2520-00-446-2486
Friction Clutch Assembly
2520004462486 004462486 8351182 MPC4911 MPC2025
A spring loaded device designed to connect and disconnect power between a driving device (engine, motor, and the like) and a driven member (transmission and the like). It may be of wet or dry design. Includes cover, and may include intermediate plates, and/or DISK, CLUTCH. View more Friction Clutch Assembly
November 2023
24
Marketplace 2520-00-446-2486
Request a Quotation from participating marketplace vendors
Related Documents 2520-00-446-2486 5+ Documents (More...)
/fsg-25/fsc-2520/us
Friction Clutch Assembly 2520004462486 https//www.nsnlookup.com /nato/nato-stock-numbers/inc Friction
Restrictions 2520-00-446-2486
2520-00-446-2486 is a Friction Clutch Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a US Munitions List Item and must be mutilated to scrap. This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 2520-00-446-2486
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2520-00-446-2486
- US Army (A920)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZ
- US Navy (N9BC)
- Effective Date:
- 1 Dec 2013
- Supplementary Collaborators:
- GG
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Feb 2013
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 2520-00-446-2486
- Part Number
- Manufacturer
- Status
- 8351182
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Source Control
- Source Control
- MPC4911
- 7R1P5 - Cmbf Products Inc (Active)
- Primary Buy
- Primary Buy
- 8351182
- 13475 - Friction Holdings, Llc (Active)
- Primary Buy
- Primary Buy
- 8351182
- 7R1P5 - Cmbf Products Inc (Active)
- Primary Buy
- Primary Buy
- MPC2025
- 79370 - The S K Wellman Corp (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- MPC4911
- 79370 - The S K Wellman Corp (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- MPC4911
- 9G780 - Friction Products Co. (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 2520-00-446-2486
- Characteristic
- Specifications
- FIIG
- Specifications
- A524Z0
- End Item Identification [AGAV]
- Transmission Model Xt-1410-2
- Special Features [FEAT]
- Steel,Carbon Comp 1065-1095;Facing Matl Sintered Bronze Wellman Spec No. 145E Or Raybestos W1349a;Internal Spline 5 Pitch Special,75 Teeth,Pressure Angle 45 Deg;Pitch Dia 15 In.;Root Dia 15.366/15.426 In.;Plate Thk 0.154/0.158 In.;Od 17.760/17.800 In.
Weapon Systems (WSDC) 2520-00-446-2486
DLA Procurement Analysis 2520-00-446-2486
- Last Stock Position:
- 306 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 2520-00-446-2486
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Jun 2014
- US Marine Corps (DM)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- V
- Discontinued W/O Replacement
- V
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- JT
- Tanks
Recovery Vehicle, M51/M74/M88
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 2520-00-446-2486
Freight Information 2520-00-446-2486
2520-00-446-2486 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 132330. A Sub NMFC of X. It has a NMFC Description of TRANSMISSIONS/CLUTCHES/PARTS,NOI. 2520-00-446-2486 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 64340 which rates the freight between FCL and LCL. 2520-00-446-2486 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 2520-00-446-2486 is not classified as a special type of cargo when transported by water. 2520-00-446-2486 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 2520-00-446-2486
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Procurement History 2520-00-446-2486 8 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE7L319P0965
- 01 Nov 2018
- Subscribe
- 268
- Subscribe
- Subscribe
- Subscribe
- SPE7L017P1281
- 12 Mar 2017
- Subscribe
- 95
- Subscribe
- Subscribe
- Subscribe
- SPE7L317P0964
- 16 Nov 2016
- Subscribe
- 138
- Subscribe
- Subscribe
- Subscribe
- SPE7L316M7557
- 08 Aug 2016
- Subscribe
- 151
- Subscribe
- Subscribe
- Subscribe
- SPE7L316M3711P00002
- 02 Mar 2016
- Subscribe
- 561
- Subscribe
- Subscribe
- Subscribe
- SPE7L316M0585
- 20 Oct 2015
- Subscribe
- 204
- Subscribe
- Subscribe
- Subscribe
- SPE7L315M8943
- 22 Sep 2015
- Subscribe
- 277
- Subscribe
- Subscribe
- Subscribe
- SPM7L214M0022
- 01 Oct 2013
- Subscribe
- 315
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 2520-00-446-2486 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- S
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
