2320-01-047-8756
W/E 6X6 M929 5T Dump Truck
2320010478756 010478756 XM929 M929 8736989-2
A truck with an open top metal body mounted on a chassis or articulated unit having an integral front panel which may include a cab protector. The metal side panels may be hinged or fitted into grooves which restrict the loss of fine materials, such as sand, gravel, or the like and may have provisions for the attachment of solid side extensions. It may have either a hinged type tailgate with or without a chute opening or a sloped back. It must have a manual or power operated body tilting mechanism to facilitate discharge of its load by gravity. The rear wheels may be powered by a chain, an electric, hydraulic, and/or air motor(s), or conventional drive. Excludes TRUCK, CARGO; TRUCK, FLATBED; TRUCK, STAKE; and TRUCK, VAN. View more Dump Truck
May 2023
8
Marketplace 2320-01-047-8756
Request a Quotation from participating marketplace vendors
Related Documents 2320-01-047-8756 5+ Documents (More...)
M929 5T DUMP TRUCK, 6X6, W/E 4 EA NS Request Quotation Updated Every Day 2320-01-047-8756 RQST
NE Updated Every Day 2320-01-047-8756 RQST Updated Every Day 2320-01-047-8756 RQST NE Related Documents
W/E 6X6 M929 5T Dump Truck 2320010478756 Documents 2320-01-047-8756 5+ Documents ( More... ) https
Includes Bracketp/N1920712300636;Bracket,Mount P/N 1920712300637End Item Identification [AGAV] 2320-01-047-8756
W/E 6X6 M929 5T Dump Truck 2320010478756 CharacteristicSpecificationsFIIGA08400End Item Identification
[AGAV] 2320-01-047-8756 https//www.nsnlookup.com /fsg-99/fsc-9905/us 9905-01-581-8749 Identification
Restrictions 2320-01-047-8756
IUID Required
2320-01-047-8756 is a W/E 6X6 M929 5T Dump Truck that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Non-Critical Munitions List Item or a Non-Sensitive Commerce Control List Item and cannnot be in the possession of any party outside of the USA who is a not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 2320-01-047-8756
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2320-01-047-8756
- US Army (A202)
- Effective Date:
- 1 Apr 1991
- US Navy (NQZZ)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- GG
- Turkey (ZW01)
- Effective Date:
- 1 Dec 1995
Approved Sources 2320-01-047-8756
Datasheet 2320-01-047-8756
- Characteristic
- Specifications
- FIIG
- Specifications
- A37500
- Drive Axle Location [CNTK]
- Front And Rear
- Drive Wheel Quantity [AGDJ]
- 6
- Axle Drive Type [CNTL]
- Any Acceptable
- Battery Quantity [AEXR]
- 4
- Battery Voltage Rating In Volts [ANLJ]
- 12.0
- Body Partition Quantity [CNZW]
- 1
- Brake Actuation Method [CNYW]
- Air
- Cab Type [CNYS]
- Any Acceptable
- Cargo Area Nominal Height [CNZR]
- 23.00 Inches
- Cargo Area Nominal Length [CNZP]
- 125.00 Inches
- Cargo Area Nominal Width [CNZQ]
- 82.00 Inches
- Cylinder Quantity [AAXZ]
- 6
- Engine Brake Horsepower [ALKK]
- 240.0
- Engine Horsepower Rating Speed In Rpm [ALKL]
- 2100.0
- Forward Speed Quantity Per Range [AXJF]
- 1
- Forward Speed Range Quantity [CNTX]
- 5
- Front Axle Engaging Mechanism Type [CNTP]
- Any Acceptable
- Front Wheel Tread Nominal Width [CNTS]
- 75.00 Inches
- Multifuel Design Feature [CNTW]
- Included
- Nominal Wheelbase [CNTR]
- 167.00 Inches
- Prime Mover Type [AKDJ]
- Diesel Engine
- Rear Wheel Mounting Type [CNTQ]
- Dual
- Rear Wheel Tread Nominal Width [CNTT]
- 72.00 Inches
- Reverse Speed Quantity [ATWQ]
- 1
- Seating Capacity [BTLY]
- 3
- Side Removability [CNZT]
- Nonremovable
- Transmission Adjunct Speed Quantity [CNTZ]
- 2
- Transmission Adjunct Type [CNTY]
- Transfer
- Transmission Type [AXJD]
- Automatic
- Vehicle Maximum Gross Weight [CPKD]
- 44548.00 Pounds
- Wheel Quantity [AGDH]
- 6
- Winch Location [CNWB]
- Any Acceptable
Management Data 2320-01-047-8756
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- May 2014
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- May 2013
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- Apr 2003
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- F
- N
- Disposal
- N
Army
- Materiel Category and Inventory Manager:
- K
- Tactical and Support Vehicles, Combat and Automotive Materiel
- Appropriation and Budget Activity:
- L
- Tactical Vehicles
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- NT
- Tactical Vehicles
M939 Family of Vehicles (Includes M939A1 and M939A2)
- Accounting Requirements:
- N
- Nonexpendable item.An item of Army property coded with an ARC of N in the AMDF.Nonexpendable items require property book accountability after issue from the stock record account.Commercial and fabricated items similar to items coded N in the AMDF are considered nonexpendable items.
Navy
- Cognizance:
- 2C
- Major construction and civil engineering equipment
Civil Engineer Support Office
- Issue, Repair, Requisition Restriction Code:
- AH
- Submit/refer requisitions to CESO (Civil Engineer Support Office) CBC Port Hueneme
Similar Supply Items to 2320-01-047-8756
Freight Information 2320-01-047-8756
2320-01-047-8756 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 190190. A Sub NMFC of X. It has a NMFC Description of VEHICLE MTR:AUTO FRT NOI TRACTORS. 2320-01-047-8756 is rated as class 150 when transported by Less-Than Truckload (LTL) freight. 2320-01-047-8756 is rated as class 150 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 93340 which rates the freight between FCL and LCL. 2320-01-047-8756 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 882 for ocean manifesting and military sealift. 2320-01-047-8756 is not classified as a special type of cargo when transported by water. 2320-01-047-8756 is not a consolidation, but exceeds 84" in at least one dimension. It may not be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 2320-01-047-8756
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
- Storage Environment
- Uncovered Space (Open Storage)
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 273.0" H x 97.6" W x 91.3" L
- --
- --
- --
- Special Requirements
- 273.0" H x 97.6" W x 91.3" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special requirement – See specific instructions or drawings provided
- --
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
