2010-00-352-0490
Ship Propulsion Shaft
2010003520490 003520490 DE99S4301-127PC103
A shaft used to transmit to the propeller the torque generated by the main engine of a ship and also to transfer the propeller thrust to the thrust block. View more Ship Propulsion Shaft
May 2023
8
Marketplace 2010-00-352-0490
Request a Quotation from participating marketplace vendors
Related Documents 2010-00-352-0490 1+ Documents (More...)
United States (US) 4. 2010-00-352-0490 Marketplace Restrictions Approved Sources Datasheet Management
Request a Quotation from participating marketplace vendors Request Updated Every Day 2010-00-352-0490
Restrictions 2010-00-352-0490
2010-00-352-0490 is a Ship Propulsion Shaft that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 2010-00-352-0490
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2010-00-352-0490
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
Approved Sources 2010-00-352-0490
- Part Number
- Manufacturer
- Status
- DE99S4301-127PC103
- Manufacturer
- 80064 - Naval Ship Systems Command (Active)
- Primary Buy
- Primary Buy
Datasheet 2010-00-352-0490
- Characteristic
- Specifications
- FIIG
- Specifications
- T08000
- After Bearing Sleeve Length [CPTP]
- 4.490 Feet Nominal
- After Bearing Sleeve Outside Diameter [CPTH]
- 9.687 Inches Nominal
- After End Coupling Design [CPNK]
- Integral
- After End Keyway [CPJG]
- Not Provided
- Construction [ARQS]
- Solid
- Coupling Outside Diameter [AHSU]
- 15.750 Inches Nominal
- Coupling Thickness [CPTB]
- 1.750 Inches Nominal
- Covering Location [CPTS]
- Surfaces Between Bearing Sleeve Covered
- Forward End Taper Length [CPNC]
- 0.709 Feet Nominal
- Forward End Taper Major Diameter [CPTT]
- 8.750 Inches Nominal
- Forward End Taper [CTMS]
- 0.125 Per Foot In Inches Nominal
- Forward Bearing Sleeve Length [CPTG]
- 3.645 Feet Nominal
- Forward Bearing Sleeve Outside Diameter [CPTF]
- 9.687 Inches Nominal
- Forward End Design [CPHM]
- Tapered
- Forward End Keyway [CPJF]
- Provided
- Material [MATT]
- Steel,Mil,Mil-S-890,Forged
- Outside Diameter [ABKV]
- 8.750 Inches Nominal
- Usage Design [ALCD]
- De51-113,129-223,234-255,281-285,316-424,438-456,508-511,531-562,567-616,633-644,665-723,739-753,763-774,789-800,Apd-37-40,42-46-48-53,55-57,59-63,65-67,69-81,84-136,139
- Keyway Quantity [AEVE]
- 3 And 1
- Keyway Width [ABRR]
- 1.125 Inches Minimum And 1.187 Inches Maximum
- Keyway Depth [ABRV]
- 0.531 Inches Nominal
- Protective Covering Type [APZX]
- Rubber
- Overall Length [ABHP]
- 27.438 Feet Nominal
- Unit Type [APQB]
- Stern Tube Shaft Section
- Usage Location [BPJZ]
- Port/Starboard
- Surface Finish [AGYE]
- Smooth Machined
- Threaded After End [CPTD]
- Not Included
- Threaded Forward End [CPNF]
- Not Included
Management Data 2010-00-352-0490
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jun 1990
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Navy (DN)
- L
- N
- Disposal
- N
Navy
- Cognizance:
- 2S
- Special Material ID:
- P2
- Propulsion
- Issue, Repair, Requisition Restriction Code:
- XR
- Submit/refer requisitions to NAVSEA. Maintain records by serial number (NAVSEAINST 4440.7 applies)
Similar Supply Items to 2010-00-352-0490
Freight Information 2010-00-352-0490
2010-00-352-0490 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 129930. A Sub NMFC of X. It has a NMFC Description of SHAFTS,TAIL SHIPS PROPELLER SHAFT. 2010-00-352-0490 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. 2010-00-352-0490 is rated as class 85 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 65760 which rates the freight between FCL and LCL. 2010-00-352-0490 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 810 for ocean manifesting and military sealift. 2010-00-352-0490 is not classified as a special type of cargo when transported by water. 2010-00-352-0490 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
