2010-00-540-8599
Ship Propulsion Shaft
2010005408599 005408599 DLG9-203-1540048PC101
A shaft used to transmit to the propeller the torque generated by the main engine of a ship and also to transfer the propeller thrust to the thrust block. View more Ship Propulsion Shaft
May 2023
7
Marketplace 2010-00-540-8599
Request a Quotation from participating marketplace vendors
Related Documents 2010-00-540-8599 1+ Documents (More...)
United States (US) 4. 2010-00-540-8599 Marketplace Restrictions Approved Sources Datasheet Management
Request a Quotation from participating marketplace vendors Request Updated Every Day 2010-00-540-8599
Restrictions 2010-00-540-8599
IUID Required
2010-00-540-8599 is a Ship Propulsion Shaft that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 2010-00-540-8599
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2010-00-540-8599
- US Navy (N2S4)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- GG
Approved Sources 2010-00-540-8599
- Part Number
- Manufacturer
- Status
- DLG9-203-1540048PC101
- Manufacturer
- 80064 - Naval Ship Systems Command (Active)
- Primary Buy
- Primary Buy
Datasheet 2010-00-540-8599
- Characteristic
- Specifications
- FIIG
- Specifications
- T08000
- After Bearing Sleeve Length [CPTP]
- 7.719 Feet Nominal
- After Bearing Sleeve Outside Diameter [CPTH]
- 22.500 Inches Nominal
- After End Design [CPTC]
- Tapered
- After End Keyway [CPJG]
- Provided
- Construction [ARQS]
- Hollow
- Covering Location [CPTS]
- Surfaces Between Bearing Sleeves Covered
- Depth [AEJZ]
- 1.250 Inches Nominal
- Forward Bearing Sleeve Length [CPTG]
- 5.708 Feet Nominal
- Forward Bearing Sleeve Outside Diameter [CPTF]
- 22.500 Inches Nominal
- Forward End Coupling Design [CPJH]
- Integral
- Forward End Coupling Length [CPJL]
- 0.709 Feet Nominal
- Forward End Coupling Outside Diameter [CPJK]
- 34.750 Inches Nominal
- Forward End Coupling Thickness [CPJM]
- 4.250 Inches Nominal
- Forward End Keyway [CPJF]
- Not Provided
- Material Document And Classification [MDCL]
- Mil-S-890, Class An Mil Spec Single Material Response
- Material [MATT]
- Steel
- Outside Diameter [ABKV]
- 20.750 Inches Nominal
- Usage Design [ALCD]
- Suitable For Dlg 6-15
- Inside Diameter [AARX]
- 5.375 Inches Minimum And 14.250 Inches Maximum
- Major Diameter [AAZR]
- 12.500 Inches Nominal
- Protective Covering Type [APZX]
- Rubber
- Quantity [NMBR]
- 2
- Overall Length [ABHP]
- 49.406 Feet Nominal
- Special Features [FEAT]
- Shaft Is Cold Rolled For A Distance Of 12 Ft 9-3/4 In. Starting At The Aft End Of The Propeller Taper
- Thread Length [ABET]
- 11.375 Inches
- Thread Quantity [AZRW]
- 4 Per Inch
- Threaded After End [CPTD]
- Included
- Threaded Forward End [CPNF]
- Not Included
- Unit Type [APQB]
- Propeller Shaft Section
- Usage Location [BPJZ]
- Port/Starboard
- Width [ABGL]
- 3.250 Inches Minimum And 3.313 Inches Maximum
- Surface Finish [AGYE]
- Smooth Machined
- Taper Length [ABND]
- 4.073 Feet Nominal
- Taper Major Diameter [ABQB]
- 20.750 Inches Nominal
- Taper [CTKF]
- 1.000 Per Foot In Inches Nominal
Management Data 2010-00-540-8599
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- May 2011
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
Navy
- Cognizance:
- 2S
- Special Material ID:
- P2
- Propulsion
- Issue, Repair, Requisition Restriction Code:
- XR
- Submit/refer requisitions to NAVSEA. Maintain records by serial number (NAVSEAINST 4440.7 applies)
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
NATO Stock Numbers Related to 2010-00-540-8599
Freight Information 2010-00-540-8599
2010-00-540-8599 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 129930. A Sub NMFC of X. It has a NMFC Description of SHAFTS,TAIL SHIPS PROPELLER SHAFT. 2010-00-540-8599 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. 2010-00-540-8599 is rated as class 85 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 65760 which rates the freight between FCL and LCL. 2010-00-540-8599 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 810 for ocean manifesting and military sealift. 2010-00-540-8599 is not classified as a special type of cargo when transported by water. 2010-00-540-8599 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 2010-00-540-8599
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
- Storage Environment
- Special (see the items storage serviceability standard or technical manual
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Special Requirements
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special requirement – See specific instructions or drawings provided
- --
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
