2320-01-431-1163
W/Winch C/S 000 Gvw 66 6X6 Light Equipment Transporter Tractor M916a2 Let Truck
2320014311163 014311163 M916A2
A self-propelled wheeled vehicle designed to tow and partially support a semitrailer by means of a fifth wheel-type coupler. See also TRUCK TRACTOR, WRECKER. View more Truck Tractor
May 2023
4
Marketplace 2320-01-431-1163
Request a Quotation from participating marketplace vendors
Related Documents 2320-01-431-1163 5+ Documents (More...)
United States (US) 4. 2320-01-431-1163 Marketplace Restrictions Approved Sources Datasheet Management
Request a Quotation from participating marketplace vendors Request Updated Every Day 2320-01-431-1163
2320014311163 014311163,M916A2 CharacteristicSpecificationsFIIGA524B0End Item Identification [AGAV
] 2320-01-431-1163 https//www.nsnlookup.com /fsg-61/fsc-6150/us 6150-01-435-0402 Electrical Lead 6150014350402014350402
2320014311163 014311163,M916A2 Vehicles 14- to 20-ton Vehicle Configuration, M916A2 https//www.nsnlookup.com
Thickness [ABPX]0.090 Inches NominalMaterial [MATT]Aluminum Alloy 5052End Item Identification [AGAV] 2320-01-431-1163
reparable.Weapons System / End Item / Homogeneous Group:NATactical Vehicles 14- to 20-ton Vehicle Configuration, M916A2
Restrictions 2320-01-431-1163
IUID Required
2320-01-431-1163 is a W/Winch C/S 000 Gvw 66 6X6 Light Equipment Transporter Tractor M916a2 Let Truck that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 2320-01-431-1163
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2320-01-431-1163
- US Army (A202)
- Effective Date:
- 1 May 1996
- Supplementary Receivers:
- AN
Approved Sources 2320-01-431-1163
- Part Number
- Manufacturer
- Status
- M916A2
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
Datasheet 2320-01-431-1163
- Characteristic
- Specifications
- FIIG
- Specifications
- A37500
- Prime Mover Type [AKDJ]
- Diesel Engine
- Cylinder Quantity [AAXZ]
- 6
- Engine Power Rating [CXQS]
- 400.0 Horsepower
- Engine Horsepower Rating Speed In Rpm [ALKL]
- 2100.0
- Piston Displacement [BQXD]
- 12.7 Liters Maximum
- Transmission Type [AXJD]
- Manual
- Seating Capacity [BTLY]
- 2
- Cab Roof Type [CNYT]
- Closed
- Tilting Feature [BBXF]
- Included
- Battery Quantity [AEXR]
- 4
- Battery Voltage Rating In Volts [ANLJ]
- 12.0
- Brake Actuation Method [CNYW]
- Air
- Fifth Wheel Type [CGNY]
- Plate W/Kingpin
- Vehicle Curb Weight [CPKC]
- 27740.0 Pounds
- End Item Identification [AGAV]
- 14- To 20 Ton Vehicle Configuration (M916a2)
Management Data 2320-01-431-1163
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jul 2020
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Sep 2018
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Army (DA)
- L
- R
- Refer To 000%
- 000%
- R
Army
- Materiel Category and Inventory Manager:
- K
- Tactical and Support Vehicles, Combat and Automotive Materiel
- Appropriation and Budget Activity:
- L
- Tactical Vehicles
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- NA
- Tactical Vehicles
14- to 20-ton Vehicle Configuration, M916A2, M916A1, M1062
- Accounting Requirements:
- N
- Nonexpendable item.An item of Army property coded with an ARC of N in the AMDF.Nonexpendable items require property book accountability after issue from the stock record account.Commercial and fabricated items similar to items coded N in the AMDF are considered nonexpendable items.
Similar Supply Items to 2320-01-431-1163
Freight Information 2320-01-431-1163
2320-01-431-1163 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 190190. A Sub NMFC of X. It has a NMFC Description of VEHICLE MTR:AUTO FRT NOI TRACTORS. 2320-01-431-1163 is rated as class 150 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 93340 which rates the freight between FCL and LCL. 2320-01-431-1163 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 867 for ocean manifesting and military sealift. 2320-01-431-1163 is not classified as a special type of cargo when transported by water. 2320-01-431-1163 is not a consolidation, but exceeds 84" in at least one dimension. It may not be compatible with a standard 72" Aircraft Cargo Door when transported by air.
