2320-00-965-0651
Cargo Truck
2320009650651 009650651 D200 MILT45338REVF
A truck with either a box type body or a body having integral sides and front panel mounted on a chassis or articulated unit. It usually consists of a flat loading platform, tailgate, removable top bows, and tarpaulin. It may include side extensions or stakes. The rear wheels may be powered by a chain, an electric, hydraulic, and/or air motor(s), or conventional drive. View more Cargo Truck
May 2023
9
Marketplace 2320-00-965-0651
Request a Quotation from participating marketplace vendors
Related Documents 2320-00-965-0651 5+ Documents (More...)
9184 Plug Cock 4820660289184 660289184,D200 -D200 W1400-D200 A component which converts available alternating
Plug Cock 4820660289184 660289184,D200 -A G85139-W1400-D200 W1400-D200 A component //www.nsnlookup.com
/fsg-48/fsc-4820/au
Plug Cock 4820660289184660289184,D200 -D200 W1400-D200 A component Plug Cock 4820660289184660289184,
D200 -A G85139-W1400-D200 W1400-D200 A component //www.nsnlookup.com https//www.nsnlookup.com /fsg-23
W1400-D200 A https ,D200 https//www.nsnlookup.com ,D200 W1400 -D200 A https /fsg- D200 A https W1400
-D200 -D200 A https /fsg-80/fsc ,D200 -D200 W1400-D200 A https ,D200 RQST NE Updated https//www.nsnlookup.com
-D200 W1400-D200 A https ,D200 https Curer 8040991259409991259409,D200 W1400-D200 A https ,D200 RQST
,D200 ,D200 -D200 W1400-D200 A https ,D200 https Curer 8040991259409991259409 ,D200 W1400-D200 A https
,D200 ,D200 -7125/it 7125-15-217-8499 7125152178499152178499,D200 ,D200 -7125/it 7125-15-217-8499 ,D200
-15-232-1656 Reagente Ar Standar 6550152321656 152321656 8040991259409991259409,D200 -D200 W1400-D200
Restrictions 2320-00-965-0651
IUID Required
2320-00-965-0651 is a Cargo Truck that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item has been determined to be hazardous and information is contained in the Hazardous Materials Information Resource System (HMIRS). This item does not contain a precious metal.
Import and Export 2320-00-965-0651
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2320-00-965-0651
- US Air Force (FGG4)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 2320-00-965-0651
- Part Number
- Manufacturer
- Status
- D200
- Manufacturer
- 12204 - Chrysler Realty Company Llc (Active)
- Incomplete Reference
- Incomplete Reference
- D200
- 5KAV0 - Fca Us Llc (Active)
- Primary Buy
- Primary Buy
- MILT45338REVF
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
Datasheet 2320-00-965-0651
- Characteristic
- Specifications
- FIIG
- Specifications
- A37500
- Drive Axle Location [CNTK]
- Rear
- Drive Wheel Quantity [AGDJ]
- 2
- Axle Drive Type [CNTL]
- Conventional
- Axle Speed Quantity [CNTM]
- 1
- Battery Quantity [AEXR]
- 1
- Battery Voltage Rating In Volts [ANLJ]
- 12.0
- Body Material [AAFZ]
- Steel And Wood
- Brake Actuation Method [CNYW]
- Hydraulic
- Cab Roof Type [CNYT]
- Closed
- Cab Door Quantity [CPLG]
- 4
- Cab Type [CNYS]
- Crew
- Cargo Area Nominal Height [CNZR]
- 20.00 Inches
- Cargo Area Nominal Length [CNZP]
- 78.00 Inches
- Cargo Area Nominal Width [CNZQ]
- 54.00 Inches
- Cylinder Quantity [AAXZ]
- 6
- Engine Brake Horsepower [ALKK]
- 140.0
- Engine Horsepower Rating Speed In Rpm [ALKL]
- 3900.0
- Features Provided [CBBL]
- Tailgate
- Forward Speed Quantity [AXJH]
- 4
- Front Wheel Tread Nominal Width [CNTS]
- 64.82 Inches
- Hinge Location [AYTC]
- Bottom And Top
- Nominal Wheelbase [CNTR]
- 146.00 Inches
- Nondefinitive Spec/Std Data [ZZZT]
- 11 Type And B Class
- Prime Mover Type [AKDJ]
- Gasoline Engine
- Rear Wheel Mounting Type [CNTQ]
- Single
- Rear Wheel Tread Nominal Width [CNTT]
- 63.30 Inches
- Rated Load Capacity [CNTJ]
- 0.75 Tons
- Reference Number Differentiating Characteristics [ZZZY]
- As Differentiated By Name,Feat And Model Year 1965
- Reverse Speed Quantity [ATWQ]
- 1
- Seating Capacity [BTLY]
- 6
- Special Features [FEAT]
- Right Hand Drive,Air Temp Heaterno. 87
- Transmission Type [AXJD]
- Manual
- Wheel Quantity [AGDH]
- 4
- Tailgate Operation Method [CNZD]
- Manual
Management Data 2320-00-965-0651
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Sep 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Nov 2011
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- L
- 3
- Reversal Of Phrase Code S 2320-00-580-2954
- 3
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 2320-01-127-4800
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 2320-00-752-9289
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 2320-00-965-0251
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 2320-00-965-0252
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 2320-00-926-3507
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 2320-00-926-3579
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 2320-00-926-3583
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 2320-00-935-0837
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 2320-01-067-9956
- J
- Department of the Air Force (DF)
- L
- R
- Refer To Serial-Vehicle
- SERIAL-VEHICLE
- R
- Department of the Air Force (DF)
- L
- 3
- Reversal Of Phrase Code S 2320-00-580-2954
- 3
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 2320-01-127-4800
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 2320-00-752-9289
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 2320-00-965-0251
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 2320-00-965-0252
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 2320-00-926-3507
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 2320-00-926-3579
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 2320-00-926-3583
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 2320-00-935-0837
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 2320-01-067-9956
- J
- Department of the Air Force (DF)
- L
- R
- Refer To Serial-Vehicle
- SERIAL-VEHICLE
- R
Air Force
- Fund:
- PD
- Regulated items, item manager controlled
- Budget:
- V
- 57X3080 - Vehicular Equip (REMS) Vehicle Items and centrally funded, procured, and managed replenishment spares (ERRC XD-1, XD-2)
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - U
- Reparable. Condemn at Intermediate. AF Equipment Management System (AFEMS).
Similar Supply Items to 2320-00-965-0651
Freight Information 2320-00-965-0651
2320-00-965-0651 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 190190. A Sub NMFC of X. It has a NMFC Description of VEHICLE MTR:AUTO FRT NOI TRACTORS. 2320-00-965-0651 is rated as class 150 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 93340 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 891 for ocean manifesting and military sealift. 2320-00-965-0651 is classified as a Flammable Liquid, UN Class 3, when transported by water. 2320-00-965-0651 is not a consolidation, but exceeds 84" in at least one dimension. It may not be compatible with a standard 72" Aircraft Cargo Door when transported by air.
