2320-00-835-8526
Wrecker Truck
2320008358526 008358526 MILT45362 M108 8358526
A truck with an integral mounted crane boom(s), stationary or revolving, fixed or telescoping, on a chassis or articulated unit. This vehicle is designed for on- or off-the-highway use, primarily for the recovery of disabled vehicles or equipment. The power for crane operations is provided by the truck engine. The rear wheels may be powered by a chain, and electric, hydraulic, and/or air motor(s), or conventional drive. Excludes CRANE, TRUCK MOUNTED. View more Wrecker Truck
May 2023
14
Marketplace 2320-00-835-8526
Request a Quotation from participating marketplace vendors
Related Documents 2320-00-835-8526 5+ Documents (More...)
United States (US) 4. 2320-00-835-8526 Marketplace Restrictions Approved Sources Datasheet Management
M108 TRUCK,WRECKER 99 EA NS Request Quotation Subscribe to View Vendor Details...
https//www.nsnlookup.com /fsg-23/fsc-2320/us 2320-00-706-2224 Van Truck 2320007062224 007062224,MILT45362
https//www.nsnlookup.com /fsg-23/fsc-2320/us 2320-00-690-8365 Van Truck 2320006908365 006908365,MILT45362
to enable JavaScript in your web browser . 2320-00-030-2303Truck Chassis2320000302303 000302303 MILT45362
https//www.nsnlookup.com /fsg-23/fsc-2320/us 2320-00-706-2224 Van Truck 2320007062224 007062224,MILT45362
to enable JavaScript in your web browser . 2320-00-030-2303Truck Chassis2320000302303 000302303 MILT45362
https//www.nsnlookup.com /fsg-23/fsc-2320/us 2320-00-174-1601 Tank Truck 2320001741601 001741601,MILT45362
https//www.nsnlookup.com /fsg-23/fsc-2320/us 2320-00-690-8365 Van Truck 2320006908365 006908365,MILT45362
to enable JavaScript in your web browser . 2320-00-030-2303Truck Chassis2320000302303 000302303 MILT45362
Restrictions 2320-00-835-8526
2320-00-835-8526 is a Wrecker Truck that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is a US Munitions List or Commerce Control List Item where the Item Manager, Equipment Specialist or Product Specialist must provide special demilitarization instructions. This item has been determined to be hazardous and information is contained in the Hazardous Materials Information Resource System (HMIRS). This item does not contain a precious metal.
Import and Export 2320-00-835-8526
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2320-00-835-8526
- US Army (A202)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Apr 2002
Approved Sources 2320-00-835-8526
- Part Number
- Manufacturer
- Status
- 8358526
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- MILT45362
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- M108
- 19207 - U S Army Tank Automotive Command (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
Datasheet 2320-00-835-8526
- Characteristic
- Specifications
- FIIG
- Specifications
- A37500
- Drive Axle Location [CNTK]
- Front And Rear
- Drive Wheel Quantity [AGDJ]
- 6
- Axle Drive Type [CNTL]
- Double Reduction
- Battery Quantity [AEXR]
- 2
- Battery Voltage Rating In Volts [ANLJ]
- 12.0
- Boom Maximum Length [CNWF]
- 210.00 Inches
- Boom Operation Method [CHYJ]
- Power
- Boom Operational Direction [CNWG]
- Elevating And Rotating
- Boom Type [CNWD]
- Single Telescoping
- Brake Actuation Method [CNYW]
- Air And Hydraulic
- Cab Roof Type [CNYT]
- Open
- Cab Door Quantity [CPLG]
- 2
- Cab Type [CNYS]
- Conventional
- Chassis Manufacturer Code And Model Number [CPJX]
- 19207 M45c
- Crane Operation Type [CNWJ]
- Cable
- Cylinder Quantity [AAXZ]
- 6
- Engine Brake Horsepower [ALKK]
- 146.0
- Engine Horsepower Rating Speed In Rpm [ALKL]
- 3400.0
- Engine/Motor Manufacturer Code And Model Number [AGEA]
- 50513 Oa331
- Features Provided [CBBL]
- Outrigger And Towing Pintle Hook And Trailer Brake Connection And Underwater Fording System
- Forward Speed Quantity [AXJH]
- 5
- Front Axle Engaging Mechanism Type [CNTP]
- Automatic
- Front Wheel Tread Nominal Width [CNTS]
- 67.75 Inches
- Gypsy Head [CHZB]
- Not Included
- Maximum Load Rating [AYXK]
- 10000.0 Pounds
- Minimum Swing Angle In Deg [CNWH]
- 360.0
- Nominal Wheelbase [CNTR]
- 154.00 Inches
- Nondefinitive Spec/Std Data [ZZZT]
- 8358526 Class And -108 Model And Truck,Wrecker Type
- Load Lifting Method [CNYR]
- Power
- Load Lifting Capacity Rating [CNYQ]
- 4000.0 Pounds
- Power Divider Unit [CNTN]
- Not Included
- Prime Mover Type [AKDJ]
- Gasoline Engine
- Rear Wheel Mounting Type [CNTQ]
- Dual
- Rear Wheel Tread Nominal Width [CNTT]
- 70.00 Inches
- Rated Load Capacity [CNTJ]
- 2.50 Tons
- Reverse Speed Quantity [ATWQ]
- 1
- Seating Capacity [BTLY]
- 3
- Transmission Adjunct Speed Quantity [CNTZ]
- 2
- Transmission Adjunct Type [CNTY]
- Transfer
- Transmission Type [AXJD]
- Manual
- Trailer Brake Connection Type [CHZG]
- Air
- Vehicle Curb Weight [CPKC]
- 19785.0 Pounds
- Vehicle Maximum Gross Weight [CPKD]
- 23635.00 Pounds
- Wheel Quantity [AGDH]
- 6
- Winch Type [CNWC]
- Single Drum
- Winch Location [CNWB]
- Front
Management Data 2320-00-835-8526
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- May 2012
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
Army
- Materiel Category and Inventory Manager:
- K
- Tactical and Support Vehicles, Combat and Automotive Materiel
- Appropriation and Budget Activity:
- L
- Tactical Vehicles
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- NM
- Tactical Vehicles
5 Ton Vehicle Configuration, Gas
- Accounting Requirements:
- N
- Nonexpendable item.An item of Army property coded with an ARC of N in the AMDF.Nonexpendable items require property book accountability after issue from the stock record account.Commercial and fabricated items similar to items coded N in the AMDF are considered nonexpendable items.
Similar Supply Items to 2320-00-835-8526
Freight Information 2320-00-835-8526
2320-00-835-8526 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 119020. A Sub NMFC of Z. It has a NMFC Description of CRANES O/T REVOLVING ON AUTO. 2320-00-835-8526 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 2320-00-835-8526 is rated as a variable freight class when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 60700 which rates the freight between FCL and LCL. 2320-00-835-8526 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 885 for ocean manifesting and military sealift. 2320-00-835-8526 is not classified as a special type of cargo when transported by water. 2320-00-835-8526 is not a consolidation, but exceeds 84" in at least one dimension. It may not be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 2320-00-835-8526
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
- Storage Environment
- Uncovered Space (Open Storage)
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 303.0" H x 96.4" W x 94.5" L
- --
- --
- --
- Special Requirements
- 303.0" H x 96.4" W x 94.5" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special requirement – See specific instructions or drawings provided
- --
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
