2320-01-041-2304
Tank Truck
2320010412304 010412304 6L553
A truck with a tank body mounted on a chassis or articulated unit designed for transporting water, gasoline, oil, or other liquids. It may include facilities for dispensing but excludes trucks with integral spray bars. The rear wheels may be powered by a chain, an electric, hydraulic, and/or air motor(s), or conventional drive. See DISTRIBUTOR (as modified). View more Tank Truck
May 2023
8
Marketplace 2320-01-041-2304
Request a Quotation from participating marketplace vendors
Related Documents 2320-01-041-2304 2+ Documents (More...)
United States (US) 4. 2320-01-041-2304 Marketplace Restrictions Approved Sources Datasheet Management
RQST NE Updated Every Day 2320-01-041-2304 RQST Updated Every Day 2320-01-041-2304 RQST NE Related Documents
Restrictions 2320-01-041-2304
2320-01-041-2304 is a Tank Truck This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item has been determined to be hazardous and information is contained in the Hazardous Materials Information Resource System (HMIRS). The precious metals content of this item is unknown.
Import and Export 2320-01-041-2304
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2320-01-041-2304
- US Army (A202)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Dec 1995
Approved Sources 2320-01-041-2304
- Part Number
- Manufacturer
- Status
- 6L553
- Manufacturer
- 55242 - Isometrics Inc (Active)
- Primary Buy
- Primary Buy
Datasheet 2320-01-041-2304
- Characteristic
- Specifications
- FIIG
- Specifications
- A37500
- Drive Axle Location [CNTK]
- Front And Rear
- Drive Wheel Quantity [AGDJ]
- 6
- Axle Drive Type [CNTL]
- Conventional
- Axle Speed Quantity [CNTM]
- 1
- Battery Quantity [AEXR]
- 1
- Battery Voltage Rating In Volts [ANLJ]
- 12.0
- Body Material [AAFZ]
- Steel
- Brake Actuation Method [CNYW]
- Air
- Cab Type [CNYS]
- Conventional
- Cab Door Quantity [CPLG]
- 2
- Cab Roof Type [CNYT]
- Closed
- Cylinder Quantity [AAXZ]
- 6
- Engine Brake Horsepower [ALKK]
- 190.0
- Engine Horsepower Rating Speed In Rpm [ALKL]
- 2800.0
- Features Provided [CBBL]
- Heavy Duty Cooling System And Power Take-Off
- Forward Speed Quantity [AXJH]
- 10
- Front Wheel Tread Nominal Width [CNTS]
- 78.82 Inches
- Media For Which Designed [ACKL]
- Sewage And Water
- Multifuel Design Feature [CNTW]
- Not Included
- Nominal Wheelbase [CNTR]
- 187.00 Inches
- Prime Mover Type [AKDJ]
- Diesel Engine
- Rated Load Capacity [CNTJ]
- 9.75 Tons
- Rear Wheel Mounting Type [CNTQ]
- Dual
- Rear Wheel Tread Nominal Width [CNTT]
- 71.98 Inches
- Reverse Speed Quantity [ATWQ]
- 2
- Seating Capacity [BTLY]
- 3
- Special Features [FEAT]
- Insulated And Heated Pump Compartment For Cold Weather Operation
- Transmission Type [AXJD]
- Manual
- Wheel Quantity [AGDH]
- 6
- Tank Capacity [BSSM]
- 2000.0 Gallon, Us Measure
- Tank Compartment Quantity [CNZZ]
- 1
- Tank Lining Type [CPBC]
- Any Acceptable
Management Data 2320-01-041-2304
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- May 2005
- Department of the Army (DA)
- EA
- Subscribe
- EA
Army
- Materiel Category and Inventory Manager:
- K
- Tactical and Support Vehicles, Combat and Automotive Materiel
- Appropriation and Budget Activity:
- M
- Commercial Vehicles
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- PZ
- Other Automotive Categories
Nontactical Wheeled Vehicles
- Accounting Requirements:
- N
- Nonexpendable item.An item of Army property coded with an ARC of N in the AMDF.Nonexpendable items require property book accountability after issue from the stock record account.Commercial and fabricated items similar to items coded N in the AMDF are considered nonexpendable items.
Similar Supply Items to 2320-01-041-2304
Freight Information 2320-01-041-2304
2320-01-041-2304 has freight characteristics managed by the General Services Administration (GSA).It has a National Motor Freight Classification (NMFC) of 190190. A Sub NMFC of X. It has a NMFC Description of VEHICLE MTR:AUTO FRT NOI TRACTORS. 2320-01-041-2304 is rated as class 150 when transported by Less-Than Truckload (LTL) freight. 2320-01-041-2304 is rated as class 150 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 93340 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 867 for ocean manifesting and military sealift. 2320-01-041-2304 is not classified as a special type of cargo when transported by water. 2320-01-041-2304 is not a consolidation, but exceeds 84" in at least one dimension. It may not be compatible with a standard 72" Aircraft Cargo Door when transported by air.
