2510-01-303-2933

Direct Action Shock Absorber

2510013032933 013032933 12361491 G-11018

A damper, either frictional or hydraulic, designed to dampen the shock of suddenly applied force and/or to control spring rebound and oscillation, usually attached to the vehicle frame, body or hull and connected to an axle, spring, spring support web or pad or between suspension arms of track-laying vehicles. See also MOUNT, RESILIENT and SHOCK ABSORBER, LEVER ACTION. View more Direct Action Shock Absorber

Managed by United States

NSN Created on 28 Jun 1989

Data Last Changed
November 2023

NATO Update Count
15

NATO Data Quality

BXYS Style 13 for 2510-01-303-2933 1/1 — NSN 2510-01-303-2933 (Identification) 1/1

Marketplace 2510-01-303-2933

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

2510-01-303-2933 SHOCK ABSORBER,DIRECT ACTION RQST NS

Updated Every Day

2510-01-303-2933 RQST NE

Updated Every Day

2510-01-303-2933 RQST

Updated Every Day

2510-01-303-2933 RQST NE

Restrictions 2510-01-303-2933

2510-01-303-2933 is a Direct Action Shock Absorber that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 2510-01-303-2933

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 2510-01-303-2933

US Army (A920)
Effective Date:: 1 Aug 2006
Former MOE Rule:: A181
Supplementary Receivers:: AZBF; AMC 1 AMSC G IMC Z IMCACTY AZ

Austria (WB01)
Effective Date:: 1 Feb 2005

Spain (YB01)
Effective Date:: 1 Feb 2010

Germany (ZG01)
Effective Date:: 1 Nov 1996

Norway (ZT01)
Effective Date:: 1 Feb 2005

Approved Sources 2510-01-303-2933

Part Number
Manufacturer
Status
12361491: 19207 - U S Army Tank Automotive Command (Active); Primary Buy; RNCC 3 RNVC 2 MEDALS DAC 1
G-11018: 1C852 - General Kinetics (Active); Obsolete Drawing; RNCC 7 RNVC 9 DAC 5
12361491: 06085 - Bae Systems Land & Armaments L.P. (Active); Advisory Reference; RNCC C RNVC 1 DAC 5
12361491: 076M6 - Bae Systems Land & Armaments L.P. (Active); Advisory Reference; RNCC C RNVC 1 DAC 5

Datasheet 2510-01-303-2933

Characteristic
Specifications
FIIG: A07200
Operation Method [APHE]: Hydraulic
Piston End Connection Style [BXYS]: Bearing
Piston End Nominal Inside Diameter [CXKS]: 2.534 Inches
Piston End Nominal Outside Diameter [CXLB]: 3.500 Inches
Piston End Nominal Thickness [CXLF]: 1.540 Inches
Cylinder End Connection Style [BYBF]: Bearing
Cylinder End Nominal Inside Diameter [CXNW]: 2.534 Inches
Cylinder End Nominal Outside Diameter [CXPG]: 3.500 Inches
Cylinder End Nominal Thickness [CXPM]: 1.540 Inches
Nominal Extended Length [CXDZ]: 29.180 Inches
Nominal Compressed Length [CXFN]: 19.810 Inches
Protective Shield Type [CXFW]: No Protection
Special Features [FEAT]: Used On Howitzer Model M109a2e3

Weapon Systems (WSDC) 2510-01-303-2933

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 2510-01-303-2933

Last Stock Position:: 19 In Stock
DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 2510-01-303-2933

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Defense Logistics Agency (DS); EA; Subscribe; 1
Oct 2021: Defense Logistics Agency (DS); EA; Subscribe; 1
Oct 2020: Defense Logistics Agency (DS); EA; Subscribe; 1
Oct 2019: Department of the Army (DA); EA; Subscribe; 1

Army

Materiel Category and Inventory Manager:

J: Ground Forces Support Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

NATO Stock Numbers Related to 2510-01-303-2933

2510-14-512-0438 2510-25-149-9029 2510-12-372-7889 2510-99-300-6212 2510-16-005-1896 2540-15-108-9882 2510-27-045-6178 2540-14-418-0171 2510-14-376-6106 2510-33-105-2187 2510-12-167-0031 2540-15-064-5615 2510-33-003-0177 2510-99-729-2346 2510-33-104-9066 2510-99-750-0353 2510-27-013-5913 2510-99-884-6308

Freight Information 2510-01-303-2933

2510-01-303-2933 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 019500. A Sub NMFC of X. It has a NMFC Description of AUTO SHOCK ABSORBERS R PARTS. 2510-01-303-2933 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 09030 which rates the freight between FCL and LCL. 2510-01-303-2933 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 585 for ocean manifesting and military sealift. 2510-01-303-2933 is not classified as a special type of cargo when transported by water. 2510-01-303-2933 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 2510-01-303-2933

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; --; Over 10lb; Less than 85G; Special Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; 30.0" H x 4.0" W x 4.0" L; --; --; Preservative Coating Only; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: Vendor's Protective Grease or Oil Coating; MIL-PRF-121, Type I, Medium Duty, Greaseproof, Waterproof Barrier; ASTM-D4727, Fiberboard used as Pads, Cells, Die-cuts or Sleeves; --; ASTM - D5118, Fiberboard Box; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: --; No Requirement

Procurement History 2510-01-303-2933 Most Recent 376 Records

Subscribe
View Prices

Contract: Date; CAGE; Quantity; Net Price; Std Price
SPE7LX23F29LW: 28 Sep 2023; Subscribe; 35; Subscribe; Subscribe
SPE7LX23F29WT: 28 Sep 2023; Subscribe; 22; Subscribe; Subscribe
SPE7LX23F29KT: 28 Sep 2023; Subscribe; 51; Subscribe; Subscribe
SPE7LX23F26GJ: 21 Sep 2023; Subscribe; 6; Subscribe; Subscribe
SPE7LX23F12TA: 17 Aug 2023; Subscribe; 26; Subscribe; Subscribe
SPE7LX23F12TA: 17 Aug 2023; Subscribe; 26; Subscribe; Subscribe
SPE7LX23F80X8: 22 Jun 2023; Subscribe; 97; Subscribe; Subscribe
SPE7LX23F80X8: 22 Jun 2023; Subscribe; 97; Subscribe; Subscribe
SPE7LX23F13S4: 06 Apr 2023; Subscribe; 97; Subscribe; Subscribe
SPE7LX23F13S4: 06 Apr 2023; Subscribe; 97; Subscribe; Subscribe
SPE7LX23F938K: 16 Mar 2023; Subscribe; 28; Subscribe; Subscribe
SPE7LX23F938K: 16 Mar 2023; Subscribe; 28; Subscribe; Subscribe
SPE7LX23F803X: 02 Mar 2023; Subscribe; 34; Subscribe; Subscribe
SPE7LX23F803X: 02 Mar 2023; Subscribe; 34; Subscribe; Subscribe
SPE7LX23F670A: 16 Feb 2023; Subscribe; 8; Subscribe; Subscribe
SPE7LX23F670A: 16 Feb 2023; Subscribe; 8; Subscribe; Subscribe
SPE7LX23F540U: 02 Feb 2023; Subscribe; 3; Subscribe; Subscribe
SPE7LX23F540U: 02 Feb 2023; Subscribe; 3; Subscribe; Subscribe
SPE7LX23F491D: 26 Jan 2023; Subscribe; 54; Subscribe; Subscribe
SPE7LX23F491D: 26 Jan 2023; Subscribe; 54; Subscribe; Subscribe
SPE7LX22F76W2: 19 May 2022; Subscribe; 13; Subscribe; Subscribe
SPE7LX22F76W2: 19 May 2022; Subscribe; 13; Subscribe; Subscribe
SPE7LX22F27F7: 14 Apr 2022; Subscribe; 12; Subscribe; Subscribe
SPE7LX22F27F7: 14 Apr 2022; Subscribe; 12; Subscribe; Subscribe
SPE7LX22F902M: 17 Mar 2022; Subscribe; 20; Subscribe; Subscribe
SPE7LX22F902M: 17 Mar 2022; Subscribe; 20; Subscribe; Subscribe
SPE7LX22F072C: 04 Jan 2022; Subscribe; 8; Subscribe; Subscribe
SPE7LX22F072C: 04 Jan 2022; Subscribe; 8; Subscribe; Subscribe
SPE7LX22F8031: 02 Dec 2021; Subscribe; 23; Subscribe; Subscribe
SPE7LX22F8031: 02 Dec 2021; Subscribe; 23; Subscribe; Subscribe
SPE7LX22F5000: 04 Nov 2021; Subscribe; 9; Subscribe; Subscribe
SPE7LX22F5000: 04 Nov 2021; Subscribe; 9; Subscribe; Subscribe
SPE7LX21F427Y: 08 Apr 2021; Subscribe; 10; Subscribe; Subscribe
SPE7LX21F427Y: 08 Apr 2021; Subscribe; 10; Subscribe; Subscribe
SPE7LX21F396G: 01 Apr 2021; Subscribe; 12; Subscribe; Subscribe
SPE7LX21F396G: 01 Apr 2021; Subscribe; 12; Subscribe; Subscribe
SPE7L119F086K: 10 Dec 2018; Subscribe; 4; Subscribe; Subscribe
SPE7L119F082X: 08 Dec 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L119F046B: 01 Dec 2018; Subscribe; 2; Subscribe; Subscribe
SPE7L119F7283: 09 Nov 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L119F7202: 09 Nov 2018; Subscribe; 2; Subscribe; Subscribe
SPE7L119F6717: 08 Nov 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L119F3327: 19 Oct 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L119F2882: 17 Oct 2018; Subscribe; 4; Subscribe; Subscribe
SPE7L119F2197: 12 Oct 2018; Subscribe; 4; Subscribe; Subscribe
SPE7L119F1586: 08 Oct 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L119F1500: 07 Oct 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L119F1414: 05 Oct 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L119F1265: 04 Oct 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L119F1256: 04 Oct 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L119F1222: 04 Oct 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L119F0818: 02 Oct 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F18JJ: 19 Sep 2018; Subscribe; 2; Subscribe; Subscribe
SPE7L118F17ZK: 18 Sep 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F16ND: 14 Sep 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F16JU: 13 Sep 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F15LQ: 12 Sep 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F13LR: 06 Sep 2018; Subscribe; 4; Subscribe; Subscribe
SPE7L118F12JK: 03 Sep 2018; Subscribe; 2; Subscribe; Subscribe
SPE7L118F08BH: 24 Aug 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F07JF: 23 Aug 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F05VL: 17 Aug 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F05MA: 16 Aug 2018; Subscribe; 2; Subscribe; Subscribe
SPE7L118F04UK: 15 Aug 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F03DC: 09 Aug 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F00JT: 01 Aug 2018; Subscribe; 2; Subscribe; Subscribe
SPE7L118F00MF: 01 Aug 2018; Subscribe; 2; Subscribe; Subscribe
SPE7L118F99R4: 31 Jul 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F98H0: 29 Jul 2018; Subscribe; 4; Subscribe; Subscribe
SPE7L118F98D8: 28 Jul 2018; Subscribe; 2; Subscribe; Subscribe
SPE7L118F98A1: 28 Jul 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F97Y5: 27 Jul 2018; Subscribe; 2; Subscribe; Subscribe
SPE7L118F95N9: 25 Jul 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F88A4: 16 Jul 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F87Y0: 15 Jul 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F84U3: 11 Jul 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F83Q7: 10 Jul 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F79C3: 01 Jul 2018; Subscribe; 2; Subscribe; Subscribe
SPE7L118F64J3: 12 Jun 2018; Subscribe; 6; Subscribe; Subscribe
SPE7L118F63X8: 11 Jun 2018; Subscribe; 3; Subscribe; Subscribe
SPE7L118F63N5: 10 Jun 2018; Subscribe; 3; Subscribe; Subscribe
SPE7L118F63P0: 10 Jun 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F62P6: 08 Jun 2018; Subscribe; 6; Subscribe; Subscribe
SPE7L118F59P8: 07 Jun 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F54Z9: 02 Jun 2018; Subscribe; 2; Subscribe; Subscribe
SPE7L118F47V1: 25 May 2018; Subscribe; 2; Subscribe; Subscribe
SPE7L118F34P2: 10 May 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F33F5: 09 May 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F30V5: 06 May 2018; Subscribe; 4; Subscribe; Subscribe
SPE7L118F30V9: 06 May 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F29X0P00001: 04 May 2018; Subscribe; 468; Subscribe; Subscribe
SPE7L118F27H3: 02 May 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F20K5: 25 Apr 2018; Subscribe; 1; Subscribe; Subscribe
SPE7L118F211M: 20 Dec 2017; Subscribe; 4; Subscribe; Subscribe
SPE7L118F217W: 20 Dec 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L118F198E: 19 Dec 2017; Subscribe; 5; Subscribe; Subscribe
SPE7L118F175W: 15 Dec 2017; Subscribe; 5; Subscribe; Subscribe
SPE7L118F119H: 12 Dec 2017; Subscribe; 10; Subscribe; Subscribe
SPE7L118F118F: 12 Dec 2017; Subscribe; 5; Subscribe; Subscribe
SPE7L118F118B: 12 Dec 2017; Subscribe; 5; Subscribe; Subscribe
SPE7L118F055C: 06 Dec 2017; Subscribe; 10; Subscribe; Subscribe
SPE7L118F057B: 06 Dec 2017; Subscribe; 4; Subscribe; Subscribe
SPE7L118F056E: 06 Dec 2017; Subscribe; 15; Subscribe; Subscribe
SPE7L118F9635: 29 Nov 2017; Subscribe; 20; Subscribe; Subscribe
SPE7L118F9317: 28 Nov 2017; Subscribe; 10; Subscribe; Subscribe
SPE7L118F9100: 24 Nov 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L118F8854: 22 Nov 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L118F8382: 21 Nov 2017; Subscribe; 10; Subscribe; Subscribe
SPE7L118F7027: 14 Nov 2017; Subscribe; 5; Subscribe; Subscribe
SPE7L118F6896: 12 Nov 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L118F6589: 09 Nov 2017; Subscribe; 10; Subscribe; Subscribe
SPE7L118F6323: 08 Nov 2017; Subscribe; 10; Subscribe; Subscribe
SPE7L118F5230: 02 Nov 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L118F3073: 22 Oct 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L118F1589: 12 Oct 2017; Subscribe; 4; Subscribe; Subscribe
SPE7L118F1324: 12 Oct 2017; Subscribe; 2; Subscribe; Subscribe
SPE7L118F0203: 01 Oct 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D000715P0: 28 Sep 2017; Subscribe; 2; Subscribe; Subscribe
SPE7L116D000713T3: 25 Sep 2017; Subscribe; 68; Subscribe; Subscribe
SPE7L116D000711M4: 20 Sep 2017; Subscribe; 80; Subscribe; Subscribe
SPE7L116D000708Z0: 13 Sep 2017; Subscribe; 4; Subscribe; Subscribe
SPE7L116D000708A3: 11 Sep 2017; Subscribe; 2; Subscribe; Subscribe
SPE7L116D000706F1: 05 Sep 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D000705S8: 01 Sep 2017; Subscribe; 2; Subscribe; Subscribe
SPE7L116D000705C9: 31 Aug 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D000704G9: 29 Aug 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D000703C6: 24 Aug 2017; Subscribe; 4; Subscribe; Subscribe
SPE7L116D000701L8: 21 Aug 2017; Subscribe; 4; Subscribe; Subscribe
SPE7L116D000701D0: 20 Aug 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007997J: 15 Aug 2017; Subscribe; 11; Subscribe; Subscribe
SPE7L116D0007969K: 04 Aug 2017; Subscribe; 4; Subscribe; Subscribe
SPE7L116D0007955G: 01 Aug 2017; Subscribe; 2; Subscribe; Subscribe
SPE7L116D0007935Q: 27 Jul 2017; Subscribe; 2; Subscribe; Subscribe
SPE7L116D0007914M: 24 Jul 2017; Subscribe; 2; Subscribe; Subscribe
SPE7L116D0007914Z: 24 Jul 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007904E: 21 Jul 2017; Subscribe; 4; Subscribe; Subscribe
SPE7L116D0007905Q: 21 Jul 2017; Subscribe; 4; Subscribe; Subscribe
SPE7L116D0007894G: 20 Jul 2017; Subscribe; 3; Subscribe; Subscribe
SPE7L116D0007897M: 20 Jul 2017; Subscribe; 3; Subscribe; Subscribe
SPE7L116D0007898V: 20 Jul 2017; Subscribe; 3; Subscribe; Subscribe
SPE7L116D0007891B: 18 Jul 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007890Q: 18 Jul 2017; Subscribe; 3; Subscribe; Subscribe
SPE7L116D0007883Y: 17 Jul 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007882D: 16 Jul 2017; Subscribe; 2; Subscribe; Subscribe
SPE7L116D0007784E: 16 Jun 2017; Subscribe; 2; Subscribe; Subscribe
SPE7L116D0007753M: 08 Jun 2017; Subscribe; 3; Subscribe; Subscribe
SPE7L116D0007735S: 05 Jun 2017; Subscribe; 2; Subscribe; Subscribe
SPE7L116D0007730Z: 02 Jun 2017; Subscribe; 2; Subscribe; Subscribe
SPE7L116D0007665Q: 15 May 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007639C: 03 May 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007638Z: 03 May 2017; Subscribe; 200; Subscribe; Subscribe
SPE7L116D0007558B: 10 Apr 2017; Subscribe; 4; Subscribe; Subscribe
SPE7L116D0007556Y: 10 Apr 2017; Subscribe; 134; Subscribe; Subscribe
SPE7L116D0007534K: 31 Mar 2017; Subscribe; 4; Subscribe; Subscribe
SPE7L116D0007525C: 29 Mar 2017; Subscribe; 3; Subscribe; Subscribe
SPE7L116D0007520E: 28 Mar 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007519U: 28 Mar 2017; Subscribe; 2; Subscribe; Subscribe
SPE7L116D0007518N: 27 Mar 2017; Subscribe; 2; Subscribe; Subscribe
SPE7L116D0007514M: 25 Mar 2017; Subscribe; 2; Subscribe; Subscribe
SPE7L116D0007487Y: 18 Mar 2017; Subscribe; 2; Subscribe; Subscribe
SPE7L116D0007485J: 17 Mar 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007453N: 08 Mar 2017; Subscribe; 2; Subscribe; Subscribe
SPE7L116D0007453R: 08 Mar 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007444M: 06 Mar 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007443D: 05 Mar 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007443G: 05 Mar 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007441C: 04 Mar 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007437Z: 03 Mar 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007440G: 03 Mar 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007421F: 28 Feb 2017; Subscribe; 2; Subscribe; Subscribe
SPE7L116D0007421W: 28 Feb 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007399B: 22 Feb 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007361E: 10 Feb 2017; Subscribe; 2; Subscribe; Subscribe
SPE7L116D0007361C: 10 Feb 2017; Subscribe; 4; Subscribe; Subscribe
SPE7L116D0007280C: 19 Jan 2017; Subscribe; 7; Subscribe; Subscribe
SPE7L116D0007271R: 18 Jan 2017; Subscribe; 4; Subscribe; Subscribe
SPE7L116D0007261B: 13 Jan 2017; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007228U: 03 Jan 2017; Subscribe; 62; Subscribe; Subscribe
SPE7L116D0007073H: 12 Nov 2016; Subscribe; 2; Subscribe; Subscribe
SPE7L116D0007065U: 09 Nov 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007054A: 04 Nov 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007050G: 03 Nov 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007050M: 03 Nov 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007044R: 02 Nov 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007019N: 28 Oct 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007020U: 28 Oct 2016; Subscribe; 2; Subscribe; Subscribe
SPE7L116D0007021M: 28 Oct 2016; Subscribe; 4; Subscribe; Subscribe
SPE7L116D0007022E: 28 Oct 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007023K: 28 Oct 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D0007002L: 20 Oct 2016; Subscribe; 2; Subscribe; Subscribe
SPE7L116D0007002M: 20 Oct 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D00079923: 18 Oct 2016; Subscribe; 3; Subscribe; Subscribe
SPE7L116D00079926: 18 Oct 2016; Subscribe; 3; Subscribe; Subscribe
SPE7L116D00079813: 17 Oct 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D00079656: 13 Oct 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D00079540: 10 Oct 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D00079530: 09 Oct 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D00079508: 07 Oct 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D00079352: 04 Oct 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D00079384: 04 Oct 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D00079286: 03 Oct 2016; Subscribe; 2; Subscribe; Subscribe
SPE7L116D00079191: 03 Oct 2016; Subscribe; 4; Subscribe; Subscribe
SPE7L116D00079285: 03 Oct 2016; Subscribe; 2; Subscribe; Subscribe
SPE7L116D00078928: 28 Sep 2016; Subscribe; 24; Subscribe; Subscribe
SPE7L116D00078508: 23 Sep 2016; Subscribe; 2; Subscribe; Subscribe
SPE7L116D00077778: 20 Sep 2016; Subscribe; 3; Subscribe; Subscribe
SPE7L116D00077660: 18 Sep 2016; Subscribe; 4; Subscribe; Subscribe
SPE7L116D00077245: 16 Sep 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D00076772: 12 Sep 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L116D00074064: 10 Aug 2016; Subscribe; 2; Subscribe; Subscribe
SPE7L116D00072789: 28 Jul 2016; Subscribe; 25; Subscribe; Subscribe
SPE7L116D00072012: 20 Jul 2016; Subscribe; 20; Subscribe; Subscribe
SPE7L116D00071923: 19 Jul 2016; Subscribe; 20; Subscribe; Subscribe
SPE7L116D00071651: 14 Jul 2016; Subscribe; 15; Subscribe; Subscribe
SPE7L116D00071551: 13 Jul 2016; Subscribe; 18; Subscribe; Subscribe
SPE7L116D00071360: 07 Jul 2016; Subscribe; 20; Subscribe; Subscribe
SPE7L116D00070187: 21 Jun 2016; Subscribe; 20; Subscribe; Subscribe
SPE7L116D00070005: 17 Jun 2016; Subscribe; 20; Subscribe; Subscribe
SPE7L114D000777X8: 09 Jun 2016; Subscribe; 4; Subscribe; Subscribe
SPE7L114D000777D7: 08 Jun 2016; Subscribe; 2; Subscribe; Subscribe
SPE7L114D000775L3: 30 May 2016; Subscribe; 2; Subscribe; Subscribe
SPE7L114D000772K0: 20 May 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000772K5: 20 May 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000772J9: 20 May 2016; Subscribe; 3; Subscribe; Subscribe
SPE7L114D000772K1: 20 May 2016; Subscribe; 4; Subscribe; Subscribe
SPE7L114D000772C1: 19 May 2016; Subscribe; 3; Subscribe; Subscribe
SPE7L114D000770J0: 14 May 2016; Subscribe; 2; Subscribe; Subscribe
SPE7L114D000769P7: 12 May 2016; Subscribe; 4; Subscribe; Subscribe
SPE7L114D000766T7: 05 May 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000763L5: 27 Apr 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000763X2: 27 Apr 2016; Subscribe; 2; Subscribe; Subscribe
SPE7L114D000762R0: 23 Apr 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000762Q7: 23 Apr 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000760X0: 19 Apr 2016; Subscribe; 8; Subscribe; Subscribe
SPE7L114D000758F3: 11 Apr 2016; Subscribe; 3; Subscribe; Subscribe
SPE7L114D000756Y8: 06 Apr 2016; Subscribe; 3; Subscribe; Subscribe
SPE7L114D000756Y5: 06 Apr 2016; Subscribe; 3; Subscribe; Subscribe
SPE7L114D000754V2: 29 Mar 2016; Subscribe; 3; Subscribe; Subscribe
SPE7L114D000753Y9: 27 Mar 2016; Subscribe; 2; Subscribe; Subscribe
SPE7L114D000754B4: 27 Mar 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000752W7: 24 Mar 2016; Subscribe; 2; Subscribe; Subscribe
SPE7L114D000751E4: 19 Mar 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000750N1: 17 Mar 2016; Subscribe; 4; Subscribe; Subscribe
SPE7L114D000750P5: 17 Mar 2016; Subscribe; 3; Subscribe; Subscribe
SPE7L114D000748S0: 10 Mar 2016; Subscribe; 20; Subscribe; Subscribe
SPE7L114D000747N6: 07 Mar 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000747N7: 07 Mar 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000745G9: 01 Mar 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000745E2: 29 Feb 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000745B9: 28 Feb 2016; Subscribe; 3; Subscribe; Subscribe
SPE7L114D000743T5: 24 Feb 2016; Subscribe; 2; Subscribe; Subscribe
SPE7L114D000738Z7: 10 Feb 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000736V2: 04 Feb 2016; Subscribe; 2; Subscribe; Subscribe
SPE7L114D000735P6: 02 Feb 2016; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000730G6: 22 Jan 2016; Subscribe; 2; Subscribe; Subscribe
SPE7L114D000726T7: 12 Jan 2016; Subscribe; 2; Subscribe; Subscribe
SPE7L114D000717U0: 04 Dec 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D000703T0: 15 Oct 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L114D000702F3: 08 Oct 2015; Subscribe; 60; Subscribe; Subscribe
SPE7L114D0007915S: 12 Sep 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D0007915T: 12 Sep 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D0007888B: 04 Sep 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D0007878L: 02 Sep 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D0007866M: 31 Aug 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L114D0007852S: 28 Aug 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L114D0007852Q: 28 Aug 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L114D0007721B: 21 Jul 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D0007621K: 25 Jun 2015; Subscribe; 4; Subscribe; Subscribe
SPE7L114D0007617K: 24 Jun 2015; Subscribe; 4; Subscribe; Subscribe
SPE7L114D0007593S: 17 Jun 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D0007573P: 11 Jun 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L114D0007539T: 02 Jun 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D0007538G: 02 Jun 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D0007520D: 27 May 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L114D0007516X: 26 May 2015; Subscribe; 6; Subscribe; Subscribe
SPE7L114D0007517B: 26 May 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L114D0007503Q: 21 May 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L114D0007489C: 16 May 2015; Subscribe; 3; Subscribe; Subscribe
SPE7L114D0007440M: 05 May 2015; Subscribe; 7; Subscribe; Subscribe
SPE7L114D0007438Q: 04 May 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D0007415S: 28 Apr 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D0007412Y: 28 Apr 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L114D0007407H: 24 Apr 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L114D0007325J: 06 Apr 2015; Subscribe; 6; Subscribe; Subscribe
SPE7L114D0007325K: 06 Apr 2015; Subscribe; 4; Subscribe; Subscribe
SPE7L114D0007325M: 06 Apr 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D0007298U: 30 Mar 2015; Subscribe; 3; Subscribe; Subscribe
SPE7L114D0007298K: 29 Mar 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D0007297S: 28 Mar 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L114D0007297U: 28 Mar 2015; Subscribe; 13; Subscribe; Subscribe
SPE7L114D0007297M: 28 Mar 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L114D0007282Q: 24 Mar 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L114D0007280D: 24 Mar 2015; Subscribe; 10; Subscribe; Subscribe
SPE7L114D0007276U: 23 Mar 2015; Subscribe; 3; Subscribe; Subscribe
SPE7L114D0007277D: 23 Mar 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L114D0007268X: 20 Mar 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L114D0007264T: 19 Mar 2015; Subscribe; 1; Subscribe; Subscribe
SPE7L114D0007233K: 12 Mar 2015; Subscribe; 25; Subscribe; Subscribe
SPE7L114D0007133M: 19 Feb 2015; Subscribe; 20; Subscribe; Subscribe
SPE7L114D00078713: 06 Jan 2015; Subscribe; 2; Subscribe; Subscribe
SPE7L114D00078391: 23 Dec 2014; Subscribe; 2; Subscribe; Subscribe
SPE7L114D00077545: 15 Dec 2014; Subscribe; 1; Subscribe; Subscribe
SPE7L114D00077267: 11 Dec 2014; Subscribe; 2; Subscribe; Subscribe
SPE7L114D00077028: 09 Dec 2014; Subscribe; 1; Subscribe; Subscribe
SPE7L114D00072718: 23 Oct 2014; Subscribe; 4; Subscribe; Subscribe
SPE7L114D00070806: 25 Sep 2014; Subscribe; 3; Subscribe; Subscribe
SPM7LX13D900293RJ: 03 Sep 2014; Subscribe; 2; Subscribe; Subscribe
SPM7LX13D900293MS: 31 Aug 2014; Subscribe; 2; Subscribe; Subscribe
SPM7LX13D900290YJ: 16 Aug 2014; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900290VA: 15 Aug 2014; Subscribe; 4; Subscribe; Subscribe
SPM7LX13D900290VU: 15 Aug 2014; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900284RX: 18 Jul 2014; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900282EJ: 03 Jul 2014; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900281JQ: 01 Jul 2014; Subscribe; 63; Subscribe; Subscribe
SPM7LX13D900278KQ: 16 Jun 2014; Subscribe; 12; Subscribe; Subscribe
SPM7LX13D900274LN: 29 May 2014; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900272DN: 20 May 2014; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900271CS: 16 May 2014; Subscribe; 2; Subscribe; Subscribe
SPM7LX13D900271JG: 16 May 2014; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900270QU: 15 May 2014; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900270BF: 14 May 2014; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900268ZP: 10 May 2014; Subscribe; 14; Subscribe; Subscribe
SPM7LX13D900267BP: 05 May 2014; Subscribe; 3; Subscribe; Subscribe
SPM7LX13D900255UK: 29 Mar 2014; Subscribe; 8; Subscribe; Subscribe
SPM7LX13D900245QX: 26 Feb 2014; Subscribe; 5; Subscribe; Subscribe
SPM7LX13D900245XY: 26 Feb 2014; Subscribe; 20; Subscribe; Subscribe
SPM7LX13D900245RG: 26 Feb 2014; Subscribe; 2; Subscribe; Subscribe
SPM7LX13D900245KQ: 25 Feb 2014; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900244XK: 24 Feb 2014; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900243ZK: 20 Feb 2014; Subscribe; 3; Subscribe; Subscribe
SPM7LX13D900242MQ: 13 Feb 2014; Subscribe; 3; Subscribe; Subscribe
SPM7LX13D900241WW: 11 Feb 2014; Subscribe; 4; Subscribe; Subscribe
SPM7LX13D900235WB: 13 Jan 2014; Subscribe; 3; Subscribe; Subscribe
SPM7LX13D900235QV: 11 Jan 2014; Subscribe; 2; Subscribe; Subscribe
SPM7LX13D900233QP: 20 Dec 2013; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900233QN: 20 Dec 2013; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900228EA: 21 Nov 2013; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900227SE: 18 Nov 2013; Subscribe; 2; Subscribe; Subscribe
SPM7LX13D900227LQ: 15 Nov 2013; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900226QS: 10 Nov 2013; Subscribe; 3; Subscribe; Subscribe
SPM7LX13D900225NC: 04 Nov 2013; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900225NB: 04 Nov 2013; Subscribe; 2; Subscribe; Subscribe
SPM7LX13D900224RH: 28 Oct 2013; Subscribe; 4; Subscribe; Subscribe
SPM7LX13D900218PP: 06 Sep 2013; Subscribe; 3; Subscribe; Subscribe
SPM7LX13D9002145V: 12 Aug 2013; Subscribe; 2; Subscribe; Subscribe
SPM7LX13D9002130B: 03 Aug 2013; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900211SJ: 26 Jul 2013; Subscribe; 3; Subscribe; Subscribe
SPM7LX13D9002115K: 24 Jul 2013; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900208BQ: 01 Jul 2013; Subscribe; 18; Subscribe; Subscribe
SPM7LX13D9002054H: 09 Jun 2013; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D900203XP: 03 Jun 2013; Subscribe; 4; Subscribe; Subscribe
SPM7LX13D900201XH: 20 May 2013; Subscribe; 4; Subscribe; Subscribe
SPM7LX13D90029734: 08 May 2013; Subscribe; 4; Subscribe; Subscribe
SPM7LX13D90029317: 06 May 2013; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D90027831: 23 Apr 2013; Subscribe; 105; Subscribe; Subscribe
SPM7LX13D90026079: 09 Apr 2013; Subscribe; 4; Subscribe; Subscribe
SPM7LX13D90025536: 04 Apr 2013; Subscribe; 2; Subscribe; Subscribe
SPM7LX13D90024320: 26 Mar 2013; Subscribe; 8; Subscribe; Subscribe
SPM7LX13D90024321: 26 Mar 2013; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D90024074: 22 Mar 2013; Subscribe; 1; Subscribe; Subscribe
SPM7LX13D90022413: 08 Mar 2013; Subscribe; 2; Subscribe; Subscribe
SPM7LX13D90022146: 07 Mar 2013; Subscribe; 2; Subscribe; Subscribe
SPM7LX13D90021961: 06 Mar 2013; Subscribe; 3; Subscribe; Subscribe
SPM7LX13D90021631: 03 Mar 2013; Subscribe; 4; Subscribe; Subscribe
SPM7LX13D90021632: 03 Mar 2013; Subscribe; 4; Subscribe; Subscribe
SPM7LX13D90021571: 01 Mar 2013; Subscribe; 2; Subscribe; Subscribe
SPM7LX13D90021292: 28 Feb 2013; Subscribe; 1; Subscribe; Subscribe
SPM7LX10D9009992P: 17 Feb 2013; Subscribe; 3; Subscribe; Subscribe
SPM7LX10D9009992H: 17 Feb 2013; Subscribe; 4; Subscribe; Subscribe
SPM7LX10D9009953T: 28 Jan 2013; Subscribe; 4; Subscribe; Subscribe
SPM7LX10D900994UJ: 25 Jan 2013; Subscribe; 1; Subscribe; Subscribe
SPM7LX10D900994LZ: 24 Jan 2013; Subscribe; 2; Subscribe; Subscribe
SPM7LX10D9009944R: 22 Jan 2013; Subscribe; 1; Subscribe; Subscribe
SPM7LX10D900992YC: 14 Jan 2013; Subscribe; 2; Subscribe; Subscribe
SPM7LX10D9009932Z: 14 Jan 2013; Subscribe; 2; Subscribe; Subscribe
SPM7LX10D900992YE: 14 Jan 2013; Subscribe; 2; Subscribe; Subscribe

Contracting Technical Data File (CTDF) 2510-01-303-2933 October 2021

Criticality and Quality

Critical Item Code:: X
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: F

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:: Y
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...

Marketplace 2510-01-303-2933

Related Documents 2510-01-303-2933 5+ Documents (More...)

Restrictions 2510-01-303-2933

Import and Export 2510-01-303-2933

End Users 2510-01-303-2933

Approved Sources 2510-01-303-2933

Datasheet 2510-01-303-2933

Weapon Systems (WSDC) 2510-01-303-2933

DLA Procurement Analysis 2510-01-303-2933

Management Data 2510-01-303-2933

Army

NATO Stock Numbers Related to 2510-01-303-2933

Freight Information 2510-01-303-2933

Packaging Data 2510-01-303-2933

Item Pack Level (Unpackaged)

Unit Pack Level (Packaged)

Intermediate Pack Level

Procurement History 2510-01-303-2933 Most Recent 376 Records

Contracting Technical Data File (CTDF) 2510-01-303-2933 October 2021

Criticality and Quality

Commercial Properties

Restrictions

Packaging Requirements
