2320-01-543-4411
Utility Truck
2320015434411 015434411 UTK-SC
A truck with an open body, usually with fabric top and usually equipped with removable seat(s) transverse to its longitudinal axis, designed to transport light cargo. View more Utility Truck
May 2023
4
Marketplace 2320-01-543-4411
Request a Quotation from participating marketplace vendors
Related Documents 2320-01-543-4411 3+ Documents (More...)
United States (US) 4. 2320-01-543-4411 Marketplace Restrictions Approved Sources Datasheet Management
Request a Quotation from participating marketplace vendors Request Updated Every Day 2320-01-543-4411
Restrictions 2320-01-543-4411
IUID Required
2320-01-543-4411 is a Utility Truck that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 2320-01-543-4411
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2320-01-543-4411
- US Air Force (FGG4)
- Effective Date:
- 1 Sep 2006
Approved Sources 2320-01-543-4411
- Part Number
- Manufacturer
- Status
- UTK-SC
- Manufacturer
- 98752 - Warner Robins Air Logistics Center (Active)
- Primary Buy
- Primary Buy
Datasheet 2320-01-543-4411
- Characteristic
- Specifications
- FIIG
- Specifications
- A37500
- Rated Load Capacity [CNTJ]
- 0.85 Tons
- Vehicle Maximum Gross Weight [CPKD]
- 3500.00 Pounds
- Wheel Quantity [AGDH]
- 4
- Drive Wheel Quantity [AGDJ]
- 2
- Drive Axle Location [CNTK]
- Rear
- Axle Drive Type [CNTL]
- Conventional
- Nominal Wheelbase [CNTR]
- 75.00 Inches
- Front Wheel Tread Nominal Width [CNTS]
- 48.62 Inches
- Rear Wheel Tread Nominal Width [CNTT]
- 48.03 Inches
- Prime Mover Type [AKDJ]
- Gasoline Engine
- Cylinder Quantity [AAXZ]
- 4
- Engine Brake Horsepower [ALKK]
- 43.0
- Transmission Type [AXJD]
- Any Acceptable
- Seating Capacity [BTLY]
- 2
- Battery Voltage Rating In Volts [ANLJ]
- 12.0
- Brake Actuation Method [CNYW]
- Hydraulic
- Special Features [FEAT]
- Lsv-Utk;Gvw 3500-4400Lbs;Height 65-80", Width 54-70",Wheelbase 75-100"
Management Data 2320-01-543-4411
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jul 2018
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- L
- R
- Refer To Serial-Vehicle
- SERIAL-VEHICLE
- R
- Department of the Air Force (DF)
- L
- S
- Stock As 2320-01-563-1650
- AAA
- S
- Department of the Air Force (DF)
- L
- Dod I&S Family Master Nsn - - -
- AAB
Air Force
- Budget:
- V
- 57X3080 - Vehicular Equip (REMS) Vehicle Items and centrally funded, procured, and managed replenishment spares (ERRC XD-1, XD-2)
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - U
- Reparable. Condemn at Intermediate. AF Equipment Management System (AFEMS).
Similar Supply Items to 2320-01-543-4411
Freight Information 2320-01-543-4411
2320-01-543-4411 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 190190. A Sub NMFC of X. It has a NMFC Description of VEHICLE MTR:AUTO FRT NOI TRACTORS. 2320-01-543-4411 is rated as class 150 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 93340 which rates the freight between FCL and LCL. 2320-01-543-4411 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 891 for ocean manifesting and military sealift. 2320-01-543-4411 is classified as a Flammable Liquid, UN Class 3, when transported by water. 2320-01-543-4411 is not a consolidation, but exceeds 84" in at least one dimension. It may not be compatible with a standard 72" Aircraft Cargo Door when transported by air.
