [CQCF]
- Solid
- Outside Diameter [ABHE]
- 9.352 Inches Nominal
- Teeth Quantity Per Disk [BSQC]
- 128
- Features Provided [CBBL]
- Material Facing Groove
- Special Features [FEAT]
- This Item Has Been Reviewed For Asbestos Material. The Current Approved Sources 11083 Have Indicated Their Part Number Contained Asbestos Prior To 1984. They Continue To Manufacture The Same Part Number Without Asbestos Material After 1984
Weapon Systems (WSDC) 2520-01-082-7390
DLA Procurement Analysis 2520-01-082-7390
Management Data 2520-01-082-7390
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Navy (DN)
- N
- R
- Refer To 1 Previously Contain
- 1 PREVIOUSLY CONTAIN
- R
- Department of the Navy (DN)
- N
- R
- Refer To 2 Ed Asbestos,See Su
- 2 ED ASBESTOS,SEE SU
- R
- Department of the Navy (DN)
- N
- R
- Refer To 3 Pplementary Featur
- 3 PPLEMENTARY FEATUR
- R
- Department of the Navy (DN)
- N
- R
- Refer To 4 Es
- 4 ES
- R
- Defense Logistics Agency (DS)
- I
- R
- Refer To 1 Previously Contain
- 1 PREVIOUSLY CONTAIN
- R
- Defense Logistics Agency (DS)
- I
- R
- Refer To 2 Ed Asbestos,See Su
- 2 ED ASBESTOS,SEE SU
- R
- Defense Logistics Agency (DS)
- I
- R
- Refer To 3 Pplementary Featur
- 3 PPLEMENTARY FEATUR
- R
- Defense Logistics Agency (DS)
- I
- R
- Refer To 4 Es
- 4 ES
- R
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 2520-01-082-7390
Freight Information 2520-01-082-7390
2520-01-082-7390 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 126840. A Sub NMFC of X. It has a NMFC Description of POWER TRANS BELT CLAMPS,GUIDES ETC. 2520-01-082-7390 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 64280 which rates the freight between FCL and LCL. 2520-01-082-7390 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 586 for ocean manifesting and military sealift. 2520-01-082-7390 is not classified as a special type of cargo when transported by water. 2520-01-082-7390 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 2520-01-082-7390
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Vendor's Protective Grease or Oil Coating
- --
- --
- --
- ASTM - D5118, Fiberboard Box
- Asbestos Warning Label
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Contracting Technical Data File (CTDF) 2520-01-082-7390 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
